1 CT ratio selector DIP switch S1
2 Non-conduction LEDs (green)
3 Gate firing fibre-optic connectors
4 Firing status LEDs (red)
5 Earth termination point (for voltage sensing ground connections)
6 Voltage sensing input connector (V0 ~ V3)
7 Ground fault CT connector (GF1, GF2)
8 Line CT connectors (CT1 [L11/L12], CT2 [L21/L22], CT3 [L31/L32])
9 Non-conduction readback fibre-optic connectors
10 Fan Fail (C1, C2), DOL protection activated (C3, C4) and Power supply fail input (C5, C6)
11 ID resistors
12 Serial number
13 Fibre-optic connections and LEDs to controller (Rx = Green, Tx = Red)
14 Control supply LED (green)
15 Phase arm power supply control relay output and LED (green)
16 PFC contactor relay output and LED (green)
17 Control terminals
C73, C74 Bypass readback input (BPR)
13, 14 Main device relay output (MC)
23, 24 Bypass device relay output (BC)
33, 34 PFC contactor relay output (PF)
43, 44 Phase arm power supply control relay output (PAPS) / Fan control relay output
V In (A1, A2) Control supply input
18 Bypass device relay output and LED (green)
19 Main device relay output and LED (green)
20 Bypass readback input and LED (green)
NOTE
The fan fail (C1, C2) and power supply fail (C5, C6) inputs are wire linked.
