ADC AD-15 Parts Manual page 39

AD-25 Motor Mount Assembly
Illus. No. Part No.
8 122701
122801
9 137030
10 152004
11 153002
12 153001
13 117604
14 154000
15 850017
803935*
880820
803807*
803806*
16 153050
17 100604
18 100702
19 153050
20 152006
21 120200
22 100007*
* Specify voltage when ordering.
Telephone: (508) 678-9000
(continued)
Qty. Description
8 Socket Terminal ONLY
1 Pin/Socket Extraction Tool
1 8-Pin Housing Connector
4 5/16-18 Hex Nut
4 5/16" Lock Washer
4 5/16" Flat Washer
4 1/8" x 3/8" Sponge Tape (sold by the foot)
4 5/16-18 Tinnerman Nut
1 1/2 HP Motor Mount ONLY (56Z frame)
1 1/2 HP 115-230v 1ø 60 Hz Motor Mount Assembly Complete with Plug
Motor
(includes illus. nos. 2 through 7 and 13 through 20)
1 1/2 HP 240v 1ø 50 Hz Motor Mount Assembly Complete with Plug Motor
(includes illus. nos. 2 through 7 and 13 through 20)
1 1/2 HP 208/230/380/460v 3ø 60 Hz Totally Enclosed, Fan-Cooled
(T.E.F.C.) Motor Mount Assembly Complete
(includes illus. nos. 2 through 6 and 13 through 22)
1 1/2 HP 208/230/380/460v 3ø 50 Hz Totally Enclosed, Fan-Cooled
(T.E.F.C.) Motor Mount Assembly Complete
(includes illus. nos. 2 through 6 and 13 through 22)
2 1/2" S.A.E. Flat Washer
1 12-1/2" Impellor with 1/2" Bore
1 1/8" x 1/8" x 1-1/2" Key
2 1/2" S.A.E. Flat Washer
2 1/2-20 Left Hand Jam Nut
1 3/8" 90° Connector
1 1/2 HP 208/230/380/460v 3ø 50/60 Hz Totally Enclosed, Fan-Cooled
(T.E.F.C.) Motor (56Z frame)
37
