7.2.2.7.2.1 Installing a Single RRU

This section describes the procedure and precautions for installing a single
Prerequisites
•
Before you install an RRU on a pole secured on a tower, the RRU and its mounting kits are
hoisted onto the tower. For details, see
•
The hoist clamp on the main bracket is secured properly.
NOTICE:
•
Do not stand an RRU upright because the
•
Place a foam pad or cardboard under an RRU to protect the RRU housing from damage during
the installation.
Procedure
1. Determine a position for installing the mounting kits.
•
If the RRU is installed on a tower, determine a position for installing the mounting kits
according to the instructions in
•
If the RRU is installed on the ground, determine a position for installing the mounting kits
according to
Figure 1 Distance between the mounting kits and the ground
NOTE:
As shown in the figure above, it is recommended that the mounting kits be installed at a position 1200 mm
(47.24 in.) to 1600 mm (59.06 in.) high above the ground. If the space is insufficient, only the
Clearance Requirements of an RRU
Clearance for a Single RRU
.
Figure 1
needs to be provided.
Hoisting an RRU onto a Tower
RF ports cannot support the weight of the RRU.
.
RRU on a pole.
.
