ADC AD-15 Parts Manual page 31

Drop Lint Door Assembly With Trim
For ALL Coin Models
For AD-15 OPL Models Mfd. prior to July 24, 1999
For AD-25 OPL Models Mfd. prior to November 11, 1998
Illus. No. Part No.
1 160001
160103
800150
160003
160104
2 160008
160009
150425
3 157000
4 883267*
800215*
800239
883268*
800219*
800243
5 150201
6 117604
7 117603
102307
8 180210
180310
180211
180311
9 150419
150418
10 108120
* Specify color when ordering.
Telephone: (508) 678-9000
Qty. Description
1 Lock Assembly with Key (for coin models Only)
1 Key ONLY
1 Knob Latch Kit Assembly (for non-coin models Only)
1 Dummy Lock ONLY (for non-coin models Only)
1 MK-100 Key ONLY (master key)
1 Lock Cam for Lock and Dummy Lock
1 Knob Latch Adjustable Cam (for non-coin models Only)
1 #12-24 x 3/8" Right Hand Machine Screw (for knob latch adjustable cam)
1 Drop Lint Door Spring
1 AD-15 Drop Lint Door Assembly with Black Trim
(includes illus. nos. 4 through 8)
1 AD-15 Drop Lint Door Assembly with Gray Trim
(includes illus. nos. 4 through 8)
1 AD-15 Stainless Steel Drop Lint Door Assembly with Gray Trim
1 AD-25 Drop Lint Door Assembly with Black Trim
(includes illus. nos. 4 through 8)
1 AD-25 Drop Lint Door Assembly with Gray Trim
(includes illus. nos. 4 through 8)
1 AD-25 Stainless Steel Drop Lint Door Assembly with Gray Trim
10 #10-32 x 1/4" Phillips Pan Head Machine Screw
7 Noise Suppressor Tape (sold by the foot)
3 Suppressor Tape/Gasket (sold by the foot)
For Models Mfd. as of February 8, 1995
3 Trim Bumper Gasket (sold by the foot)
For Models Mfd. prior to February 8, 1995
2 AD-15 Gray Trim/Kick Plate (31-1/8" long)
2 AD-15 Black Trim/Kick Plate (31-1/8" long)
2 AD-25 Gray Trim/Kick Plate (34-1/8" long)
2 AD-25 Black Trim/Kick Plate (34-1/8" long)
2 #6 x 1/2" Tamperproof TEK Screw
1 Tamperproof Screw Hand Driver
1 Chain for Drop Lint Door
29
