Note. The difference
between centers and
tracks is that tracks
accumulate more
quickly, but also more
quickly become solid
bars, showing only
the lane's placement.
Centers accumulate
more slowly, but
you can get more
precise information
about frequency of
vehicle detection
at a given range
for a longer time.
56
SmartSensor HD User Guide
•
Setting Description
3
Shows a ruler indicating
(Scale) distances, in feet or meters,
from the sensor. You can
click on this sidebar to see
a pop-up window showing
the spot you clicked's
distance from the sensor.
4
Shows the relative center
(Centers) of a lane, based on the
occurrence of detections;
the more vehicles are
detected at a given range,
the larger the arrow-shaped
indicators become. For best
results, you'll need to let
this run for a few minutes.
5
Shows a thin line for each
(Tracks)
vehicle that passes; as more
vehicles pass in a given
spot, the lines will pile up
to make thicker lines. You
can click on this sidebar to
clear all tracks and restart
accumulating them.
Details
Use this to measure how
far lanes or events are from
the sensor, or to determine
where to place manual
lanes.
Use this to get a sense of
where vehicles are most
often being detected, which
can be useful for verifying
lane placement or manually
adding lanes.
Use this to get a sense of
where vehicles are most
often being detected, which
can be useful for verifying
lane placement or manually
adding lanes.
