32 | Hardware Installation and Maintenance Guide for SG5700 Appliances
E5700SG controller boot-up codes
During a normal boot-up of the appliance, the seven-segment display on the E5700SG controller
shows the following codes in the order listed:
Code Indicates
HI The master boot script has started.
PP The system is checking to see if the FPGA needs to be updated.
HP The system is checking to see if the 10/25-GbE controller firmware needs to be
updated.
RB The system is rebooting after applying firmware updates.
FP The hardware subsystem firmware update checks have been completed. Inter-
controller communication services are starting.
HE The system is awaiting connectivity with the E2800 controller and synchronizing with
the SANtricity operating system.
Note:
between the two controllers.
HC The system is checking for existing StorageGRID installation data.
HO The StorageGRID Appliance Installer is running.
HA StorageGRID is running.
E5700SG controller error codes
These codes represent error conditions that might be shown on the E5700SG controller as the
appliance boots up. Additional two-digit hexadecimal codes are displayed if specific low-level
hardware errors occur. If any of these codes persists for more than a second or two, or if you are
unable to resolve the error by following one of the prescribed troubleshooting procedures, contact
technical support.
Code
22
23
2A, 2B
40
41
42
51
92 to 96
A0 to A3
AB
AE
EA
E8
EU
If this boot procedure does not progress past this stage, check the connections
Indicates
No master boot record found on any boot device.
The internal flash disk is not connected.
Stuck bus, unable to read DIMM SPD data.
Invalid DIMMs.
Invalid DIMMs.
Memory test failed.
SPD reading failure.
PCI bus initialization.
SATA drive initialization.
Alternate boot code.
Booting OS.
DDR4 training failed.
No memory installed.
The installation script was not found.
