Using the Excluded Area window

Click any excluded (red) area, either shoulder or lane, to open this
window.
Setting Description
Range & Shows and changes the
Width
size and placement of the
excluded area (Range refers
to the distance from the
sensor).
Include Area
Restores the area or
lane that was previously
excluded.
Figure 70. Excluded Area window
Details
Change these values with
the arrows or by typing in
order to manually fine-
tune your lane placement.
Be aware that changing
these may cause other
lanes to change size or even
disappear.
When you include a
lane that was previously
excluded, it may reappear as
an automatic lane; click on
it to capture it.
Chapter 7: Configuring Lanes
67
•
