- Page 1 Nicolet FT-IR Spectrometer Safety Guide...
- Page 2 The information in this publication is provided for reference only. All information contained in this publication is believed to be correct and complete. Thermo Fisher Scientific shall not be liable for errors contained herein nor for incidental or consequential damages in connection with the furnishing, performance or use of this material.
-
Page 3: Table Of Contents
Contents Operating a Spectrometer Safely ............1 Conventions used in this manual .............. 1 Questions or concerns................2 General safety information ................ 2 Fire safety and burn hazards..............3 Environmental conditions..............5 Using liquid nitrogen................5 Cleaning the spectrometer..............6 Lifting or moving the spectrometer ............6 Biohazard or radioactive materials and infectious agents...... -
Page 5: Operating A Spectrometer Safely
Operating a Spectrometer Safely This safety guide contains a summary of the safety precautions that must be followed when using a Thermo Scientific Nicolet™ FT-IR spectrometer. Each person who will be using these instruments should read this manual. Safety information is also included in your spectrometer, accessory, computer, and software manuals. -
Page 6: Questions Or Concerns
National Certification Body, and a Notified Body for Europe that provides testing and certification services for the products. The ETL symbol indicates that the instrument has been inspected and approved by an independent testing laboratory. Nicolet FT-IR Spectrometer Safety Guide Thermo Fisher Scientific... -
Page 7: Fire Safety And Burn Hazards
Use only nitrogen or dried air to purge your spectrometer and accessories. • Do not touch the infrared source housing; it may be very hot. • Do not place anything on the electronics cover of a Nicolet 380 spectrometer. Thermo Fisher Scientific Nicolet FT-IR Spectrometer Safety Guide... - Page 8 Do not place anything on top of the electronics cover of a Nicolet 380 spectrometer. Electronic components under the cover can become overheated if items are placed on the cover. The following illustration shows the location of the spectrometer electronics cover. Nicolet FT-IR Spectrometer Safety Guide Thermo Fisher Scientific...
-
Page 9: Environmental Conditions
▲ Warning To avoid hazardous equipment damage or contact with liquid nitrogen, make sure any dewar or container you use to hold liquid nitrogen can do so safely without breaking. Thermo Fisher Scientific Nicolet FT-IR Spectrometer Safety Guide... -
Page 10: Cleaning The Spectrometer
Caution Nicolet FT-IR spectrometers cannot be lifted safely by a single person. Lifting or moving a Nicolet FT-IR spectrometer requires two people. Be sure to use the handholds on the sides of the spectrometer. -
Page 11: Biohazard Or Radioactive Materials And Infectious Agents
If you see this symbol on the spectrometer or on an accessory, be sure to read the safety label and check the information in the documentation that came with the instrument or accessory. The symbol indicates that there is additional information in the documentation. Thermo Fisher Scientific Nicolet FT-IR Spectrometer Safety Guide... -
Page 12: Electrical Safety
The table that follows shows the symbols and lists the meaning of each. Check the documentation that came with your spectrometer if you find a symbol that is not included in the table. Nicolet FT-IR Spectrometer Safety Guide Thermo Fisher Scientific... -
Page 13: Powering On
▲ Power switch (on external power supply) Nicolet 380 Nicolet 380 Power switch (on external power supply) Nexus 4700/5700/6700/8700 Nicolet 6700 and Nicolet 8700 Thermo Fisher Scientific Nicolet FT-IR Spectrometer Safety Guide... -
Page 14: Power Supplies
+ 5 VDC Not connected Fuses The Nicolet FT-IR spectrometers are protected by two 2 A, time-lag (also known as T-type or slow-blow) fuses that are built into the external power supply. The fuses for these spectrometers are not individually replaceable. If the fuses blow, you must replace the power supply. -
Page 15: Electrical Service
2 volts (common mode) less than 20 volts (normal mode) If you are not sure that your electrical service meets these requirements, contact technical support for information about a power line audit. Thermo Fisher Scientific Nicolet FT-IR Spectrometer Safety Guide... -
Page 16: Grounding
To prevent electrical hazards, do not remove or defeat the ground prong on the power cord, and do not use any cords that are frayed or damaged. If you use an extension cord, it also must have a protective conductor. Nicolet FT-IR Spectrometer Safety Guide Thermo Fisher Scientific... -
Page 17: Laser Safety
For these spectrometers, the accessible laser radiation in the sample compartment is very low, with less than 10 μW of continuous power. For Nicolet FT-IR spectrometers, less than 0.39 mW of laser light is accessible during normal use and maintenance. Class I laser products (FDA-CDRH and IEC 60825-1:2001) are inherently safe. -
Page 18: Laser Indicator
3.0 mrad spacing C/2L 1039 MHz operating voltage 1700 ± 100 VDC CDRH Class 3R classification * At output of laser head reduced with fixed neutral density filter to 150 μW. Nicolet FT-IR Spectrometer Safety Guide Thermo Fisher Scientific... -
Page 19: Corrosives, Solvents, And Pressurized Gases
The purge gas must be free of moisture, oil and other reactive materials. Use only clean, dried air or nitrogen to purge the instrument. Other gases, even inert gases such as argon (AR), can damage the spectrometer. Thermo Fisher Scientific Nicolet FT-IR Spectrometer Safety Guide... -
Page 20: Caustic Or Corrosive Agents
The pyrolysis of these solvents by an infrared source or by excessive heating halogenated caused by laser absorption may produce hydrochloric acid (HCl), hydrocarbons hydrofluoric acid (HF), phosgene (COCl ), or other hazardous compounds. Nicolet FT-IR Spectrometer Safety Guide Thermo Fisher Scientific... - Page 21 Damage due to pyrolysis of halogenated hydrocarbons and/or exposure to other corrosive or caustic agents is not covered by warranty. Thermo Fisher Scientific Nicolet FT-IR Spectrometer Safety Guide...
-
Page 22: Safety Labels
Nicolet 380 CAUTION Exposure to liquid nitrogen may cause skin burns. Hand and eye protection required. Top view Nicolet 380 with MCT detector Nicolet FT-IR Spectrometer Safety Guide Thermo Fisher Scientific... - Page 23 Serial Number 0000000000 Manufactured: 0000 Top view Nicolet 380 Inside view Nicolet 380 Thermo Fisher Scientific Nicolet FT-IR Spectrometer Safety Guide...
- Page 24 Rear view Nicolet 380 Nicolet FT-IR Spectrometer Safety Guide Thermo Fisher Scientific...
-
Page 25: Nicolet 6700 And Nicolet 8700
Nicolet 6700 and Nicolet 8700 Front view Nicolet 6700 and Nicolet 8700 Thermo Fisher Scientific Nicolet FT-IR Spectrometer Safety Guide... - Page 26 CLASS 1 LASER PRODUCT Front view Nicolet 6700 and Nicolet 8700 Inside view Nicolet 6700 and Nicolet 8700 Nicolet FT-IR Spectrometer Safety Guide Thermo Fisher Scientific...
- Page 27 Rear view Nicolet 6700 and Nicolet 8700 Thermo Fisher Scientific Nicolet FT-IR Spectrometer Safety Guide...
- Page 28 269-169601, Rev. A...
