Control Via Contacts/Remote Contacts - BONFIGLIOLI Vectron ACTIVE Manual

10.1
In the operation mode control via digital inputs or remote digital inputs (parameter
Local/Remote
S1IND, S2IND to S6IND directly or by digital input emulation with help of the single
bits in the
instructions.
Bit No.
Note:
Note:
68
68

Control via contacts/remote contacts

412 = 0 or 2) the frequency inverter is controlled via the digital inputs
controlword
. The meaning of these inputs can be seen from the operating
Controlword
Local/Remote
( 412= 2)
Name
0 S1IND
1 S2IND
2 S3IND
3 S4IND
4 S5IND
5 S6IND
6 MFI1D
7 EM-S1IND
8 EM-S2IND
9 EM-S3IND
10 -
11 -
12 -
13 -
14 -
15 -
When using the control mode "control via remote digital inputs" the control-
ler release via STOA (terminal X210A.3) and STOB (terminal X210B.2) must
be set AND bit 0 of
The two control modes digital inputs and remote digital inputs facilitate the
mode of operation
ACTIVE CUBE inverters support an external 24V supply for control logic. Even
if the mains are not switched on the communication between PLC and in-
verter can be established.
The bit 4 "Voltage enabled" of the
the mains power supply.
Bit 4 "Voltage enabled" = 0 signals "no mains voltage" and the drive start is
disabled.
Bit 4 "Voltage enabled" = 1" signals "mains voltage switched on" and the
drive is ready to start.
Modbus Instruction manual
Modbus Instruction manual
Bit No.
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
controlword
must be set to get the drive started.
"velocity mode" only.
statusword
Stateword
Name
Ready to switch on
Switched on
Operation enabled
Fault
Voltage enabled
Quick stop
Switch on disabled
Warning
-
Remote
Target reached
Internal limit active
-
-
-
Warning 2
displays the current state of
