Ad-25 Control Door Assembly Without Trim; For Opl (Non-Coin) Models Mfd. As Of November 11, 1998 - ADC AD-15 Parts Manual

4
Illus. No. Part No.
1 881053
870011
2 882265*
3 117604
4 150300
5 102603
6 102601
7 102502
8 882541
* Specify color when ordering.
American Dryer Corporation

AD-25 Control Door Assembly Without Trim

For OPL (Non-Coin) Models Mfd. as of November 11, 1998

Qty. Description
1 ADC Logo ONLY (with double adhesive tape)
1 Logo Double Tape Kit
1 Control Door
(includes illus. nos. 2 and 3)
4 Neoprene Sponge Tape (sold by the foot)
4 #10-16 x 1/2" Hex Washer TEK Screw
1 Control Door Rod Support Catch
1 Control Door Retainer Clip
1 Control Door Support Rod
2 Spring Turn Latch Assembly
88 Currant Road / Fall River, MA 02720-4781
