Note:
Signal sources are:
- S1IND ... S6IND,
- MFI1D,
- EM-S1IND ... EM-S3IND
Assignment of parameter
* The logic state is "0" for ACT devices.
05/08
05/08
With the use of remote contacts the signal sources* are taken over from
the control word 410. Signals at the hardware contacts (terminals) are not
evaluated by the standard operation modes (e.g. 71 for S2IND).
For the evaluation of terminal signals special operation modes are avail-
able. They are denoted with the additional term "(Hardware)" and num-
bered from 526 to 546.
Exception: The controller release via the hardware contact S1IND (termi-
nal X210A.3) and Bit 0 "S1IND" of the
It is not possible to release the controller only via software.
Control Word
Control Word
410
Bit no. Bit no.
S1IND
0
1 S2IND
2 S3IND
3 S4IND
4 S5IND
5 S6IND
6 MFI1D
7 EM-S1IND
8 EM-S2IND
9 EM-S3IND
10 –
11 –
12 –
13 –
14 –
15 –
Modbus Instruction manual
Modbus Instruction manual
controlword
must be set.
Status Word
410 and actual value
Status Word
Bit no.
Ready for being switched on
0
Switched on
1
2 Operation - released
Error
3
Voltage – disabled*
4
Quick stop
5
Starting lock-out
6
Warning
7
8 –
9 Remote
Reference value reached
10
Limit value reached
11
12 –
13 –
14 –
Warning2
15
411:
411
Bit no.
