NOTICE:
Angle steel supports only the standard or reverse installation of a single RRU.
shows an RRU installed on angle steel.
Figure 12
Figure 12 RRU installed on angle steel

Installing an RRU on a Wall

The wall for installing RRUs must meet the following requirements:
•
For each RRU, the wall must be able to bear a weight four times heavier than the RRU's weight
and the bolts' pulling force of 1.25 kN (281.25 lbf) vertical to the wall.
•
Expansion bolts must be tightened to 30 N·m (265.52 lbf·in.) to ensure that the bolts work
properly and the wall remains intact.
NOTICE:
•
The standard installation is recommended for RRUs installed on a wall.
•
When RRUs are installed on a wall in side-mounted mode, RRU stacked installation is not
allowed, as shown in .
Figure 13
