To load or save settings:
1.
Open the Programming Menu
2.
Scroll to Load/Save Settings and press the
3.
Scroll to the required function and press the
access code when prompted.
4.
At the confirmation prompt, select YES to confirm or NO to cancel and
then STORE to load/save the selection.
When the action has been completed, the screen will briefly display a
confirmation message, then return to the Load/Save Settings screen
Access Code
Critical parameters (parameter group 20 and higher) are protected by a four-digit security access code, preventing
unauthorised users from viewing or modifying parameter settings.
When a user attempts to enter a restricted parameter group, the controller prompts for an access code. The access
code is requested once for the programming session, and authorisation continues until the user closes the menu.
To enter the access code, use the
value. When all four digits match your access code, press STORE. The controller will display an acknowledgement
message before continuing.
Enter Access Code
0###
STORE
Access Allowed
SUPERVISOR
To change the access code, use parameter 15A.
9.2
Standard Menu
The standard menu provides access to commonly used parameters, allowing the user to configure the MVE as
required for the application. For details of individual parameters, refer to
1
Motor Data-1
Motor Full Load Current
1A
2
Start/Stop Modes-1
Start Mode
2A
Start Ramp Time
2B
2C
Initial Current
Current Limit
2D
2H
Stop Mode
Stop Time
2I
3
Auto-Start/Stop
Auto-Stop Type
3C
Auto-Stop Time
3D
4
Protection
Excess Start Time
4A
Undercurrent
4C
Undercurrent Delay
4D
Instantaneous Overcurrent
4E
Instantaneous Overcurrent Delay
4F
Phase Sequence
4G
button.
button. Enter the
and
buttons to select a digit, and the
PROGRAMMABLE PARAMETERS
Load Defaults
Load Backup
Load User Set 1
Load Defaults
No
Yes
and
buttons to change the
Parameter Descriptions
on page 42.
MVE User Manual (710-17074-00H) |
37
