Thermo Scientific XL2 User Manual

Table of Contents

Quick Links

Download this manual

Thermo Fisher Scientific Niton

Analyzers

XL2 Analyzer

Version 8.0.1

User's Guide (Abridged)

Refer to NITON XL2 Resource Guide for complete information

Revision A

March 2012

Table of Contents

Need help?

Do you have a question about the XL2 and is the answer not in the manual?

Questions and answers

Thierry Musanda

March 4, 2025

How to delete data?

1 comments:

Mr. Anderson

March 4, 2025

To delete all data on the Thermo Scientific Niton XL2 Analyzer, follow these steps:

1. Select the Erase All Data icon on the analyzer.
2. A confirmation screen will appear asking, "Are you sure?".
3. Choose "YES" to erase all data, including signatures and readings.
4. Choosing "NO" will return you to the Erase Menu.

Caution: Do not turn off the analyzer while data is being erased.

This answer is automatically generated

Ubaid ur Rehman aqubb

February 21, 2025

Working information required for trubble shooting

1 comments:

Mr. Anderson

February 21, 2025

The troubleshooting information for the Thermo Scientific Niton XL2 includes:

1. Measurement Window Replacement – Instructions for replacing the window bracket and inserting screws.
2. The Specs Screen – Provides details such as serial number, software, and firmware versions. This information should be reported to service if there is a problem.
3. Error Messages – The analyzer can auto-detect hardware issues and display error messages.
4. System Check – If a problem persists, users are advised to re-run the System Check and contact customer service if the issue continues.
5. Registration and Licensing FAQ – Information on regulatory requirements, including registration with local radiation control authorities.

For troubleshooting, checking the Specs Screen and running a System Check are recommended steps before contacting customer service.

This answer is automatically generated

Helen Friday

May 8, 2025

trying to test will do one get to 99% then freeze

Summary of Contents for Thermo Scientific XL2

Page 1 Thermo Fisher Scientific Niton Analyzers XL2 Analyzer Version 8.0.1 User’s Guide (Abridged) Refer to NITON XL2 Resource Guide for complete information Revision A March 2012...
Page 4 Thermo Fisher Scientific Inc. provides this document to its customers with a product purchase to use in the product operation. This document is copyright protected and any reproduction of the whole or any part of this document is strictly prohibited, except with the written authorization of Thermo Fisher Scientific Inc. The contents of this document are subject to change without notice.
Page 5: Table Of Contents
Downloading Data ..........116 Thermo Scientific...
Page 6: Table Of Contents
Tips and Troubleshooting ........132 Storing and Transporting Your Niton XL2 Analyzer ....139 Chapter 8 Advanced Settings .
Page 7: Chapter 0 Contact Us
Contact Us Americas Europe Asia niton.eur@thermofisher.com niton@thermofisher.com niton.asia@thermofisher.com NitonEurope.support@thermofisher.com NitonAsia.Support@thermofisher.com...
Page 8 Contact Us Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 9: Chapter 1 Manual Overview
Figures Figures are illustrations used to show what something looks like. Figures will always be labelled and identified as Figures directly below the Figure itself, and will always be visually presented as follows: Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 10: Physical Buttons
Other Hardware refers to any physical part of the analyzer which performs a necessary function. Other Hardware will always be visually presented as follows: This is an example of Other Hardware. Example Other Hardware: Battery, Touch Screen Display, Measurement Window, and USB Cable Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 11: Chapter 2 Using Your Analyzer
Radiation and General Safety This section covers topics related to radiation safety and general safety when using a Thermo Scientific Niton XL2 analyzer. At a minimum all operators of the analyzer should be familiar with the instructions provided in this chapter in order to handle the analyzer in a safe manner.
Page 12 (i.e., skin) dose or dose to extremities. Deep, shallow, and extremity exposure from a properly used Niton XL2 analyzer should be less than 200 mrem per year, (2.0 mSv per year) even if the analyzer is used as much as 2,000 hours per year, with the shutter open continuously.
Page 13 Shown in Table 1 are the typical background radiation doses received by the average member of the public. The radiation dose limits for radiation workers in the US are also shown in Table Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 14 5000 Pregnant Worker (during gestation period) Eye Dose Equivalent 15,000 Shallow dose equivalent to the skin or 50,000 any extremity or organ Maximum allowable dose for the general public (annual) For a Minor Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 15 * The International Commission on Radiological Protection, ICRP, is an independent Registered Charity, established to advance for the public benefit the science of radiological protection, in particular by providing recommendations and guidance on all aspects of protection against ionizing radiation. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 16 Measurements. How to Use the Niton XL2 Analyzer Safely The Niton XL2 analyzer is designed to be safe to operate provided that it is used in accordance with manufacturer's instructions. Under conditions of normal use, monitored operators seldom receive a measurable dose and have not been known to receive in excess of 10% of the annual occupational dose limits (a criteria that would require monitoring under regulation in the U.S.).
Page 17 Secondary (Scattered) Beam The Shutter-Open Indicator Lights When the lights are flashing, the primary beam is on, and radiation is being emitted from the front of the analyzer. Figure 3. The X-ray Beam Indicator Lights Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 18 An example of such a program can be found on the resource CD (provided with the instrument). Take Proper Care of your Niton XL2 Keeping your analyzer maintained in good condition will help minimize the risk of accidental exposure. Mechanical malfunction of the shutter can be avoided by maintaining the measurement window, as described in the User Guide.
Page 19 This causes higher dose rates in the scattered radiation. If you are frequently handling low density samples, you should consider the use of test stands, backscatter shields, or the equivalent. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 20 Cal Due: 10/10/2009 Background Radiation Level <0.01 mr/hr Table 4 - Scatter Measurements off various substrates - Dose Rates in mRem/hr Table 4. Niton XL2 Radiation Profile - Scatter Measurements - mRem/hr Range Substrate Max @ 5cm Max @ 30 cm...
Page 21 Using Your Analyzer Safely and Effectively Using Your Analyzer Table 5 - Scatter Measurements off various substrates - Dose Rates in Sv/hr µ Table 5. Niton XL2 Radiation Profile - Scatter Measurements - Sv/hr µ Range Substrate Max @ 5cm...
Page 22 Using Your Analyzer Safely and Effectively Using Your Analyzer Table 6 - In Beam Measurements - Dose Rates in Rem/hr Table 6. Niton XL2 Radiation Profile - In Beam Measurements - Rem/hr Range Contact Deep Contact Shallow 5cm Deep 30cm Deep 0.088...
Page 23 Plastic 44.4 Main Soil <0.01 <0.01 Table 9 - Niton XL2 GOLDD Radiation Profile - Scatter Measurements - µSv/hr Table 9. Niton XL2 GOLDD Radiation Profile - Scatter Measurements - µSv/hr Range Substrate Max @ 5cm Max @ 30 cm...
Page 24 Using Your Analyzer Safely and Effectively Using Your Analyzer Table 10 - Niton XL2 GOLDD Radiation Profile - In Beam Measurements - Rem/hr Table 10. Niton XL2 GOLDD Radiation Profile - In Beam Measurements - Rem/hr Range Contact Deep Contact Shallow...
Page 25 Using Your Analyzer Safely and Effectively Using Your Analyzer Figure 4. Primary and Secondary Dose Locations (Not to Scale) Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 26 Caution should be taken when analyzing samples that are small, thin, and/or low in atomic mass or density as they may allow much more of the primary beam to escape. In-beam primary radiation dose rates for the Niton XL2 are listed in...
Page 27: Proper And Improper Operation
Note THIS PAGE CONTAINS EMERGENCY CONTACT INFORMATION THAT SHOULD BE AVAILABLE TO THE OPERATOR AT ALL TIMES. If the Niton XL2 analyzer is lost or stolen, notify your Radiation Safety Officer (RSO) or the equivalent responsible individual at your company or institution immediately. Your company's RSO, as well as other important emergency contacts, are listed below.
Page 28 1. Perform the same steps as described above for minor damage. There will be no radiation hazard as long as the battery is removed from the instrument. 2. Place all components in a plastic bag and contact Thermo Fisher Scientific. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 29 Outside the USA - Local Niton Service Center:___________________ Europe Niton Analyzers Europe Munich, Germany Phone: +49 89 3681 380 Fax: +49 89 3681 3830 Email: niton.eur@thermofisher.com Asia Niton Analyzers Asia Hong Kong Phone: +852 2869-6669 Fax: +852 2869-6665 Email: niton.asia@thermofisher.com Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 30 Proper and Improper Operation Registration and Licensing As a user of a Niton XL2 analyzer, you may be required to register or obtain a license with your local radiation control authority. In the US, if you intend to do work with your analyzer in states other than your own, you may be required to register there as well.
Page 31: Chapter 3 How To Analyze
To analyze samples, from the main menu select sample type, and then click on the appropriate Mode icon. Once in the Selection Screen you have a number of sub-modes to select from. depending on how your instrument is calibrated. See the Example Path below. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 32: General Analysis
The Element Range Screen General Analysis Note Each user should read the Thermo Scientific Niton XL2 User’s Guide carefully before initiating measurements with the system. Users are strongly urged to attend the Thermo Scientific Niton XRF Analyzer Radiation Safety and Operations Training courses offered regularly, or the web-based trainings.
Page 33 If the unit shows a failure error, then perform a second System Check by clicking Recheck. If the unit still does not show a “System OK,” please contact Thermo Scientific Niton Analyzers toll-free in the USA at (800) 875-1578, +1 978 670-7460, niton@thermofisher.com, or contact your local Niton Analyzers representative for assistance.
Page 34 Figure 7. System Check Menu Path Thermo Scientific Niton XL2 analyzers are equipped with excitation filters that optimize the analyzers’ sensitivity for various elements. The “Main Range” filter provides optimum sensitivity for the elements manganese (Mn) through bismuth (Bi). The “Low Range” filter is used to optimize the sensitivity for the elements from titanium (Ti) through chromium (Cr).
Page 35 For example: a rod only covers ½ of the aperture, so increase the measurement time by two (e.g., from 10 to 20 seconds per filter for alloy chemistry). The best procedure to measure undersized samples is to use the Thermo Scientific Niton portable test stand (optional), which is shielded to prevent radiation exposure to the operator.
Page 36 How to Analyze General Analysis Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 37: Chapter 4 Basic Operation
Basic Operation Taking a Sample Analysis Basic Operation Taking a Sample Analysis 1. Clean the sample to be analyzed so it is free of all surface contamination. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 38 Basic Operation Taking a Sample Analysis 2. Place the analyzer so the sample is covered by the analysis window. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 39 Basic Operation Taking a Sample Analysis 3. Select the Sample Type Icon. 4. Select the proper Mode (in this case Mining Cu/Zn) from the Mode Menu. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 40 Basic Operation Taking a Sample Analysis Note See “Analysis Modes” on page 37. for more information on the Modes available. 5. Select the Analyze Icon. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 41 Basic Operation Taking a Sample Analysis 5a. Select Data Entryif you wish todo any data entry. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 42 Basic Operation Taking a Sample Analysis 5b and 5c. Enter the data on the sample using the Virtual Keyboard. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 43 Basic Operation Taking a Sample Analysis 6. Initiate a Reading by pressing the trigger. 7. When the sample has been sufficiently analyzed, release the trigger. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 44 Basic Operation Taking a Sample Analysis 8. View the composition returned. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 45: Analysis Modes
Alloy Grade Library. It will also return an elemental composition of the alloy as analyzed. Alloy Composition is output by default in terms of percent of composition by weight. See “Using General Metals Mode” on page 39. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 46 - and containing Cu and/or Zn. This mode will return an elemental composition of the ore sample as analyzed. Ore Composition is output by default in terms of percent of composition by weight. See “Using Mining Cu/Zn Mode” on page 43. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 47 1. Clean the sample to be analyzed so it is free of all surface contamination, grinding the surface if appropriate. 2. Place the analyzer so that the sample covers the analysis window. 3. Select the Mode icon. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 48 1. Clean the sample to be analyzed so it is free of all surface contamination. 2. Place the analyzer so that the sample covers the analysis window. 3. Select the Mode icon. a. Select Precious Metals from the Mode Menu. 4. Select the Analyze icon. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 49 Enter the data on the sample using the Virtual Keyboard. 5. Initiate the analysis. 6. When the sample has been sufficiently analyzed, stop the analysis. 7. View the composition returned. 8. Remove the sample. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 50 Enter the data on the sample using the Virtual Keyboard. 5. Initiate the analysis. 6. When the sample has been sufficiently analyzed, stop the analysis. 7. View the composition returned. 8. Remove the sample. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 51 Enter the data on the sample using the Virtual Keyboard. 5. Initiate the analysis. 6. When the sample has been sufficiently analyzed, stop the analysis. 7. View the composition returned. 8. Remove the sample. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 52 6. When the sample has been sufficiently analyzed, stop the analysis. 7. View the composition returned. 8. Remove the sample. Using TestAll Geo Mode 1. Clean the sample to be analyzed so it is free of all surface contamination. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 53 Enter the data on the sample using the Virtual Keyboard. 5. Initiate the analysis. 6. When the sample has been sufficiently analyzed, stop the analysis. 7. View the composition returned. 8. Remove the sample. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 54 Basic Operation Analysis Modes Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 55: Chapter 5 Common Operations
• Diamond paper - P/N 179-1202- cut into 1 inch/2.5 cm squares. Never re-use this paper, as it may transfer contaminants to the surface of the sample from previous cleanings. Depending on the state of the sample, several squares may be needed per sample. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 56 Table 1. Comparative test results with and without grinding Sample % Mn % Ni % Cr % Mo % Cu Reported Chemistry 0.650 0.090 0.070 0.030 0.040 Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 57 The sample had painted markings, of light to medium thickness, on the surface, as well as light rust. Note the change in titanium, zinc and cobalt levels after surface grinding. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 58 If a sample's surface contains lubricants or cutting oil, use a solvent and a clean towel or rag to remove them before analysis. You may then need to grind the surface to insure good results. Clean first, grind second, test last. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 59 A kit with the drill, batteries and charging units, can be purchased from ThermoFisher, or companies such as DeWalt, Hitachi, Makita, Milwaukee or Ryobi. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 60 There are three types of connections: metal snap-on, plastic twist and plastic snap-on. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 61 Next, attach the appropriate sanding disc. The method of attachment will vary depending upon the type of fastener on the sanding disc (snap-on or twist connectors). Reinstall the battery and prepare for use. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 62 Common Operations Metal Sample Prep Figure 3. Attaching the Sanding Disc 1 Figure 4. Attaching the Sanding Disc 2 Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 63 Grinding stones are not to be used for XRF sample preparation. A rubber backup pad and a retaining nut are needed to use with sanding discs. (See picture below). Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 64 In the US, sanding discs are 4.5 inch diameter and can be purchased in various grit sizes of 36 to 120. The surface abrasive can be one of the following materials: aluminum oxide, silicon carbide or zirconia alumina. The selection of sanding discs is covered in the next section. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 65 Aluminum from the aluminum oxide disc imbeds itself in the surface of the steel sample and an XRF would show an unusually high aluminum concentration. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 66 When using a grinder, follow these safety rules: • When changing sanding discs, always remove the grinder battery to prevent accidental activation of the grinder. • Allow the grinder to stop spinning before placing it on a flat surface. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 67 • Use proper techniques and safety precautions when grinding beryllium, beryllium copper, lead, or titanium alloys. • Always follow the safety instructions outlined by the grinder's manufacture as mentioned in the instruction manual.. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 68: Soil Sample Prep
Call the Thermo Sales Department at 1-800-875-1578 for replacement blades. Note Using the soil grinder may artificially increase the amount of Fe in soil samples. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 69: Sample Preparation
(e.g. Thermo NITON Part Number 187-466). Thermo recommends using a 1/4 mil Polypropylene film (e.g. Thermo NITON Part Number 187-461). A supply of cups and films are included. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 70 Set the cup on a flat surface film-window-side down. Fill it with at least five grams of the prepared sample, making sure that no voids or uneven layers. TAMP SAMPLE Lightly tamp the sample into the cup. The end of the pestle makes a convenient tamper. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 71 Place a label on teh cup. Using a pen with indelible ink, write identifying information on the cup. Keep a record of the sample designation, the site and location, the date of the sample, and any other relevant comments. Cup is ready for testing. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 72: Preparing Mining Samples
About 4-6 g of dry pulverized sample is calcinated in an alumina or platinum crucible in a muffle furnace at 1000°C for 1 hour. b. The sample is cooled in a dedicator and loss on ignition (LOD) is calculated from weight difference before and after Calcination. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 73: Setting Up Beep Times
Second Beep. The Beep Two Time editor will open. Clear the current number of seconds with the "C" button, then select the E button to enter the information. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 74: Sorting The Custom Element Display
Select the Save Button to save your current status as the new default. Select the Reset button to reset the settings to the previously saved state. Select the Close button to exit the screen without saving. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 75: Max Measure Time
Detection Option only. Select the Minimum Test Time field, and a Virtual Numeric Keypad will pop up, allowing you to input a new Minimum Test Time in seconds. The default Minimum Test Time is set to 60 seconds. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 76: Virtual Keyboard
Generally, selecting the keys on the Virtual Keyboard will type the corresponding character into the field. The exceptions are the meta-keys Del, Clear, Left, Right, Shift, Backspace, Cancel, and Enter. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 77 Shift is the Shift Key. Selecting this key will bring up the alternate, shifted keyboard. See Figure 1-1B. Selecting the Shift Key on the shifted keyboard will bring up the normal keyboard. See Figure 1-1A. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 78 Enter Enter is the Enter Key. Selecting this key will return you to the normal screen, replacing the former contents of the field with the changes you have made. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 79: Setting Display Units
That's why it's important to use the most appropriate sigma value for the test. By adjusting the sigma value for each type of test, you can optimize the process for your needs. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 80 Figure 10. Selecting the Sigma Value When you have changed the sigma values to the appropriate number, select the Close button to save these settings for use. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 81: Adjusting The Element Range
Ranges contained in your Analyzer is used for sample testing. Selecting an empty checkbox will enable that range and place a check into the box as an indicator. Selecting a checked box will disable the Range and clear the box. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 82: Setting The Date And Time
The date and time are factory preset prior to shipping. The clock is a 24 hour clock, so add 12 to PM hours - i.e. 1:13 PM would be 13:13. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 83 When the Date & Time button is selected, the Date & Time Screen comes up on your analyzer’s LCD Screen. You may change the Month, Year, Date, Hour, and Minute on your analyzer. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 84 Figure 14. Month Drop Down Menu Select the month you want from the drop down menu, using the vertical slider button to display hidden months. The display will change to show the month you selected. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 85 Figure 15. Changing the Year Select the year you want from the drop down menu, using the vertical slider button to display hidden years. The display will change to show the year you selected. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 86 To change the date, select the date you want from the Date Selection Screen. The date you selected will be highlighted in red, while the old date will be shown in red numbers. Figure 16. Selecting the Date Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 87 To change the minute, select the minute numbers. The minute numbers will be highlighted in gray. Then select the Upwards Pointing Chevron Button to increment (increase) the minute, or the Downward Pointing Chevron Button to decrement (decrease) the minute. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 88 Date and Time will be saved. Exiting Without Saving To exit the screen without saving changes, select the "Cancel" Screen Button. The display will return to the previous screen and the Date and Time will not be saved. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 89: Calibrating The Touch Screen
7. Tap on the cross once more, and you will be presented with a Confirmation Screen. 8. Select the Yes Button to confirm that the parameters are good. Select the No Button to start the process again. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 90 Figure 20. Touch Screen Calibration Crosses The Touch Screen can be calibrated - and the system operated - with a USB mouse plugged into the USB ports in the rear of teh analyzer. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 91: Chapter 6 Data Management
Figure 21. The View Data Menu Path Use the Data Screen to view previously taken test result readings. When the View Data icon is selected, the Results screen of your most recent test is shown on the Touch Screen. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 92 Selecting the appropriate Sort Button once toggles the sort order to High-to-Low. Selecting the Sort Button again toggles the sort order to Low-to-High. To return to the Standard Sort, select the Sort Button a third time. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 93 Error Sorts Error sorts are performed based on the size of the error in the reading, i.e. from largest to smallest error, or by toggling again, from smallest to largest. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 94 For any reading result, simply use the NAV Menu to gain access to the reading’s spectrum graph. Selecting Spectra will show a graphed spectrum of this reading, called SpectraView. SpectraView can be a useful tool for rapid, qualitative analysis of a sample. See Viewing the Spectrum for details. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 95 • The position of the cursor on the energy scale (Bottom Left, under the Reading number), in the form "E: x.xx KeV", where KeV is kilo electron volts. • The count rate (Bottom Left, under the energy position), in the form “R:x.xx”. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 96 Figure 28. Delineating the Area of Interest Select the FIT button in the upper right hand corner of the Spectrum to fit the area of interest to the display area. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 97 Use the left button on the 4-way touch pad to expand the spectrum, centered on the position of the cursor. Use the right button on the 4-way touch pad to contract the spectrum, centered on the position of the cursor. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 98: Viewing Fingerprints
Select the View Fingerprints icon to view data saved as reference sample Fingerprints in Teach Fingerprint Mode. When the View Fingerprints icon is selected, the Results Screen of your most recent Teach Fingerprint is shown on the Touch Screen display. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 99: Erasing Data
Data Management Erasing Data Figure 31. The View Fingerprints Screen Erasing Data The Erase All Data Screen Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 100 CAUTION Never turn off the analyzer while data is being erased! WARNING Do not attempt to take measurements while downloading readings! This will generate an error requiring a system reset, and may corrupt your stored readings, requiring all stored readings to be erased. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 101 Selecting the Erase Readings icon will bring up a confirmation screen asking you “Are you sure?” with options to select “YES” or “NO”. Selecting the Yes Button will erase all test reading data from your analyzer. Selecting the No Button will return you to the Erase Menu. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 102 Data Management Erasing Data Figure 35. The Erase Readings Confirmation Screen Note - We recommend that you download all your readings into an NDT file for recording purposes before erasing all data. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 103 “Are you sure?” with options to select “YES” or “NO”. Selecting the Yes Button will erase all fingerprint data from your analyzer. Selecting the No Button will return you to the Erase Menu. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 104: Managing Libraries
Management Menu allows you to view and modify data in the Primary Library as well as the currently loaded alternate libraries. Just select the library you wish to view or editfrom the list on screen. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 105 The entries in the Grade Library serve as a reference for chemistry based analysis. The library entries allow the analyzer to work properly “out of the box” without needing time-consuming pre-analysis. Figure 40. The Library Editor Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 106 Element Specification Screen and enter the specification of the alloy. Del Button Selecting the Del Button will delete the currently selected alloy. First a confirmation screen appears. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 107 Selecting the Save button will save the current Library. Close Button Selecting the Close button will close the current Library without saving it. The Element Specification Screen The Element Specification Screen allows you to edit the elemental content of any alloy. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 108 This is the lowest amount of the element in question you want to be in the alloy. If the element in the analyzed sample is any lower, the sample will not be recognized as this alloy. Selecting the element minimum will open the Minimum Editor. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 109 This is the highest amount of the element in question you want to be in the alloy. If the element in the analyzed sample is any higher, the sample will not be recognized as this alloy. Selecting the element maximum will open the Maximum Editor. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 110 After selecting the E Button, you will be returned to the Element Specification Screen. OK Button Selecting the OK button will save the edited library. Cancel Button Selecting the Cancel button will exit the Element Specification Screen for this alloy, returning you to the Library Editor. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 111: Chapter 7 Connectivity
Installing the Windows 7 USB Driver 1. Insert the NDT CD and close out any dialogue box that pops up. The driver is located on this disk. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 112 Connectivity 2. Click on “Control Panel” and locate the “Device Manager”. If it is not available directly under “Control Panel”, look under “System and Security” then “System”. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 113 4. Plug in instrument using the USB cable provided 5. Message will appear “Device Driver Software Not Successfully Installed” 6. In “Device Manager”, “Unknown Device” will appear under “Other Devices” 7. Right click on “Unknown Devices”; select “Update Driver Software” Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 114 Connectivity 8. Click on “Browse My Computer for Driver Software” Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 115 Connectivity 9. Click “Browse” button; select CD drive or the location of the driver if you are not installing from the NDT CD (recommended). 10. Click “OK” 11. Click “Next” Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 116 Connectivity 12. A Security Dialog Box will appear. Select “Install This Driver Software Anyway?” 13. Driver will install; close out. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 117: Using Your Analyzer With Your Pc
The USB adapter provided by Niton uses Bluetooth wireless technology. See Setting up Bluetooth to set up Bluetooth. Select the Bluetooth icon from the System Screen to set up your analyzer for Bluetooth wireless connection. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 118 Information Screen. The Bluetooth Information Screen will supply the current name as well as the MAC address of your analyzer Search Button Selecting the Search Button will initiate a search for currently available Bluetooth devices in the area. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 119: Connecting From Your Analyzer To Your Pc
Select the Connect Button. Your analyzer's screen will show connection progress. Figure 49. Connecting Via Bluetooth Open the program you are attempting to connect to. Here we are connected to NDTr, running the analyzer remotely over COM 5 Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 120 Select a located Bluetooth device from the Search List, then select the Connect Button to connect to that device. GPS Button Select the GPS Button to download GPS data from a connected GPS Device. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 121: Reset Button
Connectivity Connecting From Your Analyzer to Your PC Figure 51. Bluetooth GPS Data Screen Reset Button Selecting the Reset Button initiates a Bluetooth reset. Config Button Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 122: Using A Usb Cable To Connect Your Analyzer
Select the close button to exit from Bluetooth setup. Using a USB Cable to Connect Your Analyzer To connect the XL2 XRF Analyzer to your PC using the USB cable: 1. Insert the Standard USB connector on the USB cable into a USB port on your computer.
Page 123 XRF Analyzer. 4. Upon initial installation, insert the NDT disk located behind the foam in your case. Follow the prompts and install the USB driver located on the disk. Figure 55. Mini USB Connector Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 124: Downloading Data
4. Click the Download button. The Download dialog box will open. Figure 56. The Download Button 5. In the Download dialog box, Select the Test button to test the serial connection to the Analyzer. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 125 Figure 59. The Connect Button 8. Click the Query Readings button. This will return a list of all current readings on your analyzer. The list appears in the large white box in the Download dialog box. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 126 Click the boxes on the left to select or de-select all the readings of a specific type. You can also use the Shift-Click method of selecting a range of readings as described above. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 127 CAUTION Some characters are not allowed in the file name. Characters such as the "#" sign will cause an error. Niton recommends using only alphanumeric characters "-", "_" and the space character when naming a file. e. Click the Download button. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 128 Connectivity Downloading Data Figure 64. The Download Button When the progress bar shows that all the readings are downloaded, click the Done button. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 129 Reading will be skipped. instrument code and the NDT code running on your Error code: computer. Use a version of NDT that matches the BOUNDARY_ERROR2. ver?sion number of the software on your analyzer. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 130 Live Download (Automatic Save) If desired, your Niton XL2 analyzer has the capability to download and store each reading to the PC in real time to a file of your choice. To enable this feature, you must do the following: •...
Page 131 By clicking on the checkbox box labeled "Save the readings to CSV file as well" you can enable simultaneously saving the data as a standard CSV (Comma Separated Value) file for use with other programs. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 132 Connectivity Downloading Data Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 133: Chapter 7 Controlling Your Analyzer From Your Pc
Clicking this icon will halt any ongoing measurement on the analyzer. Configure Connection Settings Clicking this icon will allow you to change your configuration settings. Connect Clicking this icon will attempt to establish a connection between your computer and your analyzer. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 134 Selecting the down arrow in the "Connect Using" field will display the various Com Ports on the computer that the analyzer can connect through. Figure 70. Selecting the Com Port Select the proper com port from the list, then select the OK Button. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 135 NDTr version 7 and above will automatically select the proper virtual interface for you, whether you have a Thermo Scientific Niton XL2 or XL3. The virtual interface operates exactly as the analyzer would. Selecting the buttons, icons and menus with your mouse works exactly as if you were selecting them with your finger or stylus on the real analyzer.
Page 136 Deselecting this checkbox will save the file under the same name in the same folder every time. The checkbox is selected when there is a check in it, and deselected when it is empty. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 137: Chapter 8 Learning More, Service, And Support
Learning More, Service, and Support This section of the Resource guide is about getting the most out of your analyzer. We cover troubleshooting your analyzer by using the Specs screen. We also cover advanced topics like setting thresholds, using the Tools menu, correcting for light elements in the sample composition, setting up pass/fail analysis, changing safety and start/stop parameters, and many other special situations you may need.
Page 138 Removing the Old Window • Measurement Windows come in two types - Prolene (P.N 187-1454) for 900 Series analyzers, and Polypropylene (P/N 187-1555) for all other analyzers. Figure 3. Polyethylene Window P/N 187-1555 Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 139 Do not use fingers to press window into place! Use a smooth, hard surface such as back of tweezers. Figure 6. Measurement Window Replaced • Replace Window Bracket on the front of your analyzer, then insert screws. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 140: Tips And Troubleshooting
Press the Close Screen Button to return to the previous menu. Press the ">-" Screen Button to go to the Diagnostic Menu, and press the "<-" Screen Button to return to the Specifications Screen. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 141 This is the current Date and Time. This is particularly important for date stamping. SW Version This is the currently loaded software version, which should be reported to Service if there is any problem. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 142 C = Clear All, E = Enter, and OFF shuts off the Reminder Function. Selecting the E button will enter the current value as the reminder interval and return to the Specs Screen. Figure 9. Cal Reminder Editor Screen Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 143 Detector Temperature should be within this range: - 25 + or - 5 degrees Bias: Bias should be within this range: 175 + or - 10 VCool: VCool will vary with the ambient temperature. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 144 SubBias should be within this range: -11 + or - 3 Escale: Escale should be within this range: 6.6 through 9.0 Preamp: Preamp value should only be noted, and reported to Service if there is a problem. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 145: Error Messages
The analyzer will auto-detect many perceived hardware problems and may display the following error messages: Figure 11. The Specs Screen Menu Path Please re-run the System Check and if the problem persists, contact customer service. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 146 Tips and Troubleshooting Registration and Licensing FAQ As a user of a Niton XL2 analyzer, you may be required to register or obtain a license with your local radiation control authority. In the US, if you intend to do work with your analyzer in states other than your own, you may be required to register there as well.
Page 147: Storing And Transporting Your Niton Xl2 Analyzer
Q: What is the type of X-Ray Processing? A: None. Niton XL2 analyzers do not use film. Q: How often do I need to perform leak tests on the Niton XL2? A: Never. Leak tests are only required for analyzers with radioactive isotopes. Niton XL2 analyzers do not have radioactive isotopes.
Page 148 Learning More, Service, and Support Storing and Transporting Your Niton XL2 Analyzer Figure 12. The Niton Carrying Case All padlocks are shipped with a default combination of “0-0-0”. If you change this combination, please inform Thermo of the new combination if you return the unit for service.
Page 149 Learning More, Service, and Support Storing and Transporting Your Niton XL2 Analyzer CAUTION In most cases, no notification is required if transporting within state boundaries. This may not be the case when entering federal properties. CAUTION Within the United States, always keep a copy of the US DOT compliance statement in your Niton analyzer case at all times.
Page 150 Learning More, Service, and Support Storing and Transporting Your Niton XL2 Analyzer Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 151: Chapter 8 Advanced Settings
Advanced Settings Adjusting the Element Range Figure 1. The Range Menu Path (Main) Multi-Range tests are used to either preferentially excite specific elements for increased sensitivity, or to cover a wider element range than one Range alone can provide. Most modes, when enabled, will use two Ranges in sequence to produce a combined analysis result.
Page 152 Select the mode you wish to configure. You can set different configurations for different modes. The Element Range Screen enables you to directly enable or disable any Range, or control the time that a Range alters the irradiation of the sample before auto-switching to another Range. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 153 In typical alloy analysis applications, Main Range is used for the analysis of most elements. You cannot deselect the Main Range in alloy analysis Low Range is utilized for the subsequent high sensitivity analysis of V, Ti, and Cr. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 154 Advanced Settings Figure 4. The Range Element Lists Select the Element List Button to display the Element List for that Range. This list shows the elements that the Range is best designed to detect. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 155 Your analyzer will auto-switch from one range to another when the testing time for that range is greater than or equal to the time you have chosen, and the identified alloy is flagged as needing the switch in the Niton Alloy Library. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 156 The Range Time Editor Select the C button to clear the current time, then from the virtual numeric key pad, select each digit you want to input, then select the E button to enter. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 157: Tools Menu Options
Select the digits in the range number from the keypad, then select the E button to enter the number. The C button will clear all, and the “<“ button will clear the last digit entered. The average will automatically be displayed. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 158 Tools Menu Options Figure 7. Example Averaging Screens Avg Back (Alt) Note The alternate Tools Menu is only available when viewing readings, and the menu is only accessible through the touch screen interface or NDTr. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 159 Activating and Deactivating the Live Spectrum From the Tools Menu, select the Spectra:On button to turn the Spectrum feed on. Once the spectrum is displayed, selecting Spectra:Off from the Tools Menu will stop the live spectrum display. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 160 PASS result is given, otherwise a FAIL result is returned. To turn on Pass/Fail, select the Tools Menu and select Set Pass/Fail from the menu. The Pass/Fail Setup Screen will come up. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 161 Select the Fail button to initiate Fail Mode. Use Fail Single Mode when you have an undesirable match. If the alloy being analyzed matches one of the alloys in the selected list, the alloy will Fail the analysis. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 162 Figure 11. . The Pass Fail Setup Screen Searching for Reference Alloys Select the Search button to search the library for the alloy you want as your Reference Alloy. Figure 12. Using the Search Function Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 163 When the sample analysis reaches a match with the chemistry of any one of the alloys on the Selected list, a PASS or FAIL notice is generated as appropriate. Figure 14. Metals Pass and Fail Screens Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 164 [mm] before the measurement is initiated. The thickness may be entered with precision to the second decimal place, although in practice only one decimal place is sufficient for effective correction. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 165 Advanced Settings Tools Menu Options Figure 15. How to Enable and Adjust Thickness Correction for Plastics Analysis Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 166 Thin Sample Mode. (Contact Contact Thermo Scientific or your local Niton Analyzers representative for information on this testing mode.) Whenever possible, one should analyze as thick a sample as available.
Page 167 Figure 40. Figure 18. . Incorrect Way to Measure Heat Shrink Tubing Figure 19. . Correct Way to Measure Heat Shrink Tubing WARNING Thickness correction is only for use with plastic/polymer samples. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 168 Selecting the Print Data option from the Tools Menu will print the currently displayed data to the optional attached printer. See Setting Up the Printer for details. Coatings Method Metals are sometimes coated with various materials. If you wish to analyze the coating, select the Coatings Method. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 169 You can check the version number by opening NDT, selecting the Help menu, then selecting “About Niton Data Transfer” Figure 20. . Selecting Help Select the File menu Figure 21. Selecting File Select “New” then “New Password File”. Your screen should look like this: Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 170 Advanced Settings Tools Menu Options Figure 22. Creating the Security Key Create a unique security key, then select the OK Button Figure 23. Security Key Your screen should look like this: Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 171 Advanced Settings Tools Menu Options Figure 24. User Account Creation Screen Right click, then select “New User” Figure 25. User Creation Dialog Box Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 172 Selecting the Check All check box will result in enabling all features. Figure 26. . Creating a User WARNING it is recommended that only users at the highest level have access to the “Safety” feature. This should be unchecked for all other operators. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 173 Advanced Settings Tools Menu Options Figure 27. Unchecking Safety Select the Update Button Figure 28. User is Created a. You are now ready to upload your password file to the analyzer. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 174 Advanced Settings Tools Menu Options Be sure the analyzer is switched on; connect the analyzer using USB or serial connection. Select the Upload icon. Figure 29. Selecting Upload Your screen should look like this: Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 175 Select the Connect Button, then the Upload Button. Upon completion, you will receive a “File Upload Successfully Completed” message. Click the OK Button; save your password file at this time by selecting the File icon then “Save As. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 176 Advanced Settings Tools Menu Options Figure 31. Successful Installation Message Restart your analyzer; your password file should be successfully installed. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 177: Ndf Files: User Data Structuring
Figure 32. Creating a New NDF File This will create a new window in which you can create your own fields, and specify their structure and parameters. The new window will appear with a single box, called “Untitled.” Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 178 Modes enabled on your analyzer, the new fields will only be available from the Mode you select. Only the default fields will be available from the other Mode or Modes. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 179 Figure 36. Working within a Mode The “M” indicates the mode you have chosen - in this case Alloy Mode. Right click on the Mode name to access a pop-up menu. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 180 Selecting Required makes it mandatory that the new field be filled in prior to taking a measurement. This is very useful for necessary descriptors which vary from measurement to measurement, such as lot numbers, condi tion descriptors, locations, etc. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 181 For example: P/N 455A2-1, P/N 455A2-2, P/N 455A2-3. Another Example: Impeller-1, Impeller-2, Impeller-3. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 182 - which may be changed by the user - without incrementing it, but does not require the user to input any data if there is none already there from a previous reading. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 183 Selecting Edit from the pop-up menu allows you to edit the name of the field in the Editing Window to the right of the Construction Window. Figure 44. Editing the Field Name Selecting the box to the left of the field toggles the Required option on or off. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 184 Advanced Settings NDF Files: User Data Structuring Figure 45. Toggling the Required Option Selecting Copy from the pop-up window allows you to copy the currently selected field. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 185 Once you copy a field, the Paste option can be selected to paste the copied field into the Construction Window. Figure 47. Pasting a Copied Field Selecting the New Entry option from the pop-up menu allows you to define a choice for the user for this field. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 186 Right click on the entry name, and choose Edit from the pop-up menu. Figure 50. Editing the New Entry You can sort your entries by name, alphanumerically, by right clicking on the field and selecting “Sort” from the pop-up menu. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 187 When you are finished creating your new NDF file, Upload it to your instrument using the Upload icon. Figure 53. Uploading the NDF File Make sure the instrument is connected to your computer by testing the con nection first. Use the Test button on the Upload Window. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 188 Advanced Settings NDF Files: User Data Structuring Figure 54. Testing the Upload Connection Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 189: Safety Settings
Access to the Safety Settings Screen is blocked unless the user logging in has explicitly been granted Safety access. The default login of 1234 does not have Safety access. See Passwords and User Privileges. Figure 55. . Safety Settings Menu Path Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 190 These samples also provide very little absorption of the primary x-ray beam so it is typically most appropriate to analyze these samples in a test stand when possible. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 191 Button, you cannot set start-stop settings which ignore the Proximity Button. For example, the Easy Trigger start-stop setting must have the Backscatter safety setting enabled. While using Easy Trigger, you cannot disable Backscatter. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 192 Selecting Easy Trigger will immediately disable Proximity Start. Max Time Field Figure 57. The Max Test Time Editor Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 193 C = Clear All, E = Enter, and ">" will backspace over the current value. Selecting the E button will enter the current value as the Max Time, and return to the Start/Stop Settings Screen. Save Button Selecting the Save Button will save your current settings. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 194 Easy Trigger method is being used, and will shut off any radiation directed through the window if it determines that there is no sample present. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 195 LED lights measurement is ended. The flashing of the is not synchronized to minimize power consumption. To end the test, simply release the trigger mechanism, or any other applicable preconditions. Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 196: Camera
When you take a measurement, if you choose to do so, the bitmap image will be saved on the analyzer along with the analysis results. The interface is accessible through the System menu, as in Figure 120. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 197 Advanced Settings Camera Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 198 Selecting the empty checkbox next to Save Image will enable image saving with the analysis. Selecting the checkbox again will disable automatic saving of image data. Save Image is enabled by default. Stored camera images from previous measurements can be viewed on the analyzer. Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 199: Chapter 8 Service
Service “Contact Us” page 1 to find your nearest Service facility. Warranty Warranty statement Seller warrants that the Products will operate or perform substantially in conformance with Seller's published specifications and be free from defects in material and workmanship, when subjected to normal, proper and intended usage by properly trained personnel, for the period of time set forth in the product documentation, published specifications or package inserts.
Page 200 Accessories, Spares and Consumables - exclusions (List A) Specific warranties of some common accessories: • Battery Charger and batteries - 12 months • Instrument accessories - 12 months • Consumable - no warranty Niton XL2 Analyzer User’s Guide Thermo Scientific...
Page 201 • Single-stage or two stage helium tank regulator - 12 months • Test stands, extend-a-poles and docking stations – 12 months • Parts or spares sold, installed or supplied outside of the product warranty period and not listed above – 12 months Thermo Scientific Niton XL2 Analyzer User’s Guide...
Page 202 Service Warranty Niton XL2 Analyzer User’s Guide Thermo Scientific...
