Absolute Rotary Encoder
Quick Start Guide
3. If necessary activate the terminator of the encoder by setting the relevant switch in the bus
cover.
4. If "Bd = 9" continue by reading and writing data into the relevant following objects.
Message received from Encoder on Boot up
Identifier
NN = 20h
700h + NN =
720h
Table 7.1
NN = node number of encoder
Configuration of Node Number
Object 3000h
Example:
Resulting node number = Value in object 3000h + 1h = Ah + 1h = Bh
The encoder itself adds the value 1 to the configured node number. This method is used to
prevent an identifier value of 0.
Message sent to Encoder
Identifier
NN = 20h
600h + NN
= 620h
Table 7.2
Message received from Encoder
Identifier
NN
580h + NN
= 5A0h
Table 7.3
Configuration of Baud Rate (only if auto baud feature is not used)
Object 3001h
Example: 500 kBd >> 05
Message sent to Encoder
Identifier
NN = 20h
600h + NN
= 620h
Table 7.4
24
Service/Process data
Byte 0 Byte 1 Byte 2
00
DLC Command Index
Download 3000h
8h 22h 00h
DLC Command Index
Download 3000h
8h 60h 00h
DLC Command Index
Download 3001h
8h 22h 01h
Byte 3 Byte 4 Byte 5
Subindex Service/Process data
00h Byte 4 Byte 5 Byte 6 Byte 7
30h 00h 0Ah
Subindex Service/Process data
00h Byte 4 Byte 5 Byte 6 Byte 7
30h 00h 00h
Subindex Service/Process data
00h Byte 4 Byte 5 Byte 6 Byte 7
30h 00h 05h
Byte 6 Byte 7
00h 00h 00h
00h 00h 00h
00h 00h 00h
