8.1.5 Function Code 8, Diagnostics

Example 1a:
Clearing all Diagnostic Counters (Sub function 0x0A) in the frequency inverter with
address 1.
Request: Master
Field:
Hex
Response: Frequency Inverter
Field:
Hex
The response is an echo of the request. All counters are now set to zero.
Example 1b:
With all counters set to zero, read Diagnostic Counter 4, "Slave Message Count" (Sub
function 0x0E) from the frequency inverter with address 1.
Request: Master
Field:
Hex
Response: Frequency Inverter
Field:
Hex
The counter value is 1(as this is the 1st message received after setting all counters
to zero).
Example 2:
Reading unknown Diagnostic Counter 8 (Sub function 0x13) from the frequency in-
verter with address 1
Request: Master
Field:
Hex
Error Response: Frequency Inverter
Field:
Hex
The exception code sent is hexadecimal value 0x01 = ILLEGAL FUNCTION.
42
42
Frequency Inverter
Adr Funct. Sub function
01 08 00
Adr Funct. Sub function
01 08 00
Frequency Inverter
Adr Funct. Sub function
01 08 00
Adr Funct. Sub function
01 08 00
Frequency Inverter
Adr Funct. Sub function
01 08 00
Adr Funct. Except.
01 88 01
Modbus Instruction manual
Modbus Instruction manual
Data
0A 00 00
Master
Data
0A 00 00
Data
0E 00 00
Master
Data
0E 00 01
Data
13 00 00
Master
CRC
87 C0
CRC
C0 09
CRC
C0 09
CRC
81 C8
CRC
40 08
CRC
11 CE
