30 | Hardware Installation and Maintenance Guide for SG5700 Appliances
• The seven-segment display on the E5700SG controller shows a sequence of codes, ending
with AA and FF.
2. After the controllers have booted up, confirm the seven-segment displays show the following:
Controller
E2800 controller
E5700SG
controller
3. If the seven-segment displays show other values, see "Troubleshooting the hardware installation,"
and confirm you completed the installation steps correctly. If you are unable to resolve the
problem, contact technical support.
Related references
Status indicators on the E5700SG controller
Troubleshooting the hardware installation
Related information
E5700 and E2800 System Monitoring Guide
Seven-segment display
Shows 99, which is the default ID for an E-Series controller shelf.
Shows HO, followed by a repeating sequence of two numbers.
HO -- IP address for Admin Network -- IP address for
Grid Network HO
In the sequence, the first set of numbers is the DHCP-assigned IP address
for the controller's management port 1. This address is used to connect the
controller to the Admin Network for StorageGRID. The second set of
numbers is the DHCP-assigned IP address used to connect the appliance to
the Grid Network for StorageGRID.
Note: If an IP address could not be assigned using DHCP, 0.0.0.0 is
displayed.
