Page 1 ® ® Connectrix B Series ED-48000B Version 5.2 Hardware Reference Manual P/N 300-002-855 REV A02 EMC Corporation Corporate Headquarters: Hopkinton, MA 01748 9103 1000 www.EMC.com...
Page 2 Copyright © 2001-2006 EMC Corporation. All rights reserved. Published December, 2006 EMC believes the information in this publication is accurate as of its publication date. The information is subject to change without notice. THE INFORMATION IN THIS PUBLICATION IS PROVIDED "AS IS." EMC CORPORATION MAKES NO...
Page 3 (both customer and service) only. If you need to include such a block in your manual, please submit a request to Illustration and provide a sample for setting up copy. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 4 EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 5: Table Of Contents
Providing power to the ED-48000B ..........35 Establishing a serial connection............37 Managing cables................39 Chapter 3 Initial Configuration Parameters Overview.................... 44 Configure IP addresses for the ED-48000B ........45 Establish an Ethernet connection............ 48 EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 6 Install components into new chassis..........127 Install modems (optional) ............. 129 Verify correct operation of hardware........... 130 Configure new chassis serial number.......... 130 Verify correct operation of system..........131 Reconnect system to network and fabric ........133 EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 7 System size and weight ..............170 System blade and FRU weights ........... 171 Facility requirements ..............172 Power specifications ..............173 Power cords ..................174 Environmental requirements ............178 Thermal policy................179 EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 8 Obtaining chassis and component status ........195 Interpreting POST and boot results ..........196 POST..................196 Boot.................... 197 Diagnostics ..................198 Troubleshooting the ED-48000B ..........199 Appendix C Port Numbering Template Template ..................204 Index ..........................209 EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 9: Preface
Preface As part of an effort to improve and enhance the performance and capabilities of its product line, EMC from time to time releases revisions of its hardware and software. Therefore, some functions described in this manual may not be supported by all revisions of the software or hardware currently in use.
Page 10 EMC Connectrix Enterprise Director ED-12000B Hardware Reference Manual EMC Connectrix Departmental Switch DS-32B2 Hardware Reference Manual EMC Connectrix B Series DS-4100B Hardware Reference Manual EMC Connectrix B Series DS-4900B Hardware Reference Manual EMC Connectrix B Series DS-220B Hardware Reference Manual Brocade Fabric Manager Administrator’s Guide...
Page 11 For definitions of SAN-specific terms, visit the Storage Networking Industry Association online dictionary at http://www.snia.org/education/dictionary. Conventions used in EMC uses the following conventions for notes, cautions, warnings, this guide and danger notices. Note: A note presents information that is important, but not hazard-related.
Page 12 Preface Typographical conventions EMC uses the following type style conventions in this document: Normal Used in running (nonprocedural) text for: • Names of interface elements (such as names of windows, dialog boxes, buttons, fields, and menus) • Names of resources, attributes, pools, Boolean expressions,...
Page 13 Technical support — For technical support, go to EMC Customer Service on Powerlink. To open a service request through Powerlink, you must have a valid support agreement. Please contact your EMC sales representative for details about obtaining a valid support agreement or to answer any questions about your account.
Page 14 Preface EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 15: Overview
Storage Area Network (SAN). The ED-48000B director is the highest-performance and highest-scalability director offered by EMC. It satisfies the most demanding Reliability, Availability, and Serviceability (RAS), performance, and scalability requirements of a director, while delivering investment protection, interoperability, and fabric-based intelligence advantages.
Page 16: Ed-48000B Features
Supports 1-, 2-, and 4-Gbit/sec auto-sensing Fibre Channel ports. Trunking technology groups up to eight ports to create high performance 32-Gbit/sec ISL trunks between switches. Universal ports self-configure as E_Ports, F_Ports, or FL_Ports. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 17: Hardware Components
Overview Hardware components The ED-48000B features a modular and scalable mechanical construction that allows a wide range of flexibility in installation, fabric design, and maintenance. The ED-48000B consists of the following: Up to eight hot-swappable port blade assemblies, which can be configured in a single chassis, delivering up to 384 Fibre Channel ports Two slots for control processor (CP) blade assemblies (slots 5 and...
Page 18 • 48-port 4-Gbit/sec port blade (PB-48K-48) • 18-port, 16 FC + 2 GbE (PB-48K-18i, up to two blades per chassis) Small Form-Factor Pluggable (SFP) optical transceivers utilized for 1-, 2-, and 4-Gbit/sec ports EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 19: Portside Of The Ed-48000B
Overview Portside of the ED-48000B Figure 1 displays the portside of the ED-48000B director. POWER SUPPLY 4 POWER SUPPLY 3 Link Link 10/100 Mb/s 10/100 Mb/s Active CP Active CP POWER SUPPLY 2 POWER SUPPLY 1 POWER SUPPLY 1 & 3 POWER SUPPLY 2 &...
Page 20: Nonport Side Of The Ed-48000B
Nonport side of the ED-48000B director Figure 2 Port Blade and CP Blade LEDs Blower Handle WWN Bezel Blower Assembly #3 Power Supply LEDs Blower Assembly #2 Blower Power LED Blower Assembly #1 Blower Fault LED EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 21: High Availability
Overview High availability The following features contribute to the ED-48000B high-availability design: Redundant, hot-swappable components Redundant power supply and blower assembly subsystems Enhanced data integrity on all data paths Fabric Shortest Path First (FSPF) rerouting around failed links Integration with Simple Network Management Protocol (SNMP) managers Automatic control processor failover Nondisruptive “hot”...
Page 22: Reliability
Offline control processor diagnostics and remote diagnostics simplify troubleshooting. The standby control processor continuously runs diagnostics to ensure it is operational, should a failover be necessary. Inter-IC (I C) monitoring and control. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 23: Serviceability
Nonvolatile random-access memory (NVRAM), containing the OEM serial number, EMC serial number, revision information, and part number information Background health-check daemon Memory scrubber, self test, and bus ping to determine if a bus is...
Page 24: Pb-48K-18I Blade
A maximum of two PB-48K-18i blades can be installed in a ED-48000B. The PB-48K-18i blade is intended as a platform for Fibre Channel Routing Services and FCIP. See the EMC Connectrix B Series Fabric OS Administrator’s Guide for information on configuring these features. The PB-48K-18i blade provides the following features:...
Page 25 CP. You must have Fabric OS v5.1.0 or higher or the PB-48K-18i blade will be faulted. For more information see the EMC Connectrix B Series PB-48000B-18i Hardware Reference Manual. PB-48K-18i blade...
Page 26: Software Features
Storage Management Initiative (SMI) MIBs, which allow common information necessary for management software to provide information to a SAN administrator. Refer to the EMC Connectrix B Series Fabric OS MIB Reference Manual for additional MIB information. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 27: Port Numbering
When you perform a port swap operation When you enable Extended Edge PID mode on the director. For more information on Extended Edge PID mode, refer to the EMC Connectrix B Series Fabric OS Administrator’s Guide. The ED-48000B uses the following port numbering schemes: FC4-16 port blade —...
Page 28 Overview EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 29: Installation, Setup, And Login
Invisible Body Tag Installation, Setup, and Login This chapter contains the following information: Overview ..................... 30 Time and items required ..............31 Site planning and safety guidelines ..........32 Items included with the ED-48000B ..........34 Providing power to the ED-48000B ..........35 Establishing a serial connection ............
Page 30: Overview
IMPORTANT EMC recommends that the installation of the ED-48000B be performed by trained EMC service personnel. The content in this chapter is being provided for information purposes only and is not intended to be a "how to" manual for customer set up of the ED-48000B.
Page 31: Time And Items Required
Installation, Setup, and Login Time and items required Table 1 describes the main installation and setup tasks and the estimated time required for each, based on a fully populated ED-48000B switch (384 Fibre Channel ports). Configurations containing fewer than 384 ports require less time. These time estimates assume a prepared installation site and appropriate power and network connectivity.
Page 32: Site Planning And Safety Guidelines
4. Ensure that two dedicated electrical branch circuits with the following characteristics are available: • 200–40 VAC, 50–60 Hz • Protected by a circuit breaker in accordance with local electrical codes EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 33 Installation, Setup, and Login • Supply circuit, line fusing, and wire size adequate to the electrical rating on the chassis nameplate • Location close to the ED-48000B chassis and easily accessible • Grounded outlets installed by a licensed electrician, compatible with the power cords Note: To maximize fault tolerance, connect each power cord to a separate power source.
Page 34: Items Included With The Ed-48000B
– The RS-232 cable is 10-feet (3.05 meters) long and has an adapter at one end that can be removed to provide an RJ-45-style connector. • AC-input cable: North America, United Kingdom, Continental Europe, Australia, New Zealand, and International IEC 60309 EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 35: Providing Power To The Ed-48000B
Installation, Setup, and Login Providing power to the ED-48000B If a modem is to be used with the ED-48000B, it needs to be connected Note: prior to powering on the switch. To install a modem, refer to Chapter 8, ”Setting Up and Installing Modems.” To provide power to the ED-48000B: 1.
Page 36 ED-48000B to the network until the IP addresses are configured. Refer to Chapter 3, ”Initial Configuration Parameters,” for additional information. Allow the ED-48000B to run for 10 minutes (minimum) to complete POST after powering on before you power off. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 37: Establishing A Serial Connection
Installation, Setup, and Login Establishing a serial connection Initial communication to a ED-48000B switch requires a serial connection. To establish a serial connection and log in to the director: 1. Verify that the ED-48000B is powered on and that POST is complete by verifying that all power LED indicators on the port blades and CP4 blades are displaying a steady green light.
Page 38 Local CP (Slot 6, CP1): Active Remote CP (Slot 5, CP0): Standby, Healthy HA enabled, Heartbeat Up, HA State synchronized The configuration can be modified only through a login session to the active CP blade. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 39: Managing Cables
Installation, Setup, and Login Managing cables The new cable management tray introduced in the ED-48000B allows for simpler cable management. The new tray allows additional space between the chassis and shelf and can be installed without service disruption. The ED-48000B cables can be managed in a variety of ways, including the following: Routed down through the cable management tray Routed out either side of the chassis...
Page 40 2 & - 6 0 1 & 0 - 2 - 6 0 0 - 2 Cable management tray installed in an ED-48000B Figure 4 Director Chassis Velcro Straps Cables Cable Management Trayr EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 41 Installation, Setup, and Login Cable guides (pillars) Cable guides (pillars) are provided with the ED-48000B, and can be used to organize the port cables into logical groups, such as according to port quads (sets of four neighboring ports). The cable guides do not attach to the chassis (see Figure Cable pillars are not supported when using the FC4-32 or PB-48K-48...
Page 42 10,000 m Multi Mode 50 microns 2 Gb/sec 0.5 m 300 m 4 Gb/sec 0.5 m 150 m 62.5 microns 2 Gb/sec 0.5 m 150 m 4 Gb/sec 0.5 m 70 m EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 43: Initial Configuration Parameters
Invisible Body Tag Initial Configuration Parameters This chapter describes initiation configuration parameters and includes the following sections: Overview ..................... 44 Configure IP addresses for the ED-48000B........45 Establish an Ethernet connection............. 48 Customize a switch name ..............49 Set the Domain ID................50 Verify the PID mode and connect to the fabric......
Page 44: Overview
5. Specify a domain ID for the director. 6. Verify that the PID mode matches the fabric and connect the director to the fabric. 7. Enable software licenses as necessary. 8. Back up the configuration. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 45: Configure Ip Addresses For The Ed-48000B
Initial Configuration Parameters Configure IP addresses for the ED-48000B The ED-48000B director requires three IP addresses, which are configured using the ipAddrSet command. IP addresses are required for both CP blades (CP0 and CP1) and for the single logical switch (shown as SWITCH under the ipAddrShow command) in the ED-48000B director.
Page 46 Ethernet Subnetmask [0.0.0.0]: 123.123.123.123 Gateway IP Address [0.0.0.0]: 123.123.123.124 IP address of remote CP is being changed...Done. Committing configuration...Done. swDir:admin> reboot 5. Reboot the ED-48000B director by typing at the prompt. reboot EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 47 Initial Configuration Parameters The serial port can be used to monitor error messages through a serial connection. It is not recommended as a command interface during normal operations. If this port is not going to be in ongoing use, remove the serial cable and protect the port from dust by replacing the shipping cap.
Page 48: Establish An Ethernet Connection
Telnet, Web Tools, or Fabric Manager. 4. To complete any additional ED-48000B configuration procedures through a Telnet session, log in to the switch by Telnet, using the admin login. The default password is “password”. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 49: Customize A Switch Name
Initial Configuration Parameters Customize a switch name The switch name of the ED-48000B director can be up to 15 characters long; can include alphabetic, numeric, and underscore characters; and must begin with an alphabetic character. The default name for the ED-48000B is “swDir”. Note: Changing the name causes a domain address format RSCN to be issued.
Page 50: Set The Domain Id
Fabric parameters (yes, y, no, n): [no] y 5. Enter a unique Domain ID: Domain: (1..239) [1] 3 6. Complete the remaining prompts or press to accept the other settings and exit. 7. Type to reenable the ED-48000B. switchEnable EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 51: Verify The Pid Mode And Connect To The Fabric
Initial Configuration Parameters Verify the PID mode and connect to the fabric Before connecting the ED-48000B to the fabric, verify the port identifier (PID) mode on the switch matches the other switches in the fabric. This parameter must be set identically on all switches in the fabric.
Page 52 Initial Configuration Parameters 7. Verify fabric connectivity using the fabricShow command at the prompt. The fabricShow command provides general information about the fabric. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 53: Enable Software Licenses
Enable software licenses The ED-48000B is shipped with licenses for Web Tools and Zoning factory installed. Licenses for other optional features are available by contacting your EMC account representative. To determine which licenses are currently enabled, use the licenseShow command. swDir:admin> licenseshow...
Page 54: Back Up The Configuration
Note: Passwords are not saved in the configuration file, and are not uploaded during a configUpload. Password information should be saved in hardcopy in a secure location for emergency reference, subject to your security and password management policy. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 55 Invisible Body Tag Monitor System Components Refer to the following sections for LED and CLI information about each ED-48000B component: Overview ..................... 56 Port blades................... 57 CP blades..................... 61 Power supplies ................... 63 Blower assemblies ................65 WWN card ..................67 Cable management tray ..............
Page 56: Monitor System Components
This chapter provides information about determining the status of each component (using LEDs and CLI commands). See the EMC Connectrix B Series PB-480000B-8i Hardware Reference Manual for monitoring information for those platforms. See the WebTools Administrator’s Guide and the Fabric OS Administrator’s Guide for additional information.
Page 57: Port Blades
Monitor System Components Port blades To determine the status of a port blade: 1. Check the LED indicators on the port blade (see Figure 6). The LED patterns may temporarily change during POST and other diagnostic tests; for information about how to interpret the LED patterns, refer to Table 3 on page 2.
Page 58 PB-48K-48 Port Blade Fibre Channel Ports Blade Power LED Port 27 Status LED Blade Status LED Port 3 Status LED Ejector Port 25 Status LED Thumb Screw Port 1 Status LED Ejector EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 59 Steady amber Port blade is faulty. Ensure blade is firmly seated and check status with slotShow command. If LED remains amber, consult your EMC service representative. Slow-flashing amber (on 2 Port blade is not seated Pull blade out and reseat it. If LED seconds;...
Page 60 . Fast-flashing amber (on 1/2 Transceiver or port is faulty. Change transceiver or reset switch from second; then off 1/2 second) workstation. Alternating Port is bypassed. Reset port from workstation. green/amber EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 61: Cp Blades
Monitor System Components CP blades To determine the status of a CP blade: 1. Check the LED indicators on the port blade (see Figure 8). The LED patterns may temporarily change during POST and other diagnostic tests; for information about how to interpret the LED patterns, refer to Table 4 on page 2.
Page 62 Steady green Ethernet link speed is 100 No action required. Mb/s. Active CP Steady blue Active CP blade. No action required. No light (LED is off) Standby CP blade. No action required. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 63: Power Supplies
2. Check power supply status by typing psShow The power supply status displays OK, Absent, or Faulty. If a power supply is absent or faulty, contact your EMC service representative to order replacement parts, as necessary. Figure 9 displays the power supplies supported in the ED-48000B.
Page 64 Flashing amber Power supply is unable to Verify that the incoming power meets supply power. power requirements (refer to “Power specifications” on page 173). EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 65: Blower Assemblies
The status for each blower assembly displays OK, Absent, or Faulty. The RPM of each fan in the assembly is also provided. If a blower assembly is absent or faulty, contact your EMC service representative to order replacement parts, as necessary.
Page 66 Fast-flashing amber Environmental range Check for out-of-bounds environmental (on 1/2 second; then off 1/2 exceeded. condition, resolve any problems, and second) reseat unit. If LED continues to flash, replace unit. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 67: Wwn Card
Monitor System Components WWN card Note: If a Status LED on the WWN bezel flashes, the Power LED on the WWN bezel also flashes, for increased visibility. To determine the status of the WWN card: 1. Check the LED indicators on the WWN bezel (see Figure 11 on page 68) and verify that they reflect the actual status of the...
Page 68 WWN bezel supported by the ED-48000B Figure 11 Port Blade Power LED Power Supply Power LED/Status LED Port Blade Status LED Badge CP Blade Power LED Captive Screw CP Blade Status LED EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 69 Monitor System Components Table 9 describes the WWN bezel LED patterns and the recommended actions for those patterns for the ED-48000B. WWN bezel LED descriptions Table 9 LED purpose Color Status Recommended action Port blade/CP blade Power Steady green Power is OK. No action required.
Page 70: Cable Management Tray
ED-48000B. 2 & 1 & Cable management tray for the ED-48000B Figure 12 Cable Management Tray Captive Screws (2 per cable management tray) Ground Strap Connector Hole EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 71: Remove And Replace System Components
Invisible Body Tag Remove and Replace System Components Refer to the following sections for specific FRU removal and replacement procedures: Overview ..................... 72 Replacing the cable management tray ..........73 Replacing a port blade and filler panel........... 77 Replacing a CP blade................. 85 Replacing a power supply and filler panel ........
Page 72: Overview
"how to" guide for customer- performed maintenance of the ED-48000B. Not all of the FRUs described in this chapter are available from EMC. Consult with your EMC Support representative for information concerning which components are replaceable in the field.
Page 73: Replacing The Cable Management Tray
Remove and Replace System Components Replacing the cable management tray The ED-48000B can continue to operate during the replacement of the cable management tray. Time and items required The replacement procedure for the cable management tray takes less than 5 minutes. A #1 Phillips screwdriver is required to complete the replacement.
Page 74 0 - 2 - 6 0 2 & 0 - 2 1 & Figure 13 Installing a cable management tray Director Chassis Cable Management Tray Ground Strap Connector Screws (2 per cable management tray) EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 75 Remove and Replace System Components Removing a cable management tray To remove the cable management tray (shown on the right in Figure 13 on page 74): 1. If the director is not operating: Remove the AC power connector cables and continue with step 2, then remove the cable management tray from the chassis.
Page 76 6. Arrange the cables through or along the cable management tray as required. You should route the AC power connector cables out each side of the chassis. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 77: Replacing A Port Blade And Filler Panel
Remove and Replace System Components Replacing a port blade and filler panel This section describes how to remove and replace port blades (see Figure 14 on page 78) and blade filler panels (see Figure 15 on page 79) from the ED-48000B. A filler panel should be removed only when being replaced with a port blade or new filler panel.
Page 78 0 - 2 ED-48000B port blade removal or replacement Figure 14 Director Chassis Port Blade (an FC4-16 blade is shown as an example in this figure) On/Off Slider Switch (in the Off position) Ejector EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 79 Remove and Replace System Components Figure 15 illustrates how to remove or replace a PB-48K-48 port blade, which has ejectors instead of sliders. L in b /s /1 0 L in b /s ti v /1 0 ti v - 6 0 0 - 2 - 6 0 0 - 2...
Page 80 Removing and installing a filler panel Figure 16 Director Chassis Filler Panel with Ejectors Filler Panel with Handles Ejectors (x2) Captive Screw (x2) Filler Panel with Pull Tabs Handle Pull Tabs (x2) EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 81: Removing A Port Blade
Make sure that the part number on the unit being replaced matches the replacement part number. The chassisShow command displays information about the port blades, including part numbers (xx-000xxxx-xx), EMC serial numbers, and additional status. 5. Ensure that traffic is not flowing through the port blade (port speed LEDs and port status LEDs should be off) prior to disconnecting cables.
Page 82 2. Grasp the handle in the middle of the filler panel faceplate. 3. Pull the filler panel out of the chassis using the handle. To remove a filler panel with ejectors: 1. Push in the yellow tab on each ejector. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 83 Remove and Replace System Components 2. Lever both ejectors all the way open. 3. Pull the filler panel out of the chassis. To remove a filler panel with pull tabs: 1. Unscrew the top and bottom captive screws on the filler panel. 2.
Page 84 1. Orient the filler panel so that the captive screws are at the front of the chassis and the flat side of the filler panel is on the left. 2. Tighten the captive screws in place, fastening the filler panel in the chassis. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 85: Replacing A Cp Blade
Remove and Replace System Components Replacing a CP blade This section describes how to remove and replace a control processor (CP) blade from the ED-48000B (see Figure 17 on page 87). Each ED-48000B has two CP cards: one located in slot 5 and the other in slot 6.
Page 86 Do not attempt to replace the battery on a CP card. There is danger of explosion if the battery is incorrectly replaced or discarded. Contact your EMC service representative if the real-time clock begins to lose time. Time and items required The replacement procedure for the CP blade takes approximately 30 minutes.
Page 87 Remove and Replace System Components Figure 17 displays an ED-48000B with the CP blades in the chassis. Li n ti v e Li n ti v e - 6 0 0 - 2 - 6 0 0 - 2 s c al e: .
Page 88 CP blade is active: haShow swDir:admin> haShow Local CP (Slot 6, CP1) : Active Remote CP (Slot 5, CP0) : Standby, Healthy HA Enabled, Heartbeat Up, HA State Synchronized EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 89 Remove and Replace System Components Note: Enter all remaining commands from the serial console for the active CP blade, unless otherwise indicated. For more information about commands, refer to the Fabric OS Command Reference Manual. 3. If the healthy CP blade is performing as the active CP blade, continue with step 5 on page 90.
Page 90 CP blades. Removing a CP blade might impact user performance and should not occur until the replacement CP blade is ready to be installed. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 91 Do not replace the real-time clock battery on a CP blade. There is danger of explosion if the battery is incorrectly replaced or discarded. Contact your EMC service representative if the real-time clock begins to lose time. To remove a CP blade: 1.
Page 92 To verify that boot and POST are complete on the new CP blade (a minimum of three minutes), and that the CP blades have achieved failover redundancy: 1. Wait until the status LEDs on both CP blades are not lit. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 93 Remove and Replace System Components Note: The status LEDs on the active CP blade displays amber until the active CP blade is fully operational, and the status LED on the standby CP blade displays amber until the CP blades have achieved failover redundancy.
Page 94 7. If the firmware version on the replacement blade does not match that on the active CP blade, bring the replacement blade to the same firmware level as the active blade. Check with your EMC service representative for supported versions.
Page 95 13. Type firmwareShow to verify that the firmware version has been updated. 14. Pack the old CP blade in the packaging provided with the new CP blade, and contact your EMC service representative to determine the return procedure. Replacing a CP blade...
Page 96: Replacing A Power Supply And Filler Panel
Administrator’s Guide. CAUTION To protect against AC failure on the ED-48000B, EMC recommends a minimum of one power supply in slot 1 or 3 and one in slot 2 or 4. Additional power supplies might be required depending on how populated the switch is.
Page 97 Remove and Replace System Components Disassembling any part of the power supply voids the part warranty and regulatory certifications. There are no user-serviceable parts inside the power supply. Time and items required The replacement procedure for each power supply takes less than 5 minutes.
Page 98 1 or 3, and one in slot 2 or 4. 2. Push the locking tab toward the power supply unit and pull the handle out and down. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 99 Remove and Replace System Components CAUTION Support the power supply unit from underneath while removing it from the chassis. 3. Use the handle to pull the power supply out of the chassis. 4. If you are not replacing the removed power supply unit, orient the filler panel so the handle is vertical and the side tabs are on the right;...
Page 100: Replacing A Blower Assembly
ED-48000B should be turned off to prevent overheating. CAUTION Disassembling any part of the blower assembly voids the part warranty and regulatory certifications. There are no user-serviceable parts inside the blower assembly. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 101 Remove and Replace System Components Figure 20 illustrates the removal and installation of a blower assembly, as described in the blower assembly replacement procedures. Removing and installing the blower assembly Figure 20 Chassis Captive Screws (2 per blower assembly unit) Blower Assembly Replacing a blower assembly...
Page 102 To install a blower assembly: 1. Orient the blower assembly as shown in Figure 20 on page 101 and slide it into the chassis, pushing firmly to ensure that it is seated. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 103 Remove and Replace System Components 2. Verify that the power LED displays a green light. If not, ensure that the blower assembly is seated correctly. 3. Push the top of the handle into the recess. 4. Use the screwdriver or your fingers to tighten the captive screws. Replacing a blower assembly...
Page 104: Replacing The Wwn Bezel And Card
ED-48000B after installing the new WWN card. Disassembling any part of the WWN card voids the part warranty and regulatory certifications. The WWN card contains no user-serviceable parts. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 105 Remove and Replace System Components This section provides the following information: “Time and items required” on page 105 “Verifying necessity of replacement” on page 107 “Removing the WWN card” on page 108 “Installing a WWN card” on page 110 Basic instructions for replacing the WWN card are provided in this document.
Page 106 Director Chassis Push Pad WWN Connector Captive Screw (2 per bezel) WWN Card with Push Pad WWN Card without Push Pad Handle Attaching Screws (2 per WWN Card without Push Pad) Bezel EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 107 Remove and Replace System Components Verifying necessity of replacement Before replacing the WWN card, verify that the replacement is necessary. Any of the following events can indicate that the card requires replacement: Status LEDs on the WWN bezel (see Figure 11 on page 68) not reflecting the actual status of the components Problems viewing or modifying the data stored on the WWN...
Page 108 ED-48000B. The CLI can be either a Telnet session or a serial console session. 1. Open a Telnet session to the ED-48000B and log in to the active CP as admin. The default password is "password". EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 109 Remove and Replace System Components 2. Verify you are logged into the active CP. Run the haShow command to determine the active CP. 3. Type fruReplace wwn from the active CP blade and wait for the prompt “Do you wish to continue [y/n]?” to appear; then type y. 4.
Page 110 In the CLI session, type to indicate that the continue replacement has been completed. Please enter the word `continue' after the new WWN card has been installed: continue EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 111 Note: The LEDs might take up to 2 minutes after WWN card installation to begin functioning. 5. Pack the faulty WWN card in the packaging provided with the new card and return it to your EMC service representative. Replacing the WWN bezel and card...
Page 112: Installing And Removing Sfps In A Port Blade
To use the SFP extraction tool, slide the SFP extraction tool on to the bale of the SFP and pull it out. SFP extraction tool Figure 22 For instructions that are specific to the transceiver model, refer to the transceiver manufacturer’s documentation. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 113: Chassis Replacement
Invisible Body Tag Chassis Replacement The ED-48000B chassis (D3) is highly reliable and unlikely to fail. This chapter describes how to remove and replace a D3 chassis in the event of a failure. Refer to the following sections of this chapter for specific information: Overview ...................
Page 114: Overview
Disassembling any part of the chassis voids the part warranty and regulatory certifications. The chassis itself contains no user-serviceable parts. Time required The chassis replacement procedure takes approximately 3 hours to complete. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 115: Items Required
Chassis Replacement Items required The following items are required for the chassis replacement procedure: Electrostatic discharge (ESD) grounding strap ESD grounding pads for protecting control processor (CP) cards, 16-port cards, and the WWN card Serial cable and workstation computer with a terminal emulator application (such as HyperTerminal for Windows systems or TIP for Solaris systems), required only if serial console session used Pallet jack or hydraulic or assisted lift that raises a minimum of 55...
Page 116: Verify Need For Replacement
Before replacing the chassis, verify that the replacement is necessary. Ensure that the components are firmly seated when troubleshooting, and contact your EMC Customer Service representative if you have any questions about whether the chassis should be replaced. Any of the following events might indicate that you need to replace...
Page 117: Record Critical Switch And San Information
Chassis Replacement Record critical switch and SAN information All commands must be entered from a CLI session (Telnet or serial) to the active CP card unless otherwise indicated. For detailed information about Fabric OS commands, refer to the Fabric OS Reference Manual.
Page 118 Chassis Backplane Revision: 1F SW BLADE Slot: 1 Header Version: Power Consume Factor: Factory Part Num: 60-0001532-03 Factory Serial Num: KP000000195 Manufacture: Day: Month: Year: 2000 Update: Day: 14 Month: Year: 2005 EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 119 Chassis Replacement Time Alive: 187 days Time Awake: 3 days <output truncated> CHASSIS/WWN Unit: 1 (in same assembly as WWN Unit: Header Version: Power Consume Factor: Factory Part Num: 60-0001501-07 Factory Serial Num: FT02X805BE2 Manufacture: Day: 26 Month: Year: 2003 Update: Day: 14 Month:...
Page 120 Location of “SANbefor.txt” file: Notes regarding nsshow output: Notes regarding nsallshow output: Notes regarding switchshow output: Notes regarding fabricshow output: Output from supportshow command Location of “spptshow.txt” file: Notes regarding supportshow output: EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 121 Chassis Replacement Critical information checklist (continued) Table 13 Information about the new chassis New factory serial number: New serial number (if available): Note: Copying the individual switch configurations, miscellaneous configuration information, SAN profile, and supportShow output into text files is recommended. Recommended file names are “config-switch.txt,” “config-miscinfo.txt,”...
Page 122: Disconnect From Network And Fabric
SFP transceivers can be left in the port blades or removed. If you are using any, save the cable management pillars for later use. 5. Disconnect all cables from both CP blades. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 123: Remove Components From Chassis
Chassis Replacement Remove components from chassis You must remove the field replaceable units (FRUs) from the ED-48000B chassis in the following order. Refer to the instructions in Chapter 5, ”Remove and Replace System Components,” component-specific removal instructions: 1. Remove the power supply units or filler panels as described in “Replacing a power supply and filler panel”...
Page 124 2. Wear an ESD grounding strap when handling the CP cards, 16-port cards, and WWN card. 3. Protect the CP cards, 16-port cards, and WWN card with static bags or grounding pads while they are out of the chassis. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 125: Remove And Replace Chassis
Chassis Replacement Remove and replace chassis WARNING An empty ED-48000B chassis weighs approximately 104 lbs (47 kg) and requires a hydraulic or assisted lift to move. If the switch is installed in a cabinet, ensure that the cabinet is balanced and mechanically secured and that the removal and installation procedure will not compromise cabinet stability.
Page 126 Cabinet Setup and Installation Manual or the Mid-Mount Rack Kit Installation Procedure for more information. CAUTION To ensure adequate cooling, install the chassis with the cable side, which contains the air intake vents, facing the cool air aisle. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 127: Install Components Into New Chassis
Chassis Replacement Install components into new chassis CAUTION Do not force the installation of any of the components. If the component does not slide in easily, ensure that it is correctly aligned and positioned before continuing. Do not turn on the power until it is time to verify hardware operation (see step 1 on page 130).
Page 128 “Replacing a port blade and filler panel” on page 8. Install the power supplies or filler panels in the new chassis as described in “Replacing a power supply and filler panel” on page EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 129: Install Modems (Optional)
Chassis Replacement Install modems (optional) The ED-48000B detects modems only during power on or reboot. If a modem is connected to an operating switch, a reboot is required for the ED-48000B to detect the modem. If modems are in use, reconnect modem cables to the CP cards. For modem installation instructions, refer to Chapter 8, ”Setting Up and Installing...
Page 130: Verify Correct Operation Of Hardware
If the LEDs do not indicate a standard healthy state, try reinstalling the corresponding component. Configure new chassis serial number Your EMC Customer Service representative will be provided with instructions for configuring the new chassis serial number. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 131: Verify Correct Operation Of System
Chassis Replacement Verify correct operation of system To verify that the ED-48000B is operating correctly: 1. Log in to the ED-48000B as admin: swDir:admin> login login: admin password: xxxxxxxx swDir:admin> 2. Type slotShow command and verify that all the installed cards are detected and that their status is operational.
Page 132 HostName : cp0 Gateway Address: 10.32.40.1 Ethernet IP Address: 10.32.50.11 Ethernet Subnetmask: 255.55.0.0 HostName : cp1 Gateway Address: 10.32.40.1 Backplane IP address of CP0 : 10.0.0.5 Backplane IP address of CP1 : 10.0.0.6 swDir:admin>swDir:admin> EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 133: Reconnect System To Network And Fabric
Chassis Replacement Reconnect system to network and fabric Refer to the cable routing information recorded in “Cable routing tables” on page 137 for the following steps: 1. Connect the CP blades to the local area network: a. Refer to the cable routing information recorded earlier and insert the appropriate Ethernet cables into each Ethernet port.
Page 134 The cables can be routed to either side of the management tray or down through the holes in the tray. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 135: Verify Correct Configuration Of Fabric
Chassis Replacement Verify correct configuration of fabric Copying the command outputs from this section into a file is recommended. To verify correct configuration of the fabric: 1. Create an “after” SAN profile by entering the following commands and copying the output to a text file named “SANafter.txt”: •...
Page 136 If the cardboard packaging is used, you must use banding equipment to enclose the package with a minimum of two bands around the entire package. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 137: Cable Routing Tables
Chassis Replacement Cable routing tables Table 14 provides a sample of cable routing information. Table 14 Sample cable routing table for ED-48000B (Switch name: swDir) Cable labels Slot/Port Switch end Device end Device connected to Slot/Port of device Slot 1 Port 0 North 24 - 1/0 East 26 - 0 SW3200 East 26...
Page 138 Chassis Replacement Cable routing table for ED-48000B (continued) Table 15 Slot/Port Cable labels Slot Port Switch end Device end Connected device Slot/Port of device EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 139 Invisible Body Tag Blade Support Notes This chapter contains the following information: Overview ................... 140 ED-48000B blade support ............... 141 Planning the installation ..............143 Preparing to add new blades............145 Installing port blade procedures............ 148 Validating the installation............... 150 Blade Support Notes...
Page 140: Overview
FC blades contain only Fibre Channel ports: FC4-16/32/ and PB-48K-48. AP blades are “intelligent” blades: PB-48K-18i CP blades have a control processor (CP) used to control the entire switch; they can be inserted only into slots 5 and 6. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 141: Ed-48000B Blade Support
If CP2 blades are installed, the director is an ED-24000B. If CP4 blades are installed, the director is an ED-48000B. Note: Mixed CP blades are not supported on a single chassis. EMC requires that each CP (primary and secondary partition) maintain the same firmware version.
Page 142: Port Blade Compatibility
• 18-port, 16 FC + 2 GbE (PB-48K-18i, up to two blades per chassis), running Fabric OS v5.1.0 or higher Note: The PB-48K-48 will be identified in various CLI output as FC4-48. The PB-48K-18i will be identified in various CLI output as FR4-18i. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 143: Planning The Installation
Blade Support Notes Planning the installation This section provides information on planning the installation of new port blades. Supported blade installation overview The following high-level blade installation procedures are supported. For more information on chassisConfig mode see “Chassis configuration setting” on page 143.
Page 144: Power Requirements
A fully populated ED-48000B director with no application blades can function with the power supplied on two power supplies, so there is no need to add or replace any power supplies in the chassis. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 145: Preparing To Add New Blades
Blade Support Notes Preparing to add new blades This section provides information on how to prepare for the installation. Note: The ED-12000B director is supported only up to Fabric OS v5.0.x. Upgrading to the latest Fabric OS version The Connectrix B director must be upgraded to Fabric OS v5.2.0 (or later) prior to the installation process.
Page 146: Backing Up The Director Configuration And Obtaining A San Profile
7. Upload the switch configuration settings to an FTP server using the configUpload command. 8. Run the supportSave command to provide a baseline for support, if needed. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 147: Verifying A Safe Work Space
Verify that you have adequate space in front of the Connectrix B director to safely pull and replace the blades. Verify that the chassis is properly grounded. EMC recommends that you wear a grounding strap whenever you come into physical contact with the Connectrix B director.
Page 148: Installing Port Blade Procedures
4. Verify that your switch is in chassisConfig option 1. Enter the chassisConfig command without operands to view the current mode. 5. Install the FC2-16 port blades, one at a time, as follows: EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 149 Blade Support Notes a. Verify that your wrist strap is grounded to the chassis of the ED-48000B director. Adjust the wristband so that there are no gaps between the band and your skin. b. Secure the FC2-16 blade in place. Make sure that you unscrew the latches and that they are open when you push the blade into the chassis.
Page 150: Validating The Installation
For assistance, see the following: Troubleshooting chapter in the Fabric OS Administrator’s Guide for basic troubleshooting steps. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 151: Ed-48000B Configuration Form
Blade Support Notes Run the supportSave command to provide a comparison from earlier execution of this command. Call your EMC Customer Service representative. ED-48000B configuration form Use the following forms as a hard copy reference for configuration information prior to blade installation.
Page 152 Device connected Speed Trunk Port Long Distance VC Link Init Locked L_Port Locked G_Port Disabled E_Port EX_Port Mirror Port ISL R_RDY Mode RSCN Suppressed NPIV capability MCast loopback Delay FLOGI Persistent disable EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 153 Blade Support Notes FC port configuration setting (Ports 16–31) for FC blade in slot #: ___ Table 20 Port Numbers FC Port Configuration Device connected Speed Trunk Port Long Distance VC Link Init Locked L_Port Locked G_Port Disabled E_Port EX_Port Mirror Port ISL R_RDY Mode...
Page 154 FC port configuration setting (Ports 32–47) for FC blade in slot #: ____ Table 21 Port Numbers FC Port Configuration Device connected Speed Trunk Port Long Distance VC Link Init Locked L_Port Locked G_Port Disable d E_Port EX_Port Mirror Port EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 155 Blade Support Notes FC port configuration setting (Ports 32–47) for FC blade in slot #: ____ Table 21 (continued) Port Numbers FC Port Configuration ISL R_RDY Mode RSCN Suppressed NPIV capability MCast loopback Delay FLOGI Persistent disable Validating the installation...
Page 156 Blade Support Notes EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 157: Setting Up And Installing Modems
Invisible Body Tag Setting Up and Installing Modems This chapter provides the following information: Overview ................... 158 Using high-availability connectivity ..........159 Connecting modems................ 161 Setting up a remote modem system ..........162 Verifying the modem connection........... 164 Setting Up and Installing Modems...
Page 158: Overview
ED-48000B is recommended. For increased security, any active modem sessions are automatically disconnected if the modem cable is disconnected. For optimal security, disconnect the modem cable when it is not in use EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 159: Using High-Availability Connectivity
Setting Up and Installing Modems Using high-availability connectivity High availability of the modem connection can be ensured by connecting a separate modem to each CP blade and then connecting both modems to a shared telephone line (see Figure 23 on page -160).
Page 160 POWER SUPPLY 1 & 3 POWER SUPPLY 2 & 4 scale: 1/8" = 1" 200-240 VAC 12A 50-60 Hz 200-240 VAC 12A 50-60 Hz Figure 23 Two modems attached for high availability EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 161: Connecting Modems
Setting Up and Installing Modems Connecting modems Note: Setting up the modems before powering on the ED-48000B and connecting it to the fabric is recommended. The following items are required to set up two modems to work with the ED-48000B: Two Hayes-compatible modems, such as the Zoom/Modem V.92 EXT Model 3049 Two standard modem cables, DB25 (male) to DB9 (female)
Page 162: Setting Up A Remote Modem System
2. Disable any serial communication programs running on the workstation (such as a synchronization program for a PDA). Analog Telco Remote Modem DB-25M DB-9F PC or Laptop Modem running Cable Hyperterminal Remote modem setup Figure 24 EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 163 Setting Up and Installing Modems 3. Launch the terminal emulator application and configure as described next. Terminal emulator parameters for most Windows systems Table 22 Parameter Value Port speed (bits per second) 115200 The port usually defaults to highest speed supported by modem;...
Page 164: Verifying The Modem Connection
7. Verify that after one ring, the “Off Hook” (OH) indicator illuminates on the modem associated with the active CP blade (usually in slot 5)and a login prompt is presented to the remote client. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 165 Setting Up and Installing Modems 8. Log in to the switch from the remote client as admin. The default password is “password”. Note: If the Off Hook indicator illuminates on the standby CP blade modem, recheck the modem cable connection to the active CP blade. 9.
Page 166 Setting Up and Installing Modems EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 167: Specifications
Invisible Body Tag Specifications This appendix provides product specifications for the ED-48000B. Refer to the following sections: System architecture................168 System size and weight ..............170 System blade and FRU weights ............. 171 Facility requirements ............... 172 Power specifications ................ 173 Power cords ..................
Page 168: System Architecture
PB-48K-48 supports these port types: E_Port and F_Port PB-48K-18i supports these port types: FL_Port, F_Port, E_Ports, VE_Port, EX_Port, and VEX_Port Note: Self-discovery is based on switch type (U_Port) with an optional port type control. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 169 Specifications System architecture (continued) Table 23 Data traffic types Fabric switches supporting unicast, multicast (255 groups), and broadcast Media types Hot-pluggable, industry-standard small form-factor pluggable (SFP), LC connector; • short-wave laser (SWL), up to 500 m (1,640 ft.); • long-wave laser (LWL), up to 10 km (6.2 mi); •...
Page 170: System Size And Weight
98 kg (216 lb) without media 384-port configuration with eight PB-48K-48 port blades Empty chassis 49 kg (108 lbs) • No blades • No CPs • No power supplies • No fan assemblie EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 171: System Blade And Fru Weights
Specifications System blade and FRU weights System FRU weights Table 25 Weight CP4 blade 3.1 kg (6.8 lbs) FC4-16 port blade 2.7 kg (6.0 lbs) without media FC4-32 port blade 3.1 kg (6.8 lbs) without media PB-48K-48 port blade 3.1 kg (6.8 lb) without media PB-48K-18i application blade 3.36 kg (7.4 lb) without media Filler panel...
Page 172: Facility Requirements
• The rack is balanced and mechanically secured to provide stability in the event of an earthquake. • Additional equipment does not exceed the rack’s weight limits. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 173: Power Specifications
Specifications Power specifications WARNING To remove all power from the ED-48000B, you must disconnect both power cables. The power subsystem is a redundant +48V DC power distribution system with a provision for up to four 1000-watt, 48V DC bulk power supplies.
Page 174: Power Cords
ED-48000B chassis has an IEC 60320/C19 cable connector. The two AC power receptacles on each ED-48000B chassis are equipped with IEC 60320/C20 power connectors. To order a power cord, contact your EMC service representative. Note: Regulatory compliance might not be complete for some countries listed (refer to “Regulatory compliance specifications”...
Page 175 Specifications Power cord types - International (continued) Table 27 Receptacle Style NEMA L6-20 USA, Canada, CEE-7/7 Mexico, other “Schuko” BS-1363A AS 3112 North American Continental United Kingdom/ Australia/New IEC-60309 locations Europe/Ireland Hong Kong Zealand 16A-6h, 230 V~ Country Czech, Rep. of Denmark Egypt England...
Page 176 Europe/Ireland Hong Kong Zealand 16A-6h, 230 V~ Country Malaysia Alternate Recommended Mexico Monaco Netherlands New Zealand Norway Poland Portugal Puerto Rico Russia Saudi Arabia Scotland Singapore South Africa Spain Sweden Switzerland Taiwan EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 177 Specifications Power cord types - International (continued) Table 27 Receptacle Style NEMA L6-20 USA, Canada, CEE-7/7 Mexico, other “Schuko” BS-1363A AS 3112 North American Continental United Kingdom/ Australia/New IEC-60309 locations Europe/Ireland Hong Kong Zealand 16A-6h, 230 V~ Country Turkey United Arab Emirate United Kingdom / Ireland...
Page 178: Environmental Requirements
If the internal temperature range exceeds the operating ranges of the components, the LEDs, error messages, and Fabric Watch alerts will indicate a problem. Use the tempShow command or Fabric Watch commands to view temperature status. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 179: Thermal Policy
Specifications Thermal policy At 32° Celsius or lower, fans operate at a low speed. When the chassis temperature reaches 33° Celsius, fan speed increases to high. If any blade within the chassis reaches 60° Celsius, the fan speed increases to high. If any blade reaches 65° Celsius, the blade is powered down. Environmental requirements...
Page 180: General Specifications
Less than 2 microseconds with no contention (destination port is free) Routing capacity A minimum aggregate routing capacity of four million frames per second (for Class 2, Class 3, and Class F frames in a 64-port switch) EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 181: Data Transmission Ranges
Specifications Data transmission ranges Table 30 provides the data transmission ranges for different cable types and port speeds. Table 30 Laser data transmission ranges Cable Size Extended Long Port Speed (microns) Short Wavelength Long Wavelength Wavelength 1 Gb/sec 1,640 feet (500 meters) 62.5 984 feet (300 meters) 6.2 miles (10 km)
Page 182: Fibre Channel Port Specifications
F_Ports (fabric ports), FL_Ports (fabric loop enabled), or E_Ports (expansion ports). The ports meet all required safety standards. For a listing of these standards, refer to “Regulatory compliance specifications” on page 186. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 183: Cp Blade Specifications
Specifications CP blade specifications CP blade specifications include: “Memory specifications” on page 183 “Battery specifications” on page 183 “Serial port specifications” on page 184 “Modem serial port specifications” on page 185 Memory specifications Each CP blade has the following memory: Main memory: 512 MB SDRAM (72 bits wide) Flash memory: •...
Page 184: Serial Port Specifications
9-pin subminiature-D connector. Use the pinouts listed in Table Terminal serial port pinouts Table 31 Signal Description ---- ---- TxData Transmit Data RxData Receive Data ---- ---- Logic Ground ---- ---- ---- ---- ---- ---- ---- ---- EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 185: Modem Serial Port Specifications
Specifications Modem serial port specifications Each CP blade has a modem serial port (labeled RS-232) with a fully RS-232 compliant DB-9 connector (see Figure 8 on page 61 location of port). Note: For dust and electrostatic discharge (ESD) protection, keep the cover on the serial port whenever the port is not in use.
Page 186: Regulatory Compliance Specifications
Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at the user’s own expense. MICstatement (Republic of Korea) EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 187: Vcci Statement
Specifications VCCI statement This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance might arise. When such trouble occurs, the user might be required to take corrective actions.
Page 188: Bsmi Statement (Chinese)
Specifications BSMI statement (Chinese) EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 189: Ce Statement
The standards compliance label on the ED-48000B contains the CE mark, which indicates that this system conforms to the provisions of the following European Council directives, laws, and standards: Electromagnetic Compatibility (EMC) Directive 89/336/EEC and the Complementary Directives 92/31/EEC and 93/68/EEC Low Voltage Directive (LVD) 73/23/EEC and the...
Page 190: Rtc Battery
Do not attempt to replace the real time clock (RTC) battery on the CP blade. There is danger of explosion if the battery is incorrectly replaced or disposed of. Contact your EMC service representative if the RTC begins to lose time.
Page 191 Specifications ED-48000B regulatory certifications (continued) Table 33 Country Safety specification EMC specification International IEC 60950+A1+A2+A3+A4+A11 EN55022 Class A European Union EN 60950:92 EN 55022:1998 Class A +A1:93+A2:93+A3:95+A4:96+A11:97 (Austria, Belgium, Cyprus, Czech EN 55024 (Immunity) Republic, Denmark, Estonia, Finland, 73/23/EEC EN 61000-4-2 Electrostatic Discharge...
Page 192 Specifications EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 193: Troubleshooting
Invisible Body Tag Troubleshooting For information about troubleshooting the entire fabric, refer to the Fabric OS Administrator’s Guide This appendix provides the following information: Overview ................... 194 Obtaining chassis and component status ........195 Interpreting POST and boot results..........196 Diagnostics..................
Page 194: Overview
198). Reboot the switch or power the entire chassis off/on. If the problem is still unresolved after these steps, contact your EMC Customer Service representative. The information required by your support provider in order to provide assistance is listed under “Where to get help”...
Page 195: Obtaining Chassis And Component Status
Troubleshooting Obtaining chassis and component status The CLI commands listed in Table 34 provide status and environmental information about the chassis and its components. These commands provide information only, and they do not interrupt traffic flow. For more information about these commands, refer to the Fabric OS Command Reference Manual.
Page 196: Interpreting Post And Boot Results
Fabric OS System Error Message Reference Manual. POST includes the following steps: 1. Preliminary POST diagnostics are run. 2. Operating system is initialized. 3. Hardware is initialized. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 197: Boot
Troubleshooting 4. Diagnostic tests are run on several functions, including circuitry, port functionality, ability to send and receive frames, all aspects of memory, parity, statistics counters, and serialization. Boot In addition to POST, boot includes the following steps after POST is complete: 1.
Page 198: Diagnostics
Fabric OS Administrator’s Guide and the Fabric OS Command Reference Manual. For information about system error messages (errShow or errDump), refer to the Fabric OS System Error Message Reference Manual. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 199: Troubleshooting The Ed-48000B
Troubleshooting Troubleshooting the ED-48000B Table 35 provides a list of issues, possible causes, and recommended actions. Table 35 Troubleshooting the ED-48000B Issue Possible cause Recommended action Entire chassis powers off automatically. Power supplies are inadequate to support Add an additional power supply. the installed components.
Page 200 Initial set up results in IP address/Domain The switch was connected to the fabric Refer to Chapter 3, ”Initial Configuration ID conflict. before being configured. Parameters,” and the for configuration information. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 201 Troubleshooting Troubleshooting the ED-48000B (continued) Table 35 Issue Possible cause Recommended action LEDs on one or more components are The ED-48000B might be booting or Verify that boot and POST are complete. changing rapidly or do not indicate a running POST. The ED-48000B requires a minimum of 3 healthy state.
Page 202 The component might have failed. Type the sensorShow command to determine component status. If component is a CP blade or port blade, type the slotShow command to determine status. Replace component as necessary EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 203: Port Numbering Template
Invisible Body Tag Port Numbering Template This chapter provides templates for recording the port numbering scheme for your ED-48000B director. Template .................... 204 Port Numbering Template...
Page 204: Port Numbering Template Template
ED-48000B director. For each 16-port blade installed in the director, cross out the extra 16 ports on the graphical representation of the port blade before you fill in the port numbers. EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 205 Port Numbering Template Link Link 10/100 Mb/s 10/100 Mb/s Active CP Active CP Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6 Slot 7 Slot 8 Slot 9 Slot 10 EMC Model FC4-32 port blades Figure 25 Template...
Page 206 Port Numbering Template s c al e: 5/ 16" = 1" EMC model PB-48K-18i AP blades Figure 26 EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 207 Port Numbering Template Link Link 10/100 Mb/s 10/100 Mb/s Active CP Active CP Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6 Slot 7 Slot 8 Slot 9 Slot 10 EMC model PB-48K-48 port blades Figure 27 Template...
Page 208 Port Numbering Template EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 209: Index
41 specification 183 Canada requirements 189 battery specifications 183 Canadian regulations 189 blades CE compliance 189 adding FC2-16 to director 143 CE statement 189 adding PB-48KB-18i to director 143 certifications EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 210 ED-48000B director blade support 141 electrical safety 190 label all the cables 147 EMC specifications 190 laser EMI rating 180 compliance with standards 189 environmental product class 189 requirements 178 laser compliance 189 environmental requirements 178 EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 211 180 Fibre Channel 182 RS-232 connector Ports modem serial port 185 Fibre Channel 168 terminal serial port 184 ports types of 168 battery 183, 190 POST RTC battery 190 interpreting 196 power EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 212 182 vibration 178 status port card 67 Supported Blade Installation Procedures 143 weight switch covers 35 for FRUs 171 switch name WWN bezel customizing 49 replacing 104 system WWN card performance 168 EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 213 Index bezel 68 installing 110 data stored on 67 replacing 104 determing status of 67 verifying need to replace 107 EMC Connectrix B Series ED-48000B Hardware Reference Manual...
Page 214 Index EMC Connectrix B Series ED-48000B Hardware Reference Manual...

This manual is also suitable for:

Ed-48000b

EMC Connectrix B Series Hardware Reference Manual

Preface

Chapter 1 Overview

Chapter 2 Installation, Setup, and Login

Chapter 3 Initial Configuration Parameters

Chapter 4 Monitor System Components

Chapter 5 Remove and Replace System Components

Chapter 6 Chassis Replacement

Chapter 7 Blade Support Notes

Chapter 8 Setting up and Installing Modems

Specifications

Appendix A Specifications

Troubleshooting

Appendix B Troubleshooting

Port Numbering Template Template

Appendix C Port Numbering Template

Index

Quick Links

Troubleshooting

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EMC Connectrix B Series

Summary of Contents for EMC Connectrix B Series

This manual is also suitable for:

Table of Contents
