5.2

5.2.1 Setting the Modbus Baud Rate and Parity

The transmission speed and parity of the CM-232 are set via parameters
Baud Rate
The transmission speed of the CM-232 depends on various application-specific pa-
rameters. For example, the cable length limits the transmission speed due to signal
propagation delays.
1)
Modbus Parity
Attention! Baud rate and parity changes are only active after a reset of the fre-

5.2.2 Setting the Modbus Address

The address of the CM-232 can be set via parameter
No.
1376 Modbus Address
Note:
Attention!
For details on addressing, see chapter 6.2 "Addressing Rules".
16
16

RS232 Module CM-232

Modbus Parity
10 and
Baud Rate
10
1 – 2400 Baud Transmission rate 2400 Baud
2 – 4800 Baud Transmission rate 4800 Baud
3 – 9600 Baud Transmission rate 9600 Baud
4 – 19200 Baud Transmission rate 19200 Baud
5 – 57600 Baud Transmission rate 57600 Baud
6 – 115200 Baud Transmission rate 115200 Baud
The indicated cable lengths are recommended maximum values which depend,
among other things, on the quality of the cable.
1375
0 – EVEN EVEN Parity is used in transmission
1 – ODD ODD Parity is used in transmission
2 – None No Parity is used in transmission
quency inverter via the software or Mains Off/On.
In the case of the software reset, proceed as follows:
Via the control unit KP500 or the control software VPlus open pa-
•
Program(ming)
rameter
Set parameter value "123".
•
• Confirm by pressing "ENT".
After the reset, the frequency inverter is initialized and is ready for op-
eration after a few seconds.
Parameter
Description
Normally, it is not necessary to change the default setting (Address 1).
In the case of special operating conditions, the address can be ad-
justed.
An address change is effective immediately, i.e. without a restart of
the frequency inverter.
Modbus Instruction manual
Modbus Instruction manual
1375.
Function
Function
34.
Modbus Address
Min.
1
1)
max. cable length
30 m
30 m
30 m
30 m
10 m
10 m
1376.
Settings
Max. Fact. sett.
247 1
