2H – Stop Mode
Options: Coast To Stop (default)
TVR Soft Stop
Description: Selects the stop mode.
2I – Stop Time
Range: 0:00 - 4:00 (minutes:seconds)
Description: Sets the time for soft stopping the motor using timed voltage ramp.
If a main contactor is installed, the contactor must remain closed until the end of the stop time.
3 Auto-Stop
The MVE can be programmed to stop automatically, after a specified delay or at a specified time of day.
WARNING
This function should not be used in conjunction with remote two-wire control.
The soft starter will still accept start and stop commands from the remote inputs or serial communication
network. To disable local or remote control, use parameter 6Q.
3A – Reserved
Reserved for future use.
3B – Reserved
Reserved for future use.
3C – Auto-Stop Type
Options: Off (default)
Timer
Clock
Description: Selects whether the soft starter will auto-stop after a specified delay, or at a time of day.
3D – Auto-Stop Time
Range: 00:01 - 24:00 (hours:minutes)
Description: Sets the time for the soft starter to auto-stop, in 24 hour clock format.
4 Protection Settings
These parameters determine when the soft starter's protection mechanisms will activate. The activation point for
each protection mechanism can be set to suit the installation.
The soft starter responds to protection events by tripping, warning, or writing the event to the event log. The response
is determined by the Protection Action settings. The default response is a trip.
CAUTION
The protection settings are vital for safe operation of the soft starter and motor. Defeating the protection
may compromise the installation and should only be done in the case of emergency.
4A – Excess Start Time
Excess start time is the maximum time the MVE will attempt to start the motor. If the motor does not transition to
Run mode within the programmed limit, the starter will trip. Set for a period slightly longer than required for a
normal healthy start. A setting of 0 disables excess start time protection.
Range: 0:00 - 2:00 (minutes:seconds)
Description: Set as required.
4B – Excess Start Time-2
Range: 0:00 - 2:00 (minutes:seconds)
Description: Set as required.
Default:
The soft starter will not auto-stop.
The soft starter will auto-stop after a delay from the next start, as
specified in parameter 3D.
The soft starter will auto-stop at the time programmed in parameter
3D.
Default:
Default:
Default:
PROGRAMMABLE PARAMETERS
0 second
1 minute
20 seconds
20 seconds
