SmartSensor HD User Guide
•
2 Change the Name field at the top.
3 Click the X in the upper right corner to save and close the window.

Deleting a lane

1 Click on the lane you want to delete. The Lane window will appear.
2 Click Delete. Be aware that if the lane was automatically configured,
and if Show Auto Lanes is turned on, once it is deleted it will still
appear as a blue automatic lane.

Saving the configuration

Any of the following will save the configuration:
Click OK.
˿
Click on the gray dot under the sensor for a shortcut to the Verifica-
˿
tion screen.
Either of these will cause a prompt to appear, asking if you want to save.
Click Yes.

Sidebars, menus and windows

Sidebar
Sidebar button
Vehicle Display menu
Figure 60. Tools for accessing menus and windows
The following section outlines all options available in the various side-
bars, menus and windows accessible from the Configuration screen.
Some of these change software functionality, while others simply change
how things are displayed.
View menu
View menu
Sidebar button
Tools menu
