The parameter
ing meaning:
The status word reflects the operation state.
Switched on
Operation released
Error
1)
2)
If a fault occurs, the fault status is activated.
Note:
If a fault has occurred, the cause of the fault can be read out via parameter
rent Error
05/08
05/08
Status Word
Status word
411
Bit no. Function
0 Ready for being switched on
Switched on
1
Operation - released
2
Error
3
Voltage - disabled
4
Quick stop
5
Starting lock-out
6
7 Warning
–
8
Remote
9
Reference value reached
10
Limit value reached
11
–
12
–
13
14 –
Warning2
15
Status word HEX
0x23
0x27
0x08
without consideration of bits 7 ... 15!
"X" means any value ("0" or "1")
A fault can only be acknowledged 15 seconds after the occurrence of the
fault, i.e. after the internal blocking time has elapsed.
260.
Modbus Instruction manual
Modbus Instruction manual
411 has a length of 16 bits. The set bits have the follow-
1)
Bit 6 Bit 5
0 1
0 1
2)
0 X
Bit 3 Bit 2 Bit 1
0 0 1
0 1 1
1 0 0
Bit 0
1
1
0
Cur-
51
