Drop Lint Door Assembly Without Trim

For AD-15 OPL Models Mfd. as of July 24, 1999

For AD-25 OPL Models Mfd. as of November 11, 1998

Illus. No.
Part No.
1
800150
160003
160104
2
160008
160009
150425
3
157000
4
883143*
882264*
883141
883142
5
117604
6
150419
7
108120
150418
*
Specify color when ordering.
Telephone: (508) 678-9000
Qty.
Description
1
Knob Latch Kit Assembly
(includes illus. nos. 1 and 2)
1
Dummy Lock ONLY
1
MK-100 Key ONLY
1
Lock Cam
1
Knob Latch Adjustable Cam ONLY
1
#12-24 x 3/8" Round Head Machine Screw ONLY
(screw for knob latch adjustable cam)
1
Drop Lint Door Spring
1
AD-15 Insulated Lint Door Assembly
(includes illus. nos. 4 and 5)
1
AD-25 Insulated Lint Door Assembly
(includes illus. nos. 4 and 5)
1
AD-15 Stainless Steel Lint Door Assembly
(includes illus. nos. 4 and 5)
1
AD-25 Stainless Steel Lint Door Assembly
(includes illus. nos. 4 and 5)
7
Neoprene Sponge Tape (sold by the foot)
2
#6 x 1/2" Tamperproof TEK Screw
1
Chain for Drop Lint Door (10-1/2" length)
1
Tamperproof Screw Hand Driver
27
Fax: (508) 678-9447
