Figure 8 Securing the captive screw into the connection hole
Parent Topic:
Installing the RRU
Huawei Proprietary and Confidential Copyright © Huawei Technologies Co., Ltd.
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
< Previous topic Next topic >

7.2.2.7.6 Installing an RRU on an IFS06

This section describes the process and precautions for installing an
Prerequisites
The hoist clamp on the main bracket is secured properly.
NOTICE:
•
Do not stand an RRU upright because the
•
Place a foam pad or cardboard under an RRU to protect the RRU housing from damage during
the installation.
Context
•
The upper and lower adjustable beams on an IFS06 can be moved up and down to fit for heights
of RRUs.
•
RRUs can be installed on an IFS06 when the ambient temperature is higher than or equal to the
lowest operating temperature of the RRUs and at least 5°C (41°F) lower than the highest working
temperature of the RRU. In this scenario, the IFS06 supports at least three RRUs. The IFS06
supports a maximum of six RRUs when the ambient temperature is higher than or equal to the
RF ports cannot support the weight of the RRU.
RRU on an IFS06.
