Mounting Kits For An Rru - Huawei RRU5909 Installation Manual

This section describes the procedure and precautions for installing an RRU on U-steel. An
RRU can be installed on U-steel secured on the ground or a tower. Each piece of U-steel
allows only one RRU to be installed in standard or reverse mode.
Installing an RRU on Angle Steel
This section describes the process and precautions for installing an RRU on angle steel. An
RRU can be installed on angle steel secured on the ground or a tower. Each piece of angle
steel allows only one RRU to be installed in standard or reverse mode.
Installing an RRU on a Wall
This section describes the procedure and precautions for installing an RRU on a wall.
Installing an RRU on an IFS06
This section describes the process and precautions for installing an RRU on an IFS06.
Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
< Previous topic Next topic >

7.2.2.7.1 Mounting Kits for an RRU

This section describes the bracket assembly and the attachment plate for an RRU.
shows the front and side of an RRU.
Figure 1
Figure 1 Front and side view of an RRU
(1) Front view
shows the bracket assembly for an RRU.
Figure 2
NOTE:
The RRU described in this document must use the required RRU mounting kits in new deployment scenarios.
(2) Side view (3) Attachment plate
