7.2.2.7.4 Installing an RRU on Angle Steel

This section describes the process and precautions for installing an
can be installed on angle steel secured on the ground or a tower. Each piece of angle steel allows
only one RRU to be installed in standard or reverse mode.
Prerequisites
•
Before you install an RRU on U-steel secured on a tower, the RRU and its mounting brackets are
hoisted onto the tower. For details, see
•
The hoist clamp on the main bracket is secured properly.
NOTICE:
•
Do not stand an RRU upright because the
•
Place a foam pad or cardboard under an RRU to protect the RRU housing from damage during
the installation.
Context
shows the top view of an RRU installed on angle steel.
Figure 1
Figure 1 Top view of an RRU
(1) Angle steel
Procedure
1. Determine a position for installing the mounting kits.
•
If the RRU is installed on angle steel secured on a tower, determine a position for installing
the mounting brackets according to the instructions in
•
If the RRU is installed on angle steel secured on the ground, determine a position for
installing the mounting brackets according to
Hoisting an RRU onto a Tower
RF ports cannot support the weight of the RRU.
Clearance for a Single RRU
.
Figure 2
RRU on angle steel. An RRU
.
.
