ADG-15 Direct Spark Ignition (DSI) Burner Assembly

For Models Mfd. as of May 20, 2000

Illus. No. Part No.
8 128927
880960
9 142707
10 142500
11 142754
12 142600
13 883145
883146
883147
883148
850850
809750
14 809308
880330
15 150300
16 318700
17 154004
18 802799
19 122200
20 150303
21 105500
22 319202
23 154002
802800
802801
24 319704
25 150001
26 130201
27 151000
Telephone: (508) 678-9000
Qty. Description
1 1/2" 24 VAC Redundant Gas Valve (natural gas)
(refer to DSI L.P. Conversion Kit Listing on page 65)
1 1/2" 24 VAC Liquid Propane (L.P.) Gas Valve
1 1/2" x 1-1/2" B.I. Nipple
1 1/2 x 90° Elbow
2 1/2" x 8" B.I. Nipple
1 1/2" Black Union
1 Natural Gas Burner Box Assembly Complete Less Orifice
For Non-Heat Reclaimer Models ONLY
1 Liquid Propane (L.P.) Burner Box Assembly Complete Less Orifice
For Non-Heat Reclaimer Models ONLY
1 Heat Reclaimer Natural Gas Burner Box Assembly Complete Less Orifice
1 Heat Reclaimer Liquid Propane (L.P.) Burner Box Assembly Complete
Less Orifice
1 Non-Heat Reclaimer Burner Box ONLY
1 Heat Reclaimer Burner Box ONLY
1 Ignitor/Flame-Probe Assembly with Leads
1 High Voltage (HV) Wire and Connector Assembly
6 #10-16 x 1/2" Hex Washer TEK Screw
1 Pipe Bracket
1 Twin Speed Nut
1 Sail Switch Box Cover and Bracket ONLY
1 Sail Switch
2 #4 x 3/4" Pan Head Machine Screw
1 Sail Switch Actuator Rod
1 Sail Switch Damper (flat)
1 1/8" Push On Fastener
1 Sail Switch Box with Cover
1 Sail Switch Assembly Complete
(includes illus. nos. 15 and 17 through 23)
1 Hi-Limit Mounting Bracket
2 #6-32 x 1/2" Phillips Round Head Machine Screw
1 330º Manual Reset Hi-Limit
2 #6-32 Pal Nut
