Installation Scenarios - Huawei RRU5909 Installation Manual

Table 1 RRU Indicators
Indicator Color
Red and
green
NOTE:
VSWR indicators on RRUs providing one or more than two TX channels have two types of status:
•
Steady off: No VSWR alarm is generated.
•
Steady on: VSWR alarms are generated on one or more ports.
Parent Topic:
RRU Introduction
Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
< Previous topic Next topic >

7.2.2.3.4 Installation Scenarios

An RRU can be installed on a pole, U-steel, angle steel, wall, or IFS06. Installation scenarios must
meet heat-dissipation and waterproofing requirements of the RRU.
•
Requirements for the Installation Scenarios
•
Installing an RRU on a Pole
•
Installing an RRU on U-Steel
•
Installing an RRU on Angle Steel
•
Installing an RRU on a Wall
•
Installing an RRU on an IFS06
Requirements for the Installation Scenarios
NOTICE:
Status Meaning
Steady red An optical module fails to receive or transmit signals
possibly because the optical module is faulty or the
optical fiber is broken.
Blinking red (on for The CPRI link is out of lock because of faults on the
mutual lock of dual-mode clock sources or
1s and off for 1s)
mismatched data rates on CPRI ports.
Steady off The optical module cannot be detected or is powered
off.
