3.2 Assembly Group Centre Column
Angle adjustment of the centre column by gas
pressure spring
For frequent angle adjustment of the the centre
column (e.g. for alternating load) it is recom-
mended to adjust the angle with a gas pressure
spring.
(1) To change the angle:
• Secure the mobile standing device from
rolling away by operating all wheel locks
(see above).
• Carefully operate the foot lever (A) of
the gas pressure spring (B) and place
the centre column in the desired tilt.
• Secure the user (with/without the help
of a carer) with both hands at the same
time.
• Release the foot lever.
The angle adjustment of the centre column can only take place when the mobile standing
device is still and with activated wheel locks (drum brakes and back casters).
2019-07-16
(1)
Service Record Boogie Drive
(B)
(A)
