AuCom MVE Series User Manual page 25

CONTROLLER
3. Press START or activate the start input. The soft starter simulates its
pre-start checks and closes the main contactor relay.
• On the controller, if parameter 7A (
set to 'Main Contactor', the Relay A LED on the controller activates.
• On the power interface board, the phase arm power supply control relay
and main device LEDs activate.
On the gate drive boards, the gate drive power supply LEDs activate.
•
• On the firing boards on each phase arm, the firing status LEDs activate.
NOTE
If mains voltage is connected, an error message is shown. Remove
mains voltage and proceed to the next step.
4. Press . The MVE simulates starting.
On the controller, the Start LED activates.
•
• On the power interface board, the phase 1 firing status LED starts to
flash.
• On phase arm 1, the firing signal and firing status LEDs start flashing.
5. Press . The soft starter simulates running. The bypass contactor relay
closes.
• On the controller, the Run LED stays on without flashing and the Start
LED turns off.
If parameter 7D (
•
Relay B LED on the controller activates.
On the power interface board, the PFC contactor and bypass device
•
LEDs activate. The phase 2 firing LED flashes.
• The firing signal and firing status LEDs stop flashing on phase arm 1
and start flashing on phase arm 2.
6. Press STOP or activate the stop input. The soft starter simulates stopping.
The bypass contactor relay opens.
• On the controller, the Run LED and Stop LED flash. The Relay B LED
turns off.
On the power interface board, the Phase 3 firing LED flashes.
•
• The firing signal and firing status LEDs stop flashing on phase arm 2
and start flashing on phase arm 3.
7. Press . The Ready LED flashes and the main contactor relay opens.
• On the controller, the Run LED flashes. The Stop LED turns off.
• On the power interface board, all LEDs turn off except control supply
and protection active.
The LEDs on all three phase arms turn off.
•
8. Press to return to the commissioning menu.
NOTE
Run simulation can be exited at any stage by pressing
.
24
| MVE User Manual (710-17074-00H)
7A Output Relay A Functionality
7D Output Relay B Functionality
) is
) is set to 'Run', the
.
Run Simulation
Pre-Start Checks
STORE to Continue
Run Simulation
ATTENTION!
Remove Mains Volts
STORE to Continue
Run Simulation
Starting X:XXs
STORE to Continue
Run Simulation
Running
Apply Stop Signal
Run Simulation
Stopping X:XXs
STORE to Continue
Run Simulation
Stopped
STORE to Continue
