Figure 5 Securing the captive screw into the connection hole
Parent Topic:
Installing the RRU on a Pole
Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Next topic >

7.2.2.7.2.2 Installing Two RRUs

This section describes the procedure and precautions for installing two RRUs on a pole.
Prerequisites
The hoist clamp on the main bracket is secured properly.
NOTICE:
•
Do not stand an
•
Place a foam pad or cardboard under an RRU to protect the RRU housing from damage during
the installation.
Procedure
1. Install the first RRU onto the main bracket, as shown in
.
RRU
RRU upright because the RF ports cannot support the weight of the RRU.
Figure 1
. For details, see
Installing a Single
