Absolute Rotary Encoder
Programmable Parameters
Subindex
0h
Table 9.44
The limit switch, max sets Bit 31=1 with the next message telegram, if the process value
reaches or passes under the value of the limit switch:
Function
Bit
9.5.32

Object 2160h: Customer Storage

This object provides for the customer the possibility to store any value.
Subindex
0h
1h
2h
3h
4h
Table 9.45
9.5.33

Object 2200h: Cyclic Timer PDO

This object contains cyclic time of the event timer in ms (of PDO 1).
Subindex
0h
Table 9.46
The object 2200h is hard-wired to the objects 1800h subindex 5h and 6200h and provide the
cycle time for the cyclic mode. (See chapter Cycle Timer and Event Timer)
9.5.34

Object 2300h: Save Parameter with Reset

With this object all parameters can be stored in the non volatile memory. After storing the
parameters a reset is executed.
Subindex
0h
Table 9.47
Description Data Type
Limit Switch, max. Unsigned 32
Status bits
31
1
Description Data Type
Number of sub Unsigned 8
indices
Customer Storage 1 Unsigned 32
Customer Storage 2 Unsigned 32
Customer Storage 3 Unsigned 32
Customer Storage 4 Unsigned 32
Description Data Type
Event Time in ms Unsigned 16
Description Data Type
Acess code Unsigned 32
Default Value Access
0h rw
Process value
30 29 ... 0
0 x ... x
Default Value Access
4h ro
rw
rw
rw
rw
Default Value Access
0h ro
Default Value Access
55AAAA55h wo
Restore after
Boot up
yes
Restore after
Boot up
Restore after
Boot up
yes
Restore after
Boot up
no
