Verification options
Vehicle Display menu
Vehicle Display menu
Per Vehicle Data
Verifying lanes means comparing the detection data in the SSMHD soft -
ware with the actual traffi c in the roadway; you can observe the roadway
traffi c yourself, or record it using a separate device. If the actual traffi c
matches the soft ware traffi c, your lanes are set up properly.
Verifying lanes using vehicle display options
1
Set up a way to observe on-road traffi c: seat yourself in a place where
Figure 72. Verification screen
Figure 73. Lane verification tools
Sidebar
Sidebar button
Play/pause/stop buttons
Chapter 8: Verifying Lanes
69
•
