  • Page 1 Service Record Boogie Drive Service Record...

  • Page 2: Revision Status

    We are a member of rehaKIND e.V. International association child and adolescent rehabilitation COPYRIGHT © by SORG Rollstuhltechnik GmbH + Co. KG Benzstraße 3-5, 68794 Oberhausen-Rheinhausen. All texts and pictures in this user manual underlie the international copyright protection and are not allowed to be published without our consent –...

  • Page 3: Table Of Contents

    Service Record TABLE OF CONTENT TRUSS PAD 2.6.1 Height of the chest truss pad IMPRINT 2.6.2 Angle of the chest truss pad REVISION STATUS 2.6.3 Side chest truss pad TECHNICAL STATUS ASSEMBLY GROUP PELVIC TRUSS REHAKIND PADS COPYRIGHT 2.7.1 Adjusting the height CERTIFICATION 2.7.2 Adjusting the width...

  • Page 4: Overview Mobile Standing Device

    Boogie Drive OVERVIEW MOBILE STANDING DEVICE chest truss pad therapy table toy box crank for posterior truss pad with swivel bracketl side posterior truss pad centre column frame drum brake hub profiel wheel 10. built in handrim 11. side chest truss pad 12.

  • Page 5: Preamble

    93/42/EWG. Furthermore, during transportation. SORG Rollstuhltechnik is certified according to the Quality Management System ISO 9001. With this, the quality of our CONFIRMATION OF RECEIPT wheelchairs is ensured and documented from development � INDICATION to assembly in each step.

  • Page 6: Documentation

    Boogie Drive ATTENTION ATTENTION Only original parts are to be used for all service and All parts of the mobile standing device are to be handled maintenance work. with care. Removable parts are not to be thrown or dropped! ATTENTION...

  • Page 7: General Safety Instructions

    Service Record LOADING AND TRANSPORTING GENERAL SAFETY INSTRUCTIONS ATTENTION ATTENTION WHEN LOADING AND TRANSPORTING THE MOBILE The references to possible risks that occur form the STANDING DEVICE IN A VEHICLE ALL DEMOUNTED/ use of the wheelchair/mobile standing device and are LOOSE PARTS OF IT MUST BE STOWED AND TIED UP directed to the user, are in the user manual.

  • Page 8: Adjustments Assembly Group Wheels

    Boogie Drive ADJUSTMENTS ASSEMBLY GROUP WHEELS 2.1.1 Wheel position The chart below shows which distances and dimensions with which body height and with which driving wheel are possible. The chart on the next page (page 9) explains, where the quick release axle fittings and the axle plate need to be mounted when the wheel size and/or the camber is changed.

  • Page 9: Camber

    Service Record 2.1.2 Camber We mount the wheels according to your specifications to the desired camber. With the camber you can change the distance at the top between the driving wheels (for the possible measurements see chapter 2.1.1). Picture 1 shows each row (1-3) of the quick release axle for the appropriate wheel size (see chart below) as well as the appropriate attachment (A, B, C, D) of the axle plate in the axle plate holder.

  • Page 10: Sprung Back Casters

    Boogie Drive 2.1.3 Sprung back casters If the mobile standing device is used in an area without thresholds, it is recommended to set the wheels so that each wheel has contact with the ground. If you need to overcome doorways or the like more frequently, it is recommended to set the back casters so that the front casters are not touching the ground.

  • Page 11: Assembly Group Centre Column

    Service Record ASSEMBLY GROUP CENTRE COLUMN The centre column can be set and adjusted in angle and with frame size 1 it can also be adjusted in height. 2.2.1 Height adjustment of the centre column with frame size 1 Should it become necessary to move the centre column down: •...

  • Page 12: Assembly Group Standard Foot Plates

    Boogie Drive ASSEMBLY GROUP STANDARD 2.3.2 Positioning the standard foot plates (4) Zum Anpassen der Position nach vorne/hinten: FOOT PLATES • Loosen the four screws (A). • Remove the four screws (B) and move the foot (1+2) With the position of the foot plate holder, the...

  • Page 13: Assembly Group 3D Foot Plates With Angle Adjustment

    Service Record ASSEMBLY GROUP 3D FOOT 2.4.4 Setting the depth of the 3D foot plates (1) To set the depth: PLATES WITH ANGLE ADJUSTMENT • Loosen the set screw (B) and completely remove 2.4.1 Setting the angle of the 3D foot plates the foot plate bracket (D).

  • Page 14: Assembly Group Chest

    Boogie Drive ASSEMBLY GROUP CHEST TRUSS INFORMATION The truss pads can be equipped with either set screws or clamp levers. In the following chapters the setting process will be described according to the respective picture. Should your mobile standing device be equipped differently then please proceed correspondingly.

  • Page 15: Assembly Group Pelvic Truss Pads

    Service Record ASSEMBLY GROUP PELVIC TRUSS PADS INFORMATION The truss pads can be equipped with either set screws or clamp levers. In the following chapters the setting process will be described according to the respective picture. Should your mobile standing device be equipped differently then please proceed correspondingly.

  • Page 16: Assembly Group Posterior Truss Pad Pluggable

    Boogie Drive ASSEMBLY GROUP POSTERIOR TRUSS PAD PLUGGABLE ATTENTION THE POSTERIOR TRUSS PAD MUST HAVE BEEN SET TO THE INDIVIDUAL MEASUREMENTS OF THE CHILD/ ADOLESCENT AS EXACT AS POSSIBLE BEFORE THE FIRST USE OF THE MOBILE STANDING DEVICE. WHEN THE USER IS STANDING IN THE MOBILE STANDING DEVICE, ONLY FINE ADJUSTMENTS ARE THEN ALLOWED TO BE MADE.

  • Page 17: Assembly Group Posterior Truss Pad With Crank And Swivel Bracket

    Service Record ASSEMBLY GROUP POSTERIOR TRUSS PAD WITH CRANK AND SWIVEL BRACKET ATTENTION THE POSTERIOR TRUSS PAD MUST HAVE BEEN SET TO THE INDIVIDUAL MEASUREMENTS OF THE CHILD/ ADOLESCENT AS EXACT AS POSSIBLE BEFORE THE FIRST USE OF THE MOBILE STANDING DEVICE. WHEN THE USER IS STANDING IN THE MOBILE STANDING DEVICE, ONLY FINE ADJUSTMENTS ARE THEN ALLOWED TO BE MADE.

  • Page 18: Assembly Group Standard Knee Truss Pads

    Boogie Drive 2.10 ASSEMBLY GROUP STANDARD KNEE TRUSS PADS ATTENTION THE KNEE TRUSS PADS MUST HAVE BEEN SET TO THE INDIVIDUAL MEASUREMENTS OF THE CHILD/ ADOLESCENT AS EXACT AS POSSIBLE BEFORE THE FIRST USE OF THE MOBILE STANDING DEVICE. WHEN THE USER IS STANDING IN THE MOBILE STANDING DEVICE, ONLY FINE ADJUSTMENTS ARE THEN ALLOWED TO BE MADE.

  • Page 19: Assembly Group Knee Truss

    Service Record 2.11 ASSEMBLY GROUP KNEE TRUSS PADS WITH RESTING BRACKETS ATTENTION THE KNEE TRUSS PAD MUST HAVE BEEN SET TO THE INDIVIDUAL MEASUREMENTS OF THE CHILD/ ADOLESCENT AS EXACT AS POSSIBLE BEFORE THE FIRST USE OF THE MOBILE STANDING DEVICE. WHEN THE USER IS STANDING IN THE MOBILE STANDING DEVICE, ONLY FINE ADJUSTMENTS ARE THEN ALLOWED TO BE MADE.

  • Page 20: Assembly Group Therapy Table

    Boogie Drive 2.12 ASSEMBLY GROUP THERAPY TABLE The therapy table is attached to the centre column ex works (standard assembly). However, it can be varied in height and also attached to the chest truss pad holder.. 2.12.1 Standard mounting (1) To adjust the height: •...

  • Page 21: Assembly Group Frame

    Service Record 2.13 ASSEMBLY GROUP FRAME 2.13.1 Frame size 1 and 2 (gas pressure spring or telescope) (1) To widen the frame by 4 cm • we recommend to remove the centre column. • Remove the driving wheels. • Remove at first only on one side the screws (A) on the frame crossbar (B).

  • Page 22: Technical Data

    Boogie Drive TECHNICAL DATA MEASURMENTS AND DIMENSIONS Dimension tolerance ±5° Abbreviations: FW = frame width AIN = Aid Index Number Data Model: Boogie Drive AIN: 28.29.01.3010 (according to the AIN, the mobile standing device must be mounted with foot shells)

  • Page 23: Meaning Of Labels

    CE sign capacity year of manufacture DECLARATION OF CONFORMITY SORG Rollstuhltechnik GmbH & Co.KG Benzstraße 3-5 D-68794 Oberhausen-Rheinhausen Tel.: +49 7254 9279.0 Fax: +49 7254 9279.10 e-mail: info@sorgrollstuhltechnik.de Web: www.sorgrollstuhltechnik.de declares with this in sole responsibility, that the following aid BOOGIE DRIVE Type Nr.: 884 (size I to III)

  • Page 24: Retailer Verification

    Boogie Drive RETAILER VERIFICATION This aid has been delivered by the following retailer: SORG Rollstuhltechnik GmbH + Co. KG Benzstraße 3-5 D-68794 Oberhausen-Rheinhn. Tel +49 7254 9279.0 Fax +49 7254 9279.10 info@sorgrollstuhltechnik.de www.sorgrollstuhltechnik.de Technical changes and misprints reserved.
