ADC AD-15 Parts Manual page 47

ADG-15/ADG-25 Direct Spark Ignition (DSI) Burner Assembly
For Models Mfd. prior to May 20, 2000
Illus. No. Part No.
1 318030
2 150300
3 150309
4 880134
5 880330
6 150103
7 153000
8 151001
9 141104
10 --------
11 141230
12 318700
13 150300
14 128927
880960
15 --------*
16 --------*
17 881367
18 142800
19 150309
20 318700
21 850850
850861
--------
22 882627
23 150299
-- --------
* Not available individually...must be purchased as an assembly.
Telephone: (508) 678-9000
Qty. Description
1 Direct Spark Ignition (DSI) Burner Shield
2 #10-16 x 1/2" Hex Washer TEK Screw
2 #10-16 x 1/2" Hex Head TEK Crimptite Screw
1 Ignitor/Flame-Probe Kit Assembly
(includes illus. nos. 4 and 5)
1 High Voltage (HV) Wire Connector Assembly
2 #8-32 x 1/2" Pan Head Machine Screw
2 #8 Steel Burr
2 #8-32 Pal Nut
2 Small Tube Burner ONLY
2 Burner Orifice
(refer to DSI Burner Orifice Listing on page 65)
1 1/2" Direct Spark Ignition (DSI) Manifold (2-port)
1 Pipe Bracket (bent)
2 #10-16 x 1/2" Hex Washer TEK Screw
1 1/2" 24 VAC Redundant Gas Valve (natural gas)
1 1/2" 24 VAC Liquid Propane (L.P.) Gas Valve
Tail Piece Collar ONLY
1 1/2" Union Tail Piece ONLY
1 Union Shut Off Body Complete with Tail Piece and Collar
(includes illus. nos. 15 through 17)
1 1/2" x 18" Pipe
4 #10-16 x 1/2" Hex Head TEK Crimptite Screw
2 Pipe Bracket (bent)
1 Non-Heat Reclaimer Burner Box ONLY
1 Heat Reclaimer Burner Box ONLY
1 Burner Assembly Complete Less Orifices
(refer to DSI Burner Assembly Listing on page 65)
1 ADC Direct Spark Ignition (DSI) Module ONLY
4 #10 x 1" Hex Washer TEK Screw
1 Conversion Kit
(refer to DSI L.P. Conversion Kit Listing on page 65)
45
Fax: (508) 678-9447
