ADE-15/ADE-25 Electric Oven Assembly
Illus. No. Part No.
1 803003*
--------*
2 --------*
3 150300
4 802800
802801
5 154004
6 150309
7 802799
8 122200
9 150303
10 105500
11 319202
12 154002
13 150300
14 803100
15 320611
16 150207
17 130400
18 150300
19 154001
20 121010
21 152014
22 --------*
23 --------*
24 120081
25 120080
26 152008
27 121011*
28 --------*
29 153009
30 321300
31 150402
* Refer to ADE-15/ADE-25 Electric Oven Component Application Charts on page 64.
Telephone: (508) 678-9000
Qty. Description
1 Small Electric Oven Box ONLY
1 Electric Oven Assembly Complete
- Electric Element
2 #10-16 x 1/2" Hex Washer TEK Screw
1 Sail Switch Box with Bracket and Cover ONLY
1 Sail Switch Box Assembly Complete
(includes illus. nos. 4 through 12)
1 Twin Speed Nut
2 #10-16 x 1/2" Hex Head TEK Crimptite Screw
1 Sail Switch Box Cover ONLY
1 Sail Switch ONLY
2 #4 x 3/4" Pan Head "A" Machine Screw
1 Sail Switch Actuator Rod
1 Sail Switch Damper (flat)
1 1/8" Push On Fastener
2 #10-16 x 1/2" Hex Washer TEK Screw
1 Electric Oven Front Cover ONLY
1 Large Relay Box Cover ONLY
2 #10-24 x 1/2" Phillips Round Head Machine Screw
1 290º Hi-Limit
2 #10-16 x 1/2" Hex Washer TEK Screw
2 #10-24 Speed Nut
1 L-70 Ground Lug
3 1/4-20 Free Spin Wash Nut
1 Oven Relay
1 Oven Relay Replacement Coil
- Internal Ceramic Insulator (2 per element)
- External Ceramic Insulator (2 per element)
- #10-32 Hex Nut (4 per element)
- Bus Bar
- Terminal Lug
- #10 Star Washer (2 per element)
1 Small Electric Oven Right Side Cover ONLY
2 #10-24 x 5/8" Slotted Truss Head Machine Screw
