11. Appendix
11.1 Parameter Defaults
If you require assistance from your supplier or a service technician, please note all parameter settings in the table below.
1
Primary Motor Settings
Motor Full Load Current
1A
Locked Rotor Time
1B
Locked Rotor Current
1C
Motor Service Factor
1D
2
Start/Stop Modes-1
Start Mode
2A
Start Ramp Time
2B
Initial Current
2C
2D
Current Limit
Reserved
2E
Kickstart Time
2F
Kickstart Level
2G
Stop Mode
2H
Stop Time
2I
3
Auto-Start/Stop
Reserved
3A
Reserved
3B
Auto-Stop Type
3C
Auto-Stop Time
3D
4
Protection Settings
Excess Start Time
4A
Excess Start Time-2
4B
Undercurrent
4C
Undercurrent Delay
4D
Instantaneous Overcurrent
4E
Instantaneous Overcurrent Delay
4F
Phase Sequence
4G
Current Imbalance
4H
Current Imbalance Delay
4I
Frequency Check
4J
Frequency Variation
4K
Frequency Delay
4L
Restart Delay
4M
Motor Temperature Check
4N
Ground Fault Level
4O
4P
Ground Fault Delay
Undervoltage
4Q
Undervoltage Delay
4R
Overvoltage
4S
Overvoltage Delay
4T
Instantaneous Overcurrent S2
4U
Instantaneous Overcurrent Delay S2
4V
User Set 1
User Set 2
MVE User Manual (710-17074-00G) |
APPENDIX
Default Value
100 A
00m:10s
600% FLC
105%
Constant Current
00m:01s
400% FLC
400% FLC
0 ms
500% FLC
Coast To Stop
00m:00s
Off
00h:01m
00m:20s
00m:20s
20% FLC
00m:05s
400% FLC
00m:00s
Positive Only
30%
00m:05s
Run
±5 Hz
00m:05s
30m:00s
Do Not Check
1 A
00m:03s
100 V
00m:05s
7200 V
00m:05s
4400 A
10 ms
73
