Figure 8 Stripping the sheath off the power cable
NOTICE:
Each core wire is exposed outside the female fast connector (pressfit type) for 1.5 mm (0.059
in.), as shown in .
Figure 9
Figure 9 Inserting core wires into the female fast connector (pressfit type)

Exception Handling

If the power terminal or cable is damaged or abnormal, remove the power cable.
1. Press the spring clip of the power terminal using a screwdriver and remove the power cable.
