Camber - SORG Boogie Drive Service Record

3.1 Assembly Group Wheels

3.1.2 Camber

We mount the wheels according to your specifications to the desired camber. With the camber
you can change the distance at the top between the driving wheels.
Picture 1 shows each row (1-3) of the quick re-
lease axle for the appropriate wheel size (see
chart below) as well as the appropriate attach-
ment (A, B, C, D) of the axle plate in the axle
plate holder.
Picture 2 shows the bore picture for the possib-
le camber setting for frame size 1 and 2,
Picture 3 shows the bore picture for the possib-
le camber setting for frame size 3 and 4.
(4) To change the camber remove the driving
wheels and secure the mobile standing device
from rolling away with the wheel locks of the
back casters.
• Remove on both sides both screws (A).
• Remove on both sides both screws (B).
• Move the axle plate (C) in the axle plate
holder (D) corresponding to the details
on the basis of the chart below.
• Replace all of the screws and tighten
them and replace the wheels.
Frame size 1
wheel size camber position wheel size camber position
3°
6°
24"
9°
12°
3°
6°
26"
9°
12°
3°
6°
28"
9°
12°
Frame size 3
wheel size camber position
0°
3°
32"
6°
9°
0°
3°
36"
6°
9°
10 of 36
Frame size 2
3A 3°
3A 6°
28"
3B 9°
3C 12°
2A 3°
2A 6°
30"
2B 9°
2C 12°
1A 3°
1A 6°
32"
1B 9°
1C 12°
3A
3A
3B
3C
1A
1A
1B
1C
Service Record Boogie Drive
(1)
A
B
C
D
A
B
C
D
(2)
9°
12°
(3)
3B
3C
3C
6°
3D
9°
2A
2A
2B
2C
1A
1A
(4)
1B
1C
(A)
(D)
(C)
(B)
1
2
3
3°
6°
0°
3°
