Adg-15/Adg-25 Sail Switch/Hi-Limit Assemblies - ADC AD-15 Parts Manual

ADG-15/ADG-25 Sail Switch/Hi-Limit Assemblies

Illus. No. Part No.
1 154004
2 150309
3 802799
4 150303
5 122200
6 105500
7 319202
8 154002
9 802800
802801
10 142800
11 150309
12 319704
13 151000
14 151001
15 130201
Telephone: (508) 678-9000
Qty. Description
1 Twin Speed Nut
2 #10-16 x 1/2" Hex Head TEK Crimptite Screw
1 Sail Switch Box Cover and Bracket ONLY
2 #4 x 3/4" Pan Head "A" Machine Screw
1 Sail Switch ONLY
1 Sail Switch Actuator Rod
1 Sail Switch Damper (flat)
1 1/8" Push On Fastener
1 Sail Switch Box with Cover and Bracket ONLY
1 Sail Switch Assembly Complete
(includes illus. nos. 1 through 8)
1 1/2" x 18" Pipe
2 #10-16 x 1/2" Hex Head TEK Crimptite Screw
1 Hi-Limit Mounting Bracket ONLY
2 #6-32 Pal Nut
2 #6-32 x 1/2" Round Head Machine Screw
1 330º Hi-Limit ONLY Manual Reset
49
