Behavior In Case Of Quick Stop - BONFIGLIOLI Vectron ACTIVE Manual

9.1.2.1
In this case, the parameters
Maximum Frequency
below the switch-off limit) are relevant.
In a quick stop, the drive is brought to a standstill via the emergency stop ramps
Emergency Stop Clockwise
(
If frequency/speed reaches the value zero during the switch-off time, the drive con-
tinues to be supplied with current until the switch-off time has elapsed. This ensures
that the drive is at a standstill when the state changes.
58
58

Behavior in Case of Quick Stop

419) and
f
s
Switch-Off Threshold
Modbus Instruction manual
Modbus Instruction manual
Switch-Off Threshold
Holding Time
638 (holding time after the value drops
Emergency Stop Anticlockwise
424 or
Quick Stop
Emergency Stop Clockwise
Emergency Stop Anticlockwise
637
637 (percentage of parameter
425).
424
/
425
Holding Time
638
Off
Change of Status
t
