Inputs
Inputs on Controller
Start (C23, C24) ................................................................................................................... 24 VDC, 8 mA approx
Stop (C31, C32) ................................................................................................................... 24 VDC, 8 mA approx
Reset (C41, C42) ................................................................................................................. 24 VDC, 8 mA approx
Input A (C53, C54) ............................................................................................................... 24 VDC, 8 mA approx
Input B (C63, C64) ............................................................................................................... 24 VDC, 8 mA approx
Motor thermistor (B4, B5) ...................................................................................................... Trip point > 3.6 kΩ
........................................................................................................................................................... Reset > 1.6 kΩ
Inputs on power interface board
Bypass readback input (C73, C74) ..................................................................................... 24 VDC, 8 mA approx
Fan Fail (C1, C2) ................................................................................................................. 24 VDC, 8 mA approx
DOL protection activated (C3, C4) ...................................................................................... 24 VDC, 8 mA approx
Power supply fail input (C5, C6) ......................................................................................... 24 VDC, 8 mA approx
NOTE
All control inputs are potential free. Do not apply external voltage to these inputs.
Outputs
Outputs on Controller
Output Relay A (43, 44) ......................................................................................................... Normally Open
Output Relay B (51, 52, 54) ........................................................................................................ Changeover
Output Relay C (61, 62, 64) ........................................................................................................ Changeover
Analog output (B10, B11) ............................................................................................. 0-20 mA or 4-20 mA
Ratings of output relays on Controller
................................................................................................................................. 10 A @ 250 VAC resistive
................................................................................................................................. 6 A @ 250 VAC 15 p.f. 0.3
................................................................................................................................... 10 A @ 30 VDC resistive
Outputs on power interface board
Main contactor (13, 14) ........................................................................................................ Normally Open
Bypass contactor (23, 24) .................................................................................................... Normally Open
Run Output/ PFC (33, 34) ..................................................................................................... Normally Open
Phase arm power supply control relay output (43, 44) ...................................................... Normally Open
Ratings of output relays on power interface board
................................................................................................................................. 10 A @ 250 VAC resistive
................................................................................................................................... 10 A @ 30 VDC resistive
Environmental
Degree of Protection
Power Assembly .................................................................................................................................... IP00
Controller .............................................................................................................................. IP54/ NEMA 12
Operating temperature ............................................................ - 10 ˚C to + 60 °C, above + 50 °C with derating
Humidity ............................................................................................................ 5%~95% Relative Humidity
Storage temperature .............................................................................................................. - 25 ˚C to + 70 ˚C
Humidity ............................................................................................................ 5%~95% Relative Humidity
Operating Altitude ................................................................................. 0~1000 m, above 1000 m with derating
Pollution degree .................................................................................................................... Pollution Degree 3
Vibration ............................................................................................................. Designed to IEC 60068-2-6-Fc
