Definition. Z4 is a
Wavetronix-specific
protocol that lets
sensors talk to other
Wavetronix devices,
mostly contact
closure devices.
Note. The Loop
Emulation settings
are found on the
Settings screen and
covered in chapter 6.
88
SmartSensor HD User Guide
•
for pushing data, you might want to use a different port when con-
necting to the sensor.
4
Choose which format you want the pushed data in.
Setting Description
All three pushed data types
HD
Native SmartSensor HD
(SS125) format.
SS105 Simple
Emulates the original
SmartSensor (SS105)
format, without a multi-
drop header.
SS105
Emulates the original
Multidrop
SmartSensor (SS105)
format, with a multi-drop
header.
Event data only
Z4 2-Loop Emulates a dual-loop
system. Speed and duration
are measured using the loop
size and spacing set in the
Loop Emulation settings.
Z4 1-Loop
Emulates a single-loop
system. Duration is
measured using the
loop size set in the Loop
Emulation settings.
Z4 2-Loop
Emulates a dual loop
Pulsed
system; outputs will be held
active for 125 ms for each
vehicle detected, so only
speed will be measured.
Z4 1-Loop Emulates a single-loop
Pulsed
system; only indicates
vehicle presence—no speed
or duration information.
Details
Use this for a standard
SmartSensor HD system.
Use this when you're using
the SmartSensor HD in a
system that was designed
for a SmartSensor 105.
Use this when you're using
the SmartSensor HD in a
system that was designed
for a SmartSensor 105.
Use this when you're using
the SmartSensor HD in a
system that was designed
for dual inductive loops.
Use this when you're using
the SmartSensor HD in a
system that was designed
for single inductive loops.
Use this when you're using
the SmartSensor HD in a
system that was designed
for dual inductive loops
and all you need is vehicle
presence and speed.
Use this when you're using
the SmartSensor HD in a
system that was designed
for single inductive loops
and all you need is vehicle
presence; this may be useful
for doing counts.
