PROGRAMMABLE PARAMETERS
8B, 8C – F1 and F2 Button Action
Options: None
Setup Auto-Start/Stop
Description: Selects the function of the F1 and F2 buttons on the controller.
• 8B
• 8C
8D – Display A or kW
Options: Current (default)
Motor kW
Description: Selects whether the MVE will display current (amperes) or motor kilowatts on the main monitoring
screen.
8E, 8F, 8G, 8H – User-Programmable Screen
Options: Blank
Starter State
Motor Current
Motor pf
Mains Frequency
Motor kW
Motor HP
Motor Temperature
kWh
Hours Run
Analog Input
Mains Voltage
Description: Selects which information will be displayed on the programmable monitoring screen.
• 8E
• 8F
• 8G
8H
•
8I – Performance Graphs
The MVE has a real-time performance graph to report the behaviour of critical operating parameters.
Options: Current (% FLC) (default)
Motor Temperature (%)
Motor kW (%)
Motor kVA (%)
Motor pf
Voltage (%Mains)
Description: Selects which information the graph will display.
52
| MVE User Manual (710-17074-00H)
F1 Button Action
F2 Button Action
Displays no data in the selected area, allowing long messages to be
shown without overlapping.
The starter's operating state (starting, running, stopping or tripped).
Only available for top left and bottom left positions on the screen.
The average current measured on three phases.
The motor's power factor, measured by the soft starter.
The average frequency measured on three phases.
The motor's running power in kilowatts.
The motor's running power in horsepower.
The motor's temperature, calculated by the thermal model.
The number of kilowatt hours the motor has run via the soft starter.
The number of hours the motor has run via the soft starter.
n/a
The average voltage measured on three phases.
User Screen - Top Left
User Screen - Top Right
User Screen - Bottom Left
User Screen - Bottom Right
Current as a percentage of motor full load current.
Motor temperature as a percentage of the motor rated current
(calculated by the soft starter's thermal model).
Motor kilowatts. 100% is motor FLC (parameter 1A) multiplied by
mains voltage. Power factor is assumed to be 1.0.
Motor kilovolt amperes. 100% is motor FLC (parameter 1A)
multiplied by mains voltage.
Motor power factor, measured by the soft starter.
The average voltage measured on three phases as a percentage of
the mains voltage.
Default: Setup Auto-Start/Stop
Default: None
Default: Starter State
Default: Blank
Default: kWh
Default: Hours Run
√3 . V . I . pf
FLC
1000
√3 . V . I
FLC
1000
