Recommended Clearances for Multiple RRUs Installed in Side-Mounted Mode on a
Wall
shows the recommended clearances for multiple RRUs installed in side-mounted mode on a
Figure 5
wall.
Figure 5 Recommended clearances for multiple RRUs installed in side-mounted mode on a wall
Parent Topic:
Installation Clearance Requirements of an RRU
Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
< Previous topic Next topic >
7.2.2.3.5.3 Installation Spacing Between RRUs
This section describes the horizontal and vertical spacing between RRUs.
•
Recommended Horizontal Spacing Between RRUs
•
Minimum Horizontal Spacing Between RRUs
•
Recommended Vertical Spacing Between RRUs
•
Minimum Vertical Spacing Between RRUs
Recommended Horizontal Spacing Between RRUs
shows the recommended horizontal spacing between RRUs.
Figure 1
Figure 1 Recommended horizontal spacing between RRUs
