Fastening Cables Using Clips - Huawei RRU5909 Installation Manual

This section describes the procedure for closing the cover plate of an
Procedure
1. Fasten the cables using clips, as shown in
NOTICE:
Ensure that the exposed shield layer of the power cable is properly tightened using the clip.
Figure 1 Fastening cables using clips
2. Insert waterproof blocks into vacant cable troughs in the cabling cavity, as shown in
NOTICE:
Ensure that cables and waterproof blocks are properly inserted into troughs.
.
Figure 1
RRU cabling cavity.
Figure 2
.
