Port
3 Management port 1 on
the E5700SG
controller
Management port 2 on
the E5700SG
controller
4 10/25-GbE ports 1-4
on the E5700SG
controller
Related concepts

Port bond modes for E5700SG controller ports

Related tasks
Gathering installation information
Cabling the appliance
Related information
VMware installation
Red Hat Enterprise Linux or CentOS installation
Ubuntu or Debian installation
Port bond modes for E5700SG controller ports
When configuring network links for the E5700SG controller ports, you can use port bonding for the
10/25-GbE ports that connect to the Grid Network and optional Client Network, and the 1-GbE
management ports that connect to the optional Admin Network. Port bonding helps protect your data
by providing redundant paths between StorageGRID networks and the appliance.
Related tasks
Configuring network links
Type of port
1-GbE (RJ-45)
1-GbE (RJ-45)
10-GbE or 25-GbE
The SFP+
Note:
transceivers
included with the
appliance support
10-GbE link speeds.
If you want to use
25-GbE link speeds
for the four network
ports, you must
provide SFP28
transceivers.
on page 17
on page 19
on page 26
on page 36
Preparing for installation | 17
Function
Connects the E5700SG controller to the
Admin Network for StorageGRID.
• Can be bonded with management
port 1 if you want a redundant
connection to the Admin Network.
• Can be left unwired and available
for temporary local access (IP
169.254.0.1).
• During installation, can be used to
connect the E5700SG controller to a
service laptop if DHCP-assigned IP
addresses are not available.
Connect to the Grid Network and the
Client Network for StorageGRID. See
"10/25-GbE port connections for the
E5700SG controller."
