Changing General tab settings

Setting
Serial Number
Subnet/ID
Description
Location
Orientation
Figure 46. General tab
Description
Shows the identification
number assigned to the
sensor by Wavetronix.
Subnet: defaults to 000.
ID: defaults to the last
five digits of the sensor
serial number. No two
sensors should have the
same ID.
Lets you create a
description of the
sensor. Limit of 32
characters.
Lets you enter the
sensor's location. Limit
of 32 characters.
Lets you mark which
direction the sensor is
pointing.
Details
Can't be changed.
Subnet: change if
you want to create
groupings of sensors.
ID: generally you won't
need to change this.
Change this if you
think you'll find it
useful in identifying the
sensor later.
Change this if you
think you'll find it
useful in identifying the
sensor later.
Change this if you
think you'll find it
useful in identifying the
sensor later.
Chapter 6: Configuring Sensor Settings
43
•
