EMC DS-4900B Hardware Reference Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

EMC Connectrix B Series
HARDWARE REFERENCE MANUAL
DS-4900B
Version 5.1
P/N 300-003-510
REV A01
EMC Corporation
Corporate Headquarters:
-
Hopkinton, MA 01748
9103
-
-
-
1
508
435
1000
www.emc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-4900B and is the answer not in the manual?

Questions and answers

Related Manuals for EMC DS-4900B

Summary of Contents for EMC DS-4900B

  • Page 1 EMC Connectrix B Series DS-4900B Version 5.1 HARDWARE REFERENCE MANUAL P/N 300-003-510 REV A01 EMC Corporation Corporate Headquarters: Hopkinton, MA 01748 9103 1000 www.emc.com...
  • Page 2 Copyright © 2001-2006 EMC Corporation. All rights reserved. Published May 2006 EMC believes the information in this publication is accurate as of its publication date. The information is subject to change without notice. THE INFORMATION IN THIS PUBLICATION IS PROVIDED "AS IS." EMC CORPORATION...
  • Page 3 (both customer and service) only. If you need to include such a block in your manual, please submit a request to Illustration and provide a sample for setting up copy. EMC Connectrix B Series DS-4900B Hardware Reference Manual...
  • Page 4 EMC Connectrix B Series DS-4900B Hardware Reference Manual...

  • Page 5: Table Of Contents

    Create an Ethernet connection..........2-10 Set the switch domain ID............2-10 Set the switch date and time ..........2-12 Synchronize local time with an external source....2-13 Correct the time zone of a switch ......... 2-13 EMC Connectrix B Series DS-4900B Hardware Reference Manual...
  • Page 6 Replacing the fan assembly............. 4-4 Chapter 5 Power Supply Replacement Power supply replacement............. 5-2 Time required................5-3 Items required ................5-4 Replacing a DS-4900B switch power supply ......5-4 Chapter 6 DS-4900B Specifications Switch components................6-2 Weight and physical dimensions........... 6-3 Facility requirements............... 6-4 Power supply specifications............
  • Page 7 MIC statement (Republic of Korea)........6-15 VCCI statement ..............6-15 BSMI statement (Chinese)............. 6-16 CE statement................6-17 Canadian requirements............6-17 Laser compliance..............6-17 RTC battery ................6-18 Electrical safety............... 6-18 Regulatory certifications ............6-19 Index ..........................i-1 EMC Connectrix B Series DS-4900B Hardware Reference Manual...
  • Page 8 Contents viii EMC Connectrix B Series DS-4900B Hardware Reference Manual...

  • Page 9: Preface

    Line Interface (CLI). As part of its effort to continuously improve and enhance the performance and capabilities of the EMC product line, EMC periodically releases new versions of the EMC Connectrix Departmental Switches and Enterprise Directors. Therefore, some functions described in this guide may not be supported by all versions of Fabric OS currently in use.
  • Page 10 This document is a procedures guide written to help storage access network (SAN) administrators like you configure and manage your SAN. This guide is part of the EMC Connectrix Departmental Switch and Enterprise Director documentation set. Readers of this guide are expected to be familiar with the Fabric OS operating environment used on the EMC Connectrix B Series switches and directors.
  • Page 11 Support clarification EMC may not support all of the functionality of the FOS 5.1 or the operating environment. References in this document to specific configurations, functionality, and capabilities of FOS OS 5.1 should not be interpreted to imply that EMC endorses or will support them.
  • Page 12 Preface For more information about EMC’s currently supported solutions, consult the current version of the EMC support matrices at: http://powerlink.EMC.com Consult the current version of Connectrix B Series release notes and product documentation at: http://powerlink.EMC.com What’s new in this The following changes were made since the last version of this...
  • Page 13 Note: For readability, command names in the narrative portions of this guide are presented in mixed letter casing: for example, switchShow. In actual examples, command letter casing is often all lowercase. EMC uses the following type style conventions in this guide: Keystrokes VANT...
  • Page 14 Technical support — For technical support, go to EMC WebSupport on Powerlink. To open a case on EMC WebSupport, you must be a WebSupport customer. Information about your site configuration and the circumstances under which the problem occurred is required.

  • Page 15: Introducing The Ds-4900B

    Invisible Body Tag Introducing the DS-4900B This chapter contains the following information: Overview of the DS-4900B..............1-2 Managing the DS-4900B ..............1-6 Supported features................1-7 Introducing the DS-4900B...

  • Page 16: Overview Of The Ds-4900B

    Ports on demand The DS-4900B has 64 ports. By default, ports 0 through 31 are enabled. To enable additional ports, you must install Ports On Demand (POD) licenses. The ports on demand license enables ports in 16 port increments.

  • Page 17: Port Side Of The Ds-4900B

    Introducing the DS-4900B Port Side of the DS-4900B Figure 1-1 shows the port side of the DS-4900B. Scale: 1/8" = 1" ra c in . fo r /6 4 g th le n s c re x im g to...

  • Page 18: Nonport Side Of The Ds-4900B

    ISLs between adjacent switches. For more information about ISL Trunking, see the Fabric OS Administrator’s Guide. The port side of the DS-4900B also displays the system status LED, power status LED, and port status LEDs ( Figure 3-1 on page 3-3).
  • Page 19 /6 4 in . Scale: 5/16" = 1" Nonport side of the DS-4900B Figure 1-3 Where: DS-4900B Fan Assembly #2 Nonport Side of Switch Fan Assembly #1 Power Supply #2 Power Supply #1...

  • Page 20: Managing The Ds-4900B

    Introducing the DS-4900B Managing the DS-4900B You can use the management functions built into the DS-4900B to monitor the fabric topology, port status, physical status, and other information to help you analyze switch performance and to accelerate system debugging. The DS-4900B automatically performs power-on self-test (POST) each time it is turned on.

  • Page 21: Supported Features

    0-7, 8-15, 16-23, 24-31, 32-39, 40-47, 48-55, and 56-63. There are 16 user ports per Condor ASIC on the DS-4900B. They are divided as follows: port numbers 0-15, 16-31, 32-47, and 48-63. The distinction between trunk groups and ASIC groups is important for Trunking over long distance, where the ASIC restrictions determine the number of and length of the long distance links.

  • Page 22: Trunking Over Long Distances

    5-port trunk per Condor ASIC one 2-port trunk per Condor ASIC LD – 200 km one 2-port trunk per Condor ASIC LD 250 km one 2-port trunk per Condor ASIC LD 500 km EMC Connectrix B Series DS-4900B Hardware Reference Manual...

  • Page 23: Max Number Of Long Distance Ports

    Max number of long distance ports This section lists the maximum number of long distance ports for the DS-4900B. There are 16 ports per Condor ASIC on the DS-4900B. They are divided as follows: port numbers 0-15, 16-31, 32-47, and 48-63.
  • Page 24 Introducing the DS-4900B 1-10 EMC Connectrix B Series DS-4900B Hardware Reference Manual...

  • Page 25: Installing And Configuring The Ds-4900B

    Configuring the DS-4900B This chapter provides the following information: Installation and safety considerations ..........2-2 Items included with the DS-4900B ..........2-4 Setting up as a stand-alone unit............2-5 Installing in an EIA cabinet ..............2-6 Initial setup of the DS-4900B ............2-7 Recommendations for cable management ........2-18...

  • Page 26: Installation And Safety Considerations

    Installing and Configuring the DS-4900B Installation and safety considerations You can install the DS-4900B in the following ways: As a standalone unit on a flat surface. For instructions and more information, see “Setting up as a stand-alone unit” on page 2-5.
  • Page 27 Installing and Configuring the DS-4900B Verify that the additional weight of the switch does not exceed the cabinet’s weight limits or unbalance the cabinet in any way. Secure the cabinet to ensure stability in case of unexpected movement. Installation and safety considerations...

  • Page 28: Items Included With The Ds-4900B

    • One RJ-45 serial cable cable, 10-ft (approximately 3 m) long. The DS-4900B uses an RJ-45 connector for the serial port. An RJ-45 to DB9 adaptor is also provided with the switch. EMC Connectrix B Series DS-4900B Hardware Reference Manual...

  • Page 29: Setting Up As A Stand-Alone Unit

    Installing and Configuring the DS-4900B Setting up as a stand-alone unit The DS-4900B can be configured as a standalone unit, which means that it resides outside of a rack. To configure the DS-4900B as a standalone unit: 1. Unpack the DS-4900B and verify that all ordered items are present.

  • Page 30: Installing In An Eia Cabinet

    Installing and Configuring the DS-4900B Installing in an EIA cabinet The DS-4900B can be installed into an EIA cabinet using an optionally available rack mount kit. Refer to the documentation that is shipped with the rack kit for installation instructions.

  • Page 31: Initial Setup Of The Ds-4900B

    SFP transceivers and compatible fibre cables, as required Access to an FTP server, for backing up (uploading) or downloading the switch configuration To configure the DS-4900B, you must perform the following tasks: “Provide power to the switch” on page 2-8 “Create a serial connection” on page 2-8 “Connect to the switch using the serial connection”...

  • Page 32: Provide Power To The Switch

    LEDs on the left of the port side of the switch are green. Create a serial connection To create a serial connection to the DS-4900B: 1. Remove the plug from the serial port and insert the serial cable provided with the DS-4900B.

  • Page 33: Connect To The Switch Using The Serial Connection

    Installing and Configuring the DS-4900B Flow control: None • In a UNIX environment, enter the following command at the prompt: tip /dev/ttyb -9600 Connect to the switch using the serial connection To log in to the switch through the console port: 1.

  • Page 34: Create An Ethernet Connection

    (Figure 1-1 on page 1-3). Create an Ethernet connection To create an Ethernet connection to the DS-4900B: 1. Remove the protection plug from the Ethernet port. 2. Connect an Ethernet cable from the switch Ethernet port to a network Ethernet hub.
  • Page 35 Installing and Configuring the DS-4900B e. Complete the remaining prompts or press Ctrl-D to accept the remaining settings without completing all the prompts. f. Reenable the switch by entering the switchEnable command. 3. Optionally, specify any custom status policies: a. Enter the switchStatusPolicySet command at the prompt. This command sets the policy parameters that determine overall switch status.

  • Page 36: Set The Switch Date And Time

    Year values greater than 69 are interpreted as 1970-1999; year values less than 70 are interpreted as 2000-2069. The date function does not support Daylight Savings Time or time zones, so changes will have to be reset manually. 2-12 EMC Connectrix B Series DS-4900B Hardware Reference Manual...

  • Page 37: Synchronize Local Time With An External Source

    Installing and Configuring the DS-4900B switch:admin> date Fri May 5 21:50:00 UTC 1989 switch:admin> switch:admin> date "0624165203" Tue Jun 24 16:52:30 UTC 2003 switch:admin> For more information, refer to the Fabric OS Command Reference Manual. Synchronize local time with an external source...
  • Page 38 -5,0 Eastern Daylight -4,0 Central Standard -6,0 Central Daylight -5,0 Mountain Standard -7,0 Mountain Daylight -6,0 Pacific Standard -8,0 Pacific Daylight -7,0 Alaskan Standard -9,0 Alaskan Daylight -8,0 Hawaiian Standard -10,0 2-14 EMC Connectrix B Series DS-4900B Hardware Reference Manual...

  • Page 39: Verify Correct Operation And Backup The Configuration

    Installing and Configuring the DS-4900B Verify correct operation and backup the configuration To verify correct operation and backup the switch configuration: 1. Check the LEDs to verify that all components are functional. For information about LED patterns, see “Interpreting LED activity”...
  • Page 40 F-Port 10:00:00:00:00:00:00:02 SW4900:admin> 3. Use the fabricShow command to verify fabric connectivity. 4. Back up the switch configuration to an FTP server by typing the configUpload command and following the prompts. 2-16 EMC Connectrix B Series DS-4900B Hardware Reference Manual...
  • Page 41 Installing and Configuring the DS-4900B EMC recommends backing up the configuration on a regular basis to ensure that a complete configuration is available as backup. For specific instructions about how to back up the configuration, see the Fabric OS Administrator’s Guide. The switchShow, fabricShow, and configUpload commands are described in detail in the Fabric OS Command Reference Manual.

  • Page 42: Recommendations For Cable Management

    For easier maintenance, label the fiber-optic cables and record the devices to which they are connected. Keep LEDs visible by routing port and other cables directly down or otherwise away from the LEDs. 2-18 EMC Connectrix B Series DS-4900B Hardware Reference Manual...
  • Page 43 Invisible Body Tag Operating the DS-4900B This chapter contains the following information: Interpreting LED activity ..............3-2 Interpreting POST results ..............3-8 Maintaining the DS-4900B ..............3-9 Powering off the DS-4900B .............3-10 Operating the DS-4900B...

  • Page 44: Interpreting Led Activity

    Fibre Channel ports. The port LEDs are located in the array in the same relative positions as the ports. Figure 3-1 on page 3-3 shows the port side of the DS-4900B. EMC Connectrix B Series DS-4900B Hardware Reference Manual...
  • Page 45 Operating the DS-4900B Scale: 1/4" = 1" IOIOI IOIOI Figure 3-1 LEDs on Port Side of the DS-4900B DS-4900B Port 0 Status LED System Status LED Port 4 Status LED System Power LED Ports 0 through 7 Console Port Port 32 Status LED...
  • Page 46 There is no link. Verify that the Ethernet cable is connected correctly. Steady amber There is a link. No action required. Flashing amber/no There is link activity (traffic). No action required. light EMC Connectrix B Series DS-4900B Hardware Reference Manual...
  • Page 47 Check the management interface and (flashing in the error log for details on the cause of half-second status. intervals) Contact your EMC Customer Service Representative. Steady amber (for Port is receiving light or signal carrier at No action required. more than 5 4 Gbit/sec;...

  • Page 48: Leds On The Nonport Side Of The Switch

    Fan Assembly #3 Status LED Fan Assembly #2 Fan Assembly #2 Status LED Fan Assembly #1 Fan Assembly #1 Status LED Table 3-2 on page 3-7 describes the LEDs on the nonport side of the switch. EMC Connectrix B Series DS-4900B Hardware Reference Manual...
  • Page 49 Check the power cable connection Power supply is switched off Verify that the power supply is powered on The power cable is disconnected Contact your EMC Customer Service The power supply has failed Representative to replace the power supply FRU.

  • Page 50: Interpreting Post Results

    For more information about this command, see the Fabric OS Command Reference Manual. For information about specific error messages, see the Fabric OS System Error Message Reference Manual. EMC Connectrix B Series DS-4900B Hardware Reference Manual...

  • Page 51: Maintaining The Ds-4900B

    Operating the DS-4900B Maintaining the DS-4900B The DS-4900B is designed for high availability and low failure; it does not require any regular physical maintenance. It includes diagnostic tests and field-replaceable units, described in the following sections. Diagnostic tests In addition to POST, Fabric OS includes diagnostic tests to help you troubleshoot the hardware and firmware.

  • Page 52: Powering Off The Ds-4900B

    In Web Tools, click the Fan Status icon. Powering off the DS-4900B To power off the DS-4900B: 1. Run the sysShutdown command. 2. Set each AC power switch to “0”. 3-10 EMC Connectrix B Series DS-4900B Hardware Reference Manual...

  • Page 53: Chapter 4 Fan Assembly Replacement Procedure

    Invisible Body Tag Fan Assembly Replacement Procedure This chapter contains information for replacing the fan assembly in a DS-4900B. Fan assembly replacement..............4-2 Fan Assembly Replacement Procedure...

  • Page 54: Fan Assembly Replacement

    Fan assembly replacement Fan assembly replacement should be performed by an EMC Customer Service Representative. Note: Customer servicing of the DS-4900B could result in the voiding of the warranty or service agreement. The DS-4900B switch has three fan assemblies as displayed in Figure 4-1.

  • Page 55: Time Required

    One or more of the fan(s) in the fan assembly has replaced. failed The fan FRU was disabled by the user Time required Replacing a fan assembly in the DS-4900B switch should take less than two minutes. Fan assembly replacement...

  • Page 56: Items Required

    Fan Assembly Replacement Procedure Items required You need the following items to replace a fan assembly in a DS-4900B: DS-4900B switch New fan FRU assembly Phillips-head screwdriver #1 Replacing the fan assembly To replace a fan assembly in a DS-4900B: 1.
  • Page 57 Fan assembly #1, Fan assembly #2, and Fan assembly #3). scale: 1/4" = 1" scale: 1/4" = 1" Scale: 3/8" = 1" Inserting the fan assembly in the DS-4900B Figure 4-2 DS-4900B Status LED Fan assembly unit Handle...
  • Page 58 Fan Assembly Replacement Procedure EMC Connectrix B Series DS-4900B Hardware Reference Manual...

  • Page 59: Chapter 5 Power Supply Replacement

    Invisible Body Tag Power Supply Replacement This chapter contains information on replacing the power supply in a DS-4900B. Power supply replacement ...............5-2 Power Supply Replacement...
  • Page 60 Power supply replacement Power supply replacement should be performed by the EMC Customer Service Representative. Note: Customer servicing of the DS-4900B could result in the voiding of the warranty or service agreement. The DS-4900B switch has two power supplies, as displayed in Figure 5-1.

  • Page 61: Time Required

    The power supply has failed When the switch is first powered on the power supply status LED will show amber until POST has completed. Time required Replacing a power supply in the DS-4900B should take less than two minutes. Power supply replacement...

  • Page 62: Items Required

    Orient the power supply as shown in Figure 5-2 on page 5-5, with the AC power switch on the left. b. Gently push the power supply into the chassis until it is firmly EMC Connectrix B Series DS-4900B Version 5.1 Hardware Reference Manual...
  • Page 63 Power Supply Replacement c. Secure the power supply to the chassis by screwing in the captive screw using the Phillips-head screwdriver. 7. Plug the power cord in to the power supply and power on the switch by pressing the AC power switch to the “1” symbol. 8.
  • Page 64 Power Supply Replacement Connectrix B Switch Status LED Power supply AC Power receptacle Captive screw AC Power switch Handle EMC Connectrix B Series DS-4900B Version 5.1 Hardware Reference Manual...
  • Page 65 Switch components................6-2 Weight and physical dimensions .............6-3 Facility requirements .................6-4 Power supply specifications.............6-5 Environmental requirements............6-6 General specifications................6-7 Data transmission ranges..............6-9 Memory specifications ..............6-10 Fibre Channel port specifications ..........6-11 Serial port specifications ..............6-12 POST and boot specifications............6-13 Regulatory compliance..............6-14 DS-4900B Specifications...

  • Page 66: Switch Components

    They default to high speed upon boot, then switch to low speed as the Fabric OS comes online, returning to high speed only as required. EMC Connectrix B Series DS-4900B Version 5.1 Hardware Reference Manual...

  • Page 67: Weight And Physical Dimensions

    DS-4900B Specifications Weight and physical dimensions Table 6-1 lists the weight and dimensions of the DS-4900B switch. Table 6-1 Physical specifications Dimension Value Height 2U or 8.6 cm (3.4 in.) Depth 61 cm (24 in.) Width 42.8 cm (16.8 in.) Weight (with two power supplies, three fan assemblies, and 13.7 kg (30.2 lb)

  • Page 68: Facility Requirements

    • The additional weight of the switch must not exceed the cabinet’s weight limits • The cabinet must be secured to ensure stability in case of unexpected movement EMC Connectrix B Series DS-4900B Version 5.1 Hardware Reference Manual...

  • Page 69: Power Supply Specifications

    Each power supply has a built-in fan for cooling, pushing air towards the port side of the switch. Table 6-2 lists the power supply specifications for the DS-4900B switch. Power supply specifications Table 6-2...

  • Page 70: Environmental Requirements

    20 G, 6 ms, half-sine wave 15 G, 12-18 milliseconds, trapezoid Vibration 0.5 G, 5-500 Hz 2.0 G, 5-500 Hz Air flow 54.02 cu ft/min (42.5 cu m/hr) None required. EMC Connectrix B Series DS-4900B Version 5.1 Hardware Reference Manual...

  • Page 71: General Specifications

    Specification Description Configurable port types F_Port, FL_Port, and E_Port EMC (electromagnetic compatibility) The DS-4900B complies with the following regulatory EMC requirements: Emissions FCC Rules & Regulations, Part 15 subpart B, Class A CSA C108.8 Class A VCCI Class A ITE...
  • Page 72 Aggregate switch I/O bandwidth 512 Gbit/sec if all 64 ports are running at 4 Gbit/sec, full duplex Port-to-port latency Less than 2 microseconds with no contention (destination port is free) EMC Connectrix B Series DS-4900B Version 5.1 Hardware Reference Manual...

  • Page 73: Data Transmission Ranges

    DS-4900B Specifications Data transmission ranges Table 6-5 provides the data transmission ranges for different cable types and port speeds. Table 6-5 Laser data transmission ranges Cable size Extended long Port speed (microns) Short wavelength (SWL) Long wavelength (LWL) wavelength (ELWL)

  • Page 74: Memory Specifications

    DS-4900B Specifications Memory specifications The DS-4900B has three types of memory devices: Boot flash – 4 MB Compact flash – 512 MB Main memory (DDR SDRAM) – 256 MB 6-10 EMC Connectrix B Series DS-4900B Version 5.1 Hardware Reference Manual...

  • Page 75: Fibre Channel Port Specifications

    DS-4900B Specifications Fibre Channel port specifications The Fibre Channel ports in the DS-4900B are compatible with SWL, LWL, and ELWL SFP transceivers. The strength of the signal is determined by the type of transceiver in use. The ports meet all required safety standards. For more information about these standards, see “Regulatory compliance”...

  • Page 76: Serial Port Specifications

    DS-4900B Specifications Serial port specifications The serial port is located on the port side of the switch. The DS-4900B uses an RJ-45 connector for serial port. An RJ-45 to DB9 adaptor cable is also provided with the switch. Note: To protect the serial port from damage, keep the cover on the port when not in use.

  • Page 77: Post And Boot Specifications

    DS-4900B Specifications POST and boot specifications The switch performs POST by default each time it is powered on or rebooted or the system is reset. Boot time with POST is usually about 1 to 3 minutes. POST can be skipped after subsequent reboots by entering the fastBoot command.

  • Page 78: Regulatory Compliance

    Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at the user’s own expense. 6-14 EMC Connectrix B Series DS-4900B Version 5.1 Hardware Reference Manual...

  • Page 79: Mic Statement (Republic Of Korea)

    DS-4900B Specifications MIC statement (Republic of Korea) VCCI statement This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance might arise. When such trouble occurs, the user might be required to take corrective actions.

  • Page 80: Bsmi Statement (Chinese)

    DS-4900B Specifications BSMI statement (Chinese) 6-16 EMC Connectrix B Series DS-4900B Version 5.1 Hardware Reference Manual...

  • Page 81: Ce Statement

    The standards compliance label on the DS-4900B contains the CE mark which indicates that this system conforms to the provisions of the following European Council directives, laws, and standards:...

  • Page 82: Rtc Battery

    This product is designed for an IT power system with phase-to-phase voltage of 230V. After operation of the protective device, the equipment is still under voltage if it is connected to an IT power system. 6-18 EMC Connectrix B Series DS-4900B Version 5.1 Hardware Reference Manual...

  • Page 83: Regulatory Certifications

    DS-4900B Specifications Regulatory certifications Table 6-7 lists the safety and EMC (electromagnetic compatibility) specifications for which the DS-4900B is certified. EMC Certifications Table 6-7 Country Safety specification EMC specification Canada CSA 22.2 No. 60950 Third Ed. CSA 108.8 Class A United States UL 60950 Third Ed., Info.
  • Page 84 DS-4900B Specifications 6-20 EMC Connectrix B Series DS-4900B Version 5.1 Hardware Reference Manual...

  • Page 85: Index

    DS-4900B EIA cabinet 4-10 4-10 electrical safety laser compliance environmental requirements LEDs on the nonport side of the switch LEDs on the port side of the switch facility requirements EMC Connectrix B Series DS-4900B Hardware Reference Manual...
  • Page 86 4-10 RTC battery serial port specifications set the switch date and time set the switch domain ID set the switch IP address setting up as a standalone unit EMC Connectrix B Series DS-4900B Hardware Reference Manual...
