Nicolet FTIR Spectrometers
Nicolet Summit
User Guide
269-334400
Revision E
December 2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nicolet Summit and is the answer not in the manual?

Questions and answers

Related Manuals for Thermo Scientific Nicolet Summit

Summary of Contents for Thermo Scientific Nicolet Summit

  • Page 1 Nicolet FTIR Spectrometers Nicolet Summit User Guide 269-334400 Revision E December 2019...
  • Page 2 © 2019 Thermo Fisher Scientific Inc. All rights reserved. Microsoft, Windows and Excel are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. All other trademarks are the property of Thermo Fisher Scientific Inc. and its subsidiaries.

  • Page 3: Table Of Contents

    Chapter 2 Get Started with Your Nicolet Summit Spectrometer ..... . .3 Before Your Summit Spectrometer Arrives ......4 Personal Safety with the Summit Spectrometer .

  • Page 5: Chapter 1 Welcome

    Welcome The Thermo Scientific Nicolet™ Summit Fourier transform infrared (FTIR) spectrometer lets you perform chemical analyses of sample materials by collecting data in the mid-IR spectral range using a variety of accessories. The system has integrated verification features, a powerful software suite, and many other features that make data collection easy.

  • Page 6: Ordering Parts

    If you need to send the instrument or an accessory to us for repair, call or e-mail us first for any shipping requirements or other instructions. Contacting Us For Technical Support, please contact: www.thermofisher.com If you have problems with your system, call Technical Support. Nicolet Summit User Guide Thermo Scientific...

  • Page 7: Chapter 2 Get Started With Your Nicolet Summit Spectrometer

    Get Started with Your Nicolet Summit Spectrometer To get started with your new Nicolet Summit Spectrometer, review the site and safety requirements before the instrument arrives, unpack and setup the instrument, and connect any additional accessories. Contents • Before Your Summit Spectrometer Arrives •...

  • Page 8: Before Your Summit Spectrometer Arrives

    Preparing the Workspace Before your instrument arrives, make sure your workspace will be able to properly support the spectrometer. In addition to allowing enough room for the spectrometer, consider several environmental and electrical requirements. Thermo Scientific Nicolet Summit User Guide...
  • Page 9 Keep the instrument away from sources of cool or hot air, such as near heating and air conditioning vents or large windows. If your spectrometer will be kept in an especially humid environment, consider installing a purge gas kit. Thermo Scientific Nicolet Summit User Guide...
  • Page 10 Input Voltage 100–240 VAC Line Frequency 47–63 Line Disturbances Sags, surges, or other line disturbances must not exceed 10% of input voltage Noise Less than 2 V (common mode) Less than 20 V (normal mode) Thermo Scientific Nicolet Summit User Guide...

  • Page 11: Personal Safety With The Summit Spectrometer

    (HCl), hydroflouric acic (HF), or phosgene (COCl WARNING Avoid toxic inhalation. Hydrochloric acid, hydrofluoric acid, and phosgene are highly toxic. If you are using solvents containing halogenated hydrocarbons, ensure your work area is properly ventilated. Thermo Scientific Nicolet Summit User Guide...
  • Page 12 Biohazard or Radioactive Materials and Infectious Agents Biological samples, such as tissues, body fluids, infectious agents, and blood, have the potential to transmit infectious diseases. Follow your organization’s Biosafety Program protocols for working with potentially infectious materials. Thermo Scientific Nicolet Summit User Guide...
  • Page 13 You may be exposed to different hazards while performing maintenance on the instrument than you would encounter during normal use. During maintenance, the primary hazards involve purging the instrument and working with the instrument’s internal components. Thermo Scientific Nicolet Summit User Guide...
  • Page 14 • If you adjust the laser or perform procedures that are not described in the user guides and manuals, you could be exposed to hazardous radiation. Thermo Scientific Nicolet Summit User Guide...
  • Page 15 Summary The Nicolet Summit spectrometer is a safe and rugged instrument, but you can be exposed to hazards during use and maintenance. During normal operation, use caution when handling potentially hazardous samples and solvents and avoid parts of the spectrometer that are hot or emit heat.

  • Page 16: Unpack And Get Started With The Spectrometer

    Unpack and Get Started with the Spectrometer Unpacking and setting up your Thermo Scientific™ Nicolet™ Summit Spectrometer requires you to place the instrument in your workspace, to connect and power on the spectrometer, and to run a short performance test.
  • Page 17 10. Mini DisplayPort to HDMI adapter 4. Everest ATR Accessory 11. WiFi access dongle (comes pre-installed 5. Touchscreen monitor if purchased) 6. ZnSe window replacement kit, including Not shown: Optional 22” High-Definition window replacement tool and nitrile gloves Monitor Thermo Scientific Nicolet Summit User Guide...
  • Page 18 NOTICE Use care when lifting the spectrometer. • Do not grasp the touchscreen monitor to lift the spectrometer. • Do not touch the sample compartment windows while unpacking the instrument. Touching the windows could cause permanent damage. Thermo Scientific Nicolet Summit User Guide...
  • Page 19 It is recommended that you leave the password blank during initial setup and later create a secure password and additional user accounts as needed. a. Connect the power supply to the spectrometer and to a properly grounded AC power source. Thermo Scientific Nicolet Summit User Guide...
  • Page 20 Launch the Thermo Scientific™ OMNIC™ Paradigm software. The first time the software starts, it will open with the touchscreen interface. Later, you can switch between the touchscreen and the desktop interfaces.
  • Page 21 Windows 10 includes several built-in tools for backing up and recovering your data. For instructions on creating a recovery drive and system image and on restoring your system, “Back up and Recover Your Data.” Thermo Scientific Nicolet Summit User Guide...

  • Page 22: Back Up And Recover Your Data

    1. Insert the flash drive in one of the USB ports on the side of the spectrometer. 2. In the Windows 10 search box in the taskbar, search for “Create Recovery Drive” and select Create Recovery Drive. Thermo Scientific Nicolet Summit User Guide...
  • Page 23 Depending on how much data you copy to the system image, the process may take a while. If you are copying a large amount of data, it may take more than an hour for the process to complete. Required Materials • NTFS formatted SSD Thermo Scientific Nicolet Summit User Guide...
  • Page 24 6. When asked “Do you want to create a system repair disc,” click No. 7. Click Close and safely remove the SSD from the Summit. Label the drive as Summit Recovery and store it in safe place. Thermo Scientific Nicolet Summit User Guide...
  • Page 25 3. Connect the USB recovery drive to one of the USB ports. 4. Turn the system on. 5. When the screen shows the Thermo Scientific splash screen, tap “Esc” on the keyboard several times to open the system BIOS. If a popup dialog shows “Quit Without Saving?” use the arrow keys to select No.
  • Page 26 14. In the “Select a system image backup” window, use the latest available system image or select another system image. Click Next. 15. Click Next to leave additional restore options in their default state, and click Finish to restore the system image. Click Yes to confirm. Thermo Scientific Nicolet Summit User Guide...
  • Page 27 Windows 10 features several options for backing up files, including the File History tool. The information technology (IT) personnel at your organization should determine which backup methods are best for your organization’s needs. Thermo Scientific Nicolet Summit User Guide...

  • Page 28: Connect An External Monitor

    USB devices, such as wireless keyboards and mice. If you notice performance issues with your wireless keyboard and mouse, such as lag or delayed or missed input, use the provided USB extension cable to position the wireless USB receiver farther from the USB ports. Thermo Scientific Nicolet Summit User Guide...

  • Page 29: Install A Sampling Accessory

    Integrated accessories and baseplates are easy to install and remove and are recognized automatically by OMNIC Paradigm software. Installing Integrated Accessories Integrated accessories such as the Thermo Scientific™ Everest™ ATR Accessory fit over two alignment pins on the spectrometer baseplate and are held in place by magnets. 1. Pins 2.
  • Page 30 Install a Sampling Accessory  To install an integrated accessory 1. Hold the accessory by the front and rear handles and lower it into the spectrometer sample compartment. Magnets hold the accessory in place. Thermo Scientific Nicolet Summit User Guide...
  • Page 31 Note To remove an accessory, disconnect the purge line if necessary and then grasp the accessory by the handles and lift it up. When not using an accessory, store it in a dust-free environment, such as a cabinet or box. Thermo Scientific Nicolet Summit User Guide...
  • Page 32 The iD Base Adapter has two sets of screw holes so the slide mount can be installed facing either direction. To install the slide mount, position it over the screw holes, and then insert and tighten the two washers and screws. Thermo Scientific Nicolet Summit User Guide...
  • Page 33 To install an accessory using the iD Base Adapter 1. Attach the accessory to the iD Base Adapter. 2. Place the iD Base Adapter on the two pins in the spectrometer baseplate. Strong magnets hold the adapter and accessory in place. Thermo Scientific Nicolet Summit User Guide...
  • Page 34 2” X 3” slide mount.  To install a slide-mounted accessory 1. Slide the accessory into one pair of slots in the iD1 Transmission Accessory. Thermo Scientific Nicolet Summit User Guide...
  • Page 35 Install a Sampling Accessory Choose a pair of slots that will place the center of the accessory at the beam focus (designated by arrow heads on the accessory housing). Thermo Scientific Nicolet Summit User Guide...

  • Page 36: Understand The Spectrometer Lightbar

    Understand the Spectrometer LightBar The Thermo Scientific™ Nicolet™ Summit FTIR Spectrometer features a convenient LightBar that gives you a quick, visual pass/fail indication of product quality and instrument status at a glance. The following tables describes all of the LightBar’s signals.
  • Page 37 30% for a threshold match value of 30. Diagnostics Signal System Status Description Red Flash System error Full LightBar flashes red. See System Status in OMNIC Paradigm software for a description of the error. Thermo Scientific Nicolet Summit User Guide...

  • Page 38: View Your Data With The Omnic Anywhere App

    Connect account, and view, explore, or share the data on another device in your dorm or workspace. For instructions on creating a Connect account and viewing your data with OMNIC Anywhere, visit “Cloud-enabled FTIR Spectroscopy”. Thermo Scientific Nicolet Summit User Guide...

  • Page 39: Chapter 3 Options And Accessories

    Options and Accessories The Nicolet Summit Spectrometer can be used with the optional purge kit and is compatible with a wide range of sampling accessories. Contents • Sampling Accessories for the Summit Spectrometer • Install and Maintain a Purge Kit...

  • Page 40: Sampling Accessories For The Summit Spectrometer

    Sampling Accessories for the Summit Spectrometer The Thermo Scientific™ Nicolet™ Summit FTIR spectrometers are compatible with Thermo Scientific™ Nicolet™ iS5 iD sampling accessories and hundreds of other third-party accessories. For instructions on installing a sampling accessory, see “Install a Sampling Accessory.”...
  • Page 41 The Golden Gate ATR accessory is also ideal for macro sampling. For details, see “Thermo Scientific™ Golden Gate ATR for Nicolet iS5 FTIR Spectrometer.” Thermo Scientific Nicolet Summit User Guide...

  • Page 42: Install And Maintain A Purge Kit

    Setup needed Before installing the purge kit, you will need a source of dry air or nitrogen that meets Thermo Scientific specifications for the Nicolet™ Summit Spectrometer. See the instrument’s Site and Safety guide for details. Note For best results, dry the purge gas to a dew point of -70 °C (-94 °F) or below.
  • Page 43 Wrap the reducing nipple or the 1/4-inch male fitting with thread seal tape, and then install the pressure coupling. Use a 3/4-inch open-ended wrench to tighten the connection. Thermo Scientific Nicolet Summit User Guide...
  • Page 44 Entry of flammable liquids or gases into the desiccant compartment is an explosion hazard. If such entry occurs, contact us immediately and do not apply power to the instrument until the condition has been corrected. Thermo Scientific Nicolet Summit User Guide...
  • Page 45 O-ring, and then secure it using the two screws. Note the correct orientation of the cartridge. You should be able to read the label on the cartridge from the front of the instrument when the cartridge is installed. Thermo Scientific Nicolet Summit User Guide...
  • Page 46 4-10 iD5 ATR Accessory 4-10 iD Foundation 4-10 b. Plug in the power cord to the instrument and turn on the power. c. Wait 30 - 60 minutes for the instrument to fully purge. Thermo Scientific Nicolet Summit User Guide...
  • Page 47 • Accessory pressure, 5 psig (34 kPa) • Accessory flow: 4 –10 scfh (1.9 – 4.7 l/min) NOTICE Flow rates greater than recommended values can cause vibration, which can affect the quality of your data. Thermo Scientific Nicolet Summit User Guide...
  • Page 48 1. Turn off the purge gas at the main valve. Do not turn down the flowmeter or the pressure regulator. 2. Remove the plastic bowl that houses the filter and then remove the filter. (You can unscrew them both by hand.) Filter Bowl Thermo Scientific Nicolet Summit User Guide...
  • Page 49 Install and Maintain a Purge Kit 3. Install the new filter and then reinstall the bowl. 4. Open the main valve to turn on the purge flow to the instrument and verify proper purge gas flow rate. Thermo Scientific Nicolet Summit User Guide...

  • Page 50: Chapter 4 Maintenance

    Maintenance Your Thermo Scientific™ Nicolet™ Summit FTIR Spectrometer requires little upkeep and no daily maintenance. However, basic care will ensure continued peak performance. Contents • Maintenance Schedule for the Summit Spectrometer • Align the Spectrometer Optics • Calibrate the Laser Frequency •...

  • Page 51: Maintenance Schedule For The Summit Spectrometer

    Maintenance Schedule for the Summit Spectrometer Your Thermo Scientific™ Nicolet™ Summit FTIR Spectrometer requires little upkeep and no daily maintenance. However, basic care will ensure continued peak performance. Follow the guidelines in this article. For best performance, leave the spectrometer powered on.
  • Page 52 Pink or white Desiccant has expired Replace the desiccant and the humidity indicator For more information, see the article titled “Replace the Desiccant” in the online help. Thermo Scientific Nicolet Summit User Guide...
  • Page 53 Purge Gas Filter” in the article titled “Install and Maintain a Purge Kit” in the online help. Figure 2. The purge filter is located inside of the plastic bowl below the pressure gauge Thermo Scientific Nicolet Summit User Guide...

  • Page 54: Align The Spectrometer Optics

    To align the spectrometer optics (desktop) 1. Select Acquire Data > Diagnostics > Align Spectrometer. 2. In the Align Spectrometer dialog, click Start. The system automatically aligns the spectrometer and indicates when alignment is complete. Thermo Scientific Nicolet Summit User Guide...

  • Page 55: Calibrate The Laser Frequency

    ]to open the Diagnostics view. 2. Open the Laser Calibration tab and touch Calibrate to begin. When laser calibration is complete, a message indicates whether the laser frequency has been changed and displays the new frequency. Thermo Scientific Nicolet Summit User Guide...

  • Page 56: Clean The Spectrometer And Touchscreen

    Clean the Spectrometer and Touchscreen Before cleaning the Thermo Scientific™ Nicolet™ Summit spectrometer, turn it off and disconnect the power supply. Clean the Summit Spectrometer Gently clean the exterior of the instrument with a soft, clean cloth lightly dampened with mild soap.
  • Page 57 To clean the screen, apply window or glass cleaner to a clean cloth or sponge, and gently wipe the screen with the cloth. CAUTION Do not use alcohol (methyl, ethyl, or isopropyl), thinner, benzene, or other abrasive cleaners. NOTICE Never apply the cleaner directly to the touchscreen. Thermo Scientific Nicolet Summit User Guide...

  • Page 58: Replace The Desiccant

    WARNING Replace the desiccant only with replacement parts supplied by us.  To replace the desiccant 1. Turn off the spectrometer. a. To turn off the spectrometer, press the power button. b. Unplug the power cord. Thermo Scientific Nicolet Summit User Guide...
  • Page 59 3. Remove the desiccant canisters and replace the humidity indicator. WARNING The contents of the desiccant canisters (hydrated metal aluminosilicate molecular sieve) could be harmful if ingested. If you discard the saturated desiccant canisters, make sure they are properly disposed of. Thermo Scientific Nicolet Summit User Guide...
  • Page 60 Insert the canisters into the channel of the desiccant cartridge and tighten the eight screws (approximately 2 turns) until they are flush with the cartridge channel. Thermo Scientific Nicolet Summit User Guide...
  • Page 61 Reconnect the purge line to the instrument, if applicable, and turn on the purge. 7. Verify the instrument performance. a. When the instrument is warmed up, open OMNIC Paradigm software and run the Nicolet FTIR - Factory Qualification workflow. Thermo Scientific Nicolet Summit User Guide...

  • Page 62: Replace The Source

    Remove any installed accessories from the instrument. CAUTION The source becomes extremely hot while you are using the instrument. Wait at least 10 minutes after turning the instrument off before you perform the next step. Thermo Scientific Nicolet Summit User Guide...
  • Page 63 Summit PRO spectrometer with touchscreen monitor in the storage position b. Carefully tip the instrument back until it rests on the fins of the heat sink. Do not use the touchscreen monitor to support the weight of the spectrometer. Thermo Scientific Nicolet Summit User Guide...
  • Page 64 Replace the desiccant. See Replace the Desiccant for instructions. Because the internal optics are exposed to the atmosphere when removing the source, the desiccant should always be replaced after replacing the source. Thermo Scientific Nicolet Summit User Guide...
  • Page 65 Click Start and follow the on-screen prompts. Click Close when complete to return to the dashboard. b. Verify the instrument’s performance. In the Workflows pane, double-click Nicolet FTIR - Factory Qualification and follow the on-screen prompts. 6. Replace any accessories that you removed earlier. Thermo Scientific Nicolet Summit User Guide...

  • Page 66: Install The Touchscreen Monitor

    Press the power button to turn off the spectrometer and then unplug the power cord. b. Turn off the purge, if applicable, and disconnect the purge line to the instrument and any accessory. c. Remove any accessory from the sample compartment. Thermo Scientific Nicolet Summit User Guide...
  • Page 67 Guide the front bottom of the mount into the compartment and then rotate the mount past the sides of the compartment, as shown in Figure 3. Figure 6. Position the touchscreen mount over the three pre-drilled holes Thermo Scientific Nicolet Summit User Guide...
  • Page 68 The touchscreen monitor connects to the spectrometer with three cables: an HDMI cable, a USB cable, and the power cable. We recommend routing the cables in the sequence described below to ensure that the cover sits properly over the cables. Thermo Scientific Nicolet Summit User Guide...
  • Page 69 Figure 6. It may be easier to roll the cable into place rather than pushing it. Figure 9. Tuck the extra length of HDMI cable in front of the touchscreen mount Thermo Scientific Nicolet Summit User Guide...
  • Page 70 Figure 10. The three cables fit in the cable guides along the back of the spectrometer 1. HDMI cable 2. Heat sink fins Thermo Scientific Nicolet Summit User Guide...
  • Page 71 To turn on the touchscreen, press the power button on the rear side of the monitor. Congratulations. Your touchscreen monitor is installed and ready for use. With the touchscreen monitor installed, you can open OMNIC Paradigm software and switch to the touchscreen interface for a convenient, streamlined experience. Thermo Scientific Nicolet Summit User Guide...

  • Page 72: Replace The Sample Compartment Windows

    Replace the Sample Compartment Windows The Thermo Scientific™ Nicolet™ Summit FTIR Spectrometer has windows on both sides of the sample compartment that seal the instrument from moisture and other contaminants but allow the infrared beam to enter and exit the sample compartment. The windows should always be installed, even if your system is purged with dry air or nitrogen.
  • Page 73 (includes desiccant) and seal the package securely. • KBr windows are clear; ZnSe windows are yellow. Time needed: 10 minutes Tools needed: • Nicolet Summit ZnSe (or KBr) replacement windows kit The kit includes the following items: – ZnSe (or KBr) replacement windows (2) –...
  • Page 74 Line up the three ribs on the window replacement tool’s inside rim with the notches in the outside rim of the first installed window. Note The window fittings are tight. Use one hand to stabilize the instrument and the other to remove the window. Thermo Scientific Nicolet Summit User Guide...
  • Page 75 NOTICE The window should turn easily at the start; if it doesn’t, reverse the direction of rotation and restart the insertion to avoid stripping the threads. e. Continue rotating the tool clockwise until you feel the O-ring compress, plus 1/8 turn more. Thermo Scientific Nicolet Summit User Guide...
  • Page 76 (especially if you changed the window type). See the article titled “Qualify the Summit Spectrometer” in the online help for more information. 10. Replace any accessories you removed earlier on the spectrometer. Thermo Scientific Nicolet Summit User Guide...
